Data Sheet

RM 2,54 mm, schneidklemm, lange
Verriegelungen
DIN 41651 Flachkabel Verbindersystem
Wannenstecker mit Verriegelung
Pitch 2.54 mm, IDC, long latches
DIN 41651 Flat Cable Connector System
Box Headers with Locking
SPECIFICATION:
Operating Current (Nom.): 3 A
Operating Temperature: -55°C to 105°C
Insulation Resistance (Min.): 5000 MΩ
Contact Resistance (Max.): 30 mΩ
Dielectric Strength: 1,000 Vac
MATERIAL:
Material (Housing): PBT
Flammability Class: UL 94 V-0
Material (Contact Area): copper alloy, gold plated
HANDLING:
Packaging: tray
TOLERANCE:
.X: ± 0.30
.XX: ± 0.20
Order Informaon
Idener:
No. of Contacts:
Version:
Locking:
WS # SK VL
Box header with ange pitch 2.54 mm
10: 2 x 5
IDC
long latches
14: 2 x 7
16: 2 x 8
20: 2 x 10
24: 2 x 12
26:
2 x 13
30:
2 x 15
34:
2 x 17
40:
2 x 20
50: 2 x 25
60: 2 x 30
