Specifications

2005/9·G-1084·10 Printed in Germany
FUJITSU TEN LIMITED
Kontakt: FUJITSU TEN (EUROPE) GMBH
Mündelheimer Weg 39. D-40472 Düsseldorf
Tel: [phone]
Fax: [phone]
www.eclipse-web.com/eu/
14.4V Power Supply
CD8445E CD5425E
Max. Power Output 50W × 4
RMS Power Output 14W × 4 (20 — 20,000Hz, 1% THD, 4Ω)
Preamp Output and Impedance 8V(0dB)/55Ω 5V(0dB)/55Ω
Tone Bass/Mid/Treble ±12dB at 80Hz/±12dB at 630Hz/±12dB at 10kHz
Control
Loudness +10dB at 100Hz/+6.5dB at 10kHz
FM Frequency Range 87.5 — 108.0 MHz (50kHz step)
Usable Sensitivity 13dBf
50dB Quieting Sensitivity 14dBf
Frequency Response 30 — 15,000Hz
Stereo Separation 38dB (1kHz)
MW Frequency Range 522 — 1,611kHz (9kHz step)
Usable Sensitivity 20µV
LW Frequency Range 153 — 279kHz (3kHz step)
Usable Sensitivity 30µV (216kHz)
CD Frequency Response 20 Hz — 20,000Hz
S/N Ratio (A-weighted) 100dB 95dB
Total Harmonic Distortion 0.008%
Channel Separation 85dB 80dB
Memory Frequency Response 20 — 20,000Hz —
Stick
S/N Ratio (A-weighted) 100dB —
Total Harmonic Distortion 0.008% —
Dimensions (W × H × D) 178 × 50 × 155mm
Notes and Precautions
CD8445E CD5425E
CONTROL
Remote Control ● Optional
CD Changer Control ●●
CD-R/CD-RW ●●
WMA ● —
MP3 ●●
Digital Servo System (DSS) ●●
TUNER
FM/MW/LW ●●
RDS Tuner AF, REG, TP, TA, PS, PTY, EON
AUDIO
Output Voltage and Impedance 8V/55Ω 5V/55Ω
MOSFET Amplifier ●●
Advanced 24-Bit ∆∑ DAC ● —
Source Volume Control (SVC) ●●
Sound Control Mode Professional
On Off
—
Circle Surround II — ● —
Bass/Mid/Treble Control ● — ●
Time Alignment ●● —
Parametric EQ 10-band 7-band —
Multi-Harmonizer (MP3/WMA/ATRAC3) ●● —
Listening Position Selector — ● —
Crossover ●● ●
Non Fader Level / Phase Control ●● ●
Frequency Response Analysis ● ● —
3-band Graphic EQ — ●
Dual Pre Outputs ●●
Non-Fader Pre Outputs ●●
AUX In ● Optional
GENERAL
5-pattern illumination ● —
Dimmer Control ● —
ATRAC3 Decoder ● —
ESN security MS/CD CD
Detachable Front panel ●●
Display 8-step VF LCD
Full Face Tilt ●●
E-LAN data link system ●●
Telephone mute ●●
Feature List
Specifications
Product safety notice
• To ensure the safe operation of ECLIPSE
products, please read the owner’s manuals
carefully prior to using.
• ECLIPSE is not responsible for any accident or
damage due to improper installation, connections
or products modified in any way.
Warning
• All products are intended for DC 12-Volt
operation in negative grounded vehicles only.
Never use them in 24-Volt vehicles such as heavy
trucks or diesel cars with cold-region
specification, aircraft or marine environments
unless specifically rated to handle these
conditions.
• Do not adjust controls while driving. To adjust the
controls, stop the car in a safe location.
Caution
• Installation of products requires experience and
knowledge. Ask your ECLIPSE retailer for proper
installation.
• ECLIPSE cannot guarantee that every product it
manufactures will be able to be installed in every
vehicle model or make. To be sure, please consult
your ECLIPSE retailer.
• In some cases due to installation-related
considerations, additional connecting cables may
need to be purchased for an ECLIPSE product.
• The rear view camera is a parking aid. It must be
used only to supplement your vehicle's side view
and rearview mirrors. It is not a substitute for
mirrors and careful driving.
• Do not remove the HDD from the head unit.
ECLIPSE is not responsible for any loss of data,
damage or malfunction to the disk drive
mechanism resulting from unauthorised removal
or tampering with the HDD.
• Please be sure to follow instructions provided in
the installation manual for correct procedures as
incorrect installation may affect driving-related
operation and/or airbag operation.
• Please make sure only the official parts supplied
with the unit are used. Do not substitute other
parts as it may affect operation or compromise
unit build integrity.
• Optimal MP3 and WMA file reproduction quality
depends greatly on the original encoding process.
Depending on the original encoding, files may
sometimes not playback properly.
• The ECLIPSE navigation system requires its
dedicated database for optimal performance. Do
not insert other database DVDs that may cause
the unit to malfunction or not respond.
General
• Product design and specifications are subject to
change without prior notice or obligation as
ECLIPSE reserves the right to constantly seek to
improve its products.
• Due to characteristics and properties of various
photography and printing processes, the
colour(s) of the actual product may slightly differ
from those shown on these pages.
• Some screen images shown are simulated.
Licensing and Trademarks
• “Dolby”, “Pro Logic” and the double D symbol 2
are trademarks of Dolby Laboratories and the
Dolby Laboratories Licensing Corporation.
• “dts” and “dts Digital Out” is a trademark of
Digital Theater System, Inc.
• Circle Surround II and the SRS logo are
trademarks or registered trademarks of SRS
Labs, Inc.
• TMC is a registered trademark of Grundig
Aktiengesellschaft.
• Memory Stick is a registered trademark of Sony
Corp.
• Magic Gate is a registered trademark of Sony
Corp.
Others
• Some recent audio discs may resemble
conventional music CDs but are technically not
Compact Discs (CD Red Book format) because of
the copy protection technology employed.
ECLIPSE cannot guarantee operation and
performance if these discs are used.
• DVD-R/RW and DVD+R/RW playback is possible
only for discs formatted for video mode.
• VR (Video Recording) mode-recorded discs and
discs not finalised will not play in the unit.
• Some PC-authored discs may not play due to
software application settings during authoring.
• DVD-R/RW, DVD+R/RW and CD-R/RW playback
quality may be affected by disk surface condition
and disc format initialisation process.
• DVD-R/RW, DVD+R/RW, CD and CD-R/RW discs
may not operate perfectly on unit due to disc
imperfections.
• DVD-R/RW, DVD+R/RW, CD and CD-R/RW disc
performance may suffer if a disc exhibits
excessive wear, dirt and scratching
• ATRAC3 is an efficient compression codec for
digital music files, allowing files to take up just
1/10 their uncompressed size without degrading
audio quality.
• Playback of song data is only possible on Magic
Gate-compatible memory stick devices.
• Memory Sticks up to 128MB can be used.
Initialisation must be executed with Windows
2000 or later.
• ECLIPSE is not responsible for any data loss on a
Memory Stick or HDD due to unit failure or
malfunction.
Operation notes
• DVD-Video compatible units are only compatible
with NTSC/PAL standards and Region-2
DVD-Video discs.
• DVD-Video is disabled when the vehicle is in
motion. Inserting a DVD-Video will only allow the
audio to be heard.
• The Global Positioning System or GPS was
developed in the United States. It is a system that
pinpoints a current position making use precisely
of radio waves transmitted to earth from 3 or 4
GPS satellites.
• GPS data can sometimes be unavailable due to
circumstances such as:
•
Interrupted GPS satellite radio waves because of
geographical interference factors such as
buildings, tunnels, elevated roads and similar
conditions.
•
Unsatisfactory reception due to objects being on
or in the near vicinity of the GPS antenna.
•
Interrupted transmission service may sometimes
result from periodic maintenance or upgrades
being performed by the US-based GPS tracking
control system.
•
Transmission can be interrupted or degraded
when a digital cellular operating on a 1.5GHz
frequency rate is being used in the vicinity of the
GPS-enabled unit.
AVN-specific
• Do not follow a navigation route if it could place
you in an illegal, unsafe, or dangerous situation.
• Navigation controls cannot be operated in a
moving vehicle.
• Do not watch moving images on a product
display while driving as doing so may lead to an
accident resulting in serious injury or death.
