HO
Low Voltage Connectors
Miniature Jack 2.6 mm
SPECIFICATION:
Current rang: 16 A
Voltage rang: 60 V DC max.
Contact resistance: 5 mΩ max.
Operang temperature: -25°C up to 85°C
MATERIAL:
Housing: ABS
Contact: CuZn38Pb1.5-F41
Screw: CuZn39Pb3-F51
FINISH:
Contact: Glossy nickel plated 3-5 µm
Screw: Glossy nickel plated 3-5 µm
HANDLING:
Connecon: Hand soldering
Packing: Bulk
Order-Informaon
Series: Colour:
HOB #
HO Socket 2.6 mm SW: black *
RT: red *
BL: blue *
GE: yellow *
GN: green *
GR: grey
WS: white
BR: brown
* = standard OR: orange
