Specifications

12
High-end performance comparable to dedicated components.
Time Alignment Pro
If sound from all the speakers arrives at the
ears simultaneously, it is more natural
sounding. Time delay can be adjusted to
achieve identical arrival times.
Crossover Pro
Fullrange speakers can be time-aligned
automatically with the AUTO setting.
One single push is all that’s needed for
the whole process.
Complex to perform manually, optimal
delay settings can be adjusted
automatically for the various speakers
in the system for true time alignment.
For experienced users, more tweaking
is possible in the manual mode.
Adjusting a crossover point’s frequency,
rolloff using “slopes” from bandpass to
6/12/18/24dB/octave and level settings.
Low Mid High
Low Mid High
Multiple speakers are necessary for wide bandwidth sound since each
speaker covers a limited frequency range. A speaker must smoothly
‘crossover’ to the next speaker, making the overall system sound as if it
was coming from a single source.
Discontinuities between
speaker units can be heard.
Integrating the sound from different
speakers into an organic, whole sound
that is more natural and lifelike.
To suit preferences and music genres, up to
five sets of user-configured PEQ settings can
be preset and stored in memory for instant
recall.
Parametric EQ Pro
Front 1-way example Front 3-way example
The professional EQ method for tuning a system’s frequency response
because of its absolute versatility and precision control. It smoothes out
system response, eliminating troublesome frequency peaks and dips.
Sound from speakers in different locations arrive at the
listener’s ears at all different times. Speakers are
electronically processed with varying time delays to ensure
all the sound is heard at the same time no matter how the
speakers are positioned.
Test microphone picks up the
system’s frequency response.
Note: test microphone not supplied with the AVN8826.
Please contact your ECLIPSE dealer.
Each vehicle type has its own acoustic environment.
System frequency response is precisely adjusted
manually for an ideal flat frequency response.
Audio
A simpler time alignment
performed by selecting the car type
and speaker positions, then
adjusting each speaker level. Delay
parameters are then adjusted for a
time-aligned response.
Simpler parametric equalisation
function can adjust the “Q,” i.e.
bandwidth, of each of the 7 centre
frequencies from wide to narrow in
3 steps.
Normal Mode
Time Alignment
7-band Parametric EQ
Perform easy audio
customisation using the
AVN8826 by itself.
AVN8826 + DCU105 — Precision tonal contouring for accurate sound.
AVN8826
AVN8826 + DCU105 — Optimising for the best audio performance.
AVN8826
AVN8826 + DCU105 — Wide-bandwidth, perfectly balanced sound.
