Instruction Manual
EN Instruction Manual ��������������������������������������������������������������������������������������������������������������2 Live Smart. Enjoy Life. Congratulations on the purchase of your ECOVACS ROBOTICS WINBOT! We hope it brings you many years of satisfaction. We trust the purchase of your new robot will help keep your home clean and provide you with more quality time to do other things. Before you go any further, please register your product on the ECOVACS ROBOTICS website at www.
Contents 1. Important Safety Instructions �������������������������������������������������������������������������������������������������������������������������������������������4 2. Package Contents and Technical Specifications �����������������������������������������������������������������������������������������������������������6 3.
1. Important Safety Instructions IMPORTANT SAFETY INSTRUCTIONS When using an electrical appliance, basic precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE SAVE THESE INSTRUCTIONS 1. This Appliance is not intended to be used by children under 8 or anyone lacking knowledge on proper use. Supervision may be necessary. Do not allow children to play with the Appliance. 2.
1. Important Safety Instructions 23. The Appliance must be disconnected from the receptacle before removing the battery for disposal of the Appliance. 24. Please dispose of used batteries according to local laws and regulations. 25. Do not incinerate the Appliance even if it is severely damaged. The battery can explode in a fire. 26. The Appliance must be used in accordance with the directions in this Instruction Manual.
2. Package Contents and Technical Specifications 2.1 Package Contents WINBOT Power Adapter Instruction Manual Quick Start Guide Safety Pod with Batteries Remote Control with Batteries Cleaning Pads * 4 WINBOT Cleaning Solution Note: Figures and illustrations are for reference only and may differ from actual product appearance. Product design and specifications are subject to changes without notice.
2. Package Contents and Technical Specifications 2.2 Specifications Model 2.3 Product Diagram WINBOT WA30 Working voltage 22.2V DC Rated power 60W Handle Remote Control Rated output voltage 3V DC Power Adapter OH-1048A2701700U1-U Input 100-240V AC, 50/60Hz,1.5A Output 27V DC, 1.7A Note: Technical and design specifications may be changed in the course of continuous product improvement.
2.
2.
3. Operating and Programming 3.1 Notes Before Cleaning EN Do not use WINBOT on a framed window with a frame smaller than 5mm (0.2’’). WINBOT can clean framed or frameless glass, larger than 50cm x 50cm (19.7’’ x 19.7’’). If WINBOT’s Status Indicator Light flashes RED, the battery requires charging. If the Battery Pod’s Battery Indicator Light flashes RED, the battery power is low, and the Safety Pod cannot work. Please change the battery.
3. Operating and Programming If the window is covered with dirt, clean a small area on the glass before use and place WINBOT there. WINBOT can clean glass mounted at an angle but may not operate normally; in such a case, a person should be in the vicinity to assist should there be a problem. WINBOT can clean horizontally mounted glass but only when using the Direction Control Buttons on the Remote Control. Keep the Safety Pod firmly attached to the glass. Do not use WINBOT upside down.
3. Operating and Programming 3.2 Using WINBOT 1 3 Charge WINBOT Assemble Power Adapter Note: When WINBOT is charging, the Status Indicator Light flashes BLUE. When WINBOT is fully charged, WINBOT glows a continuous BLUE and then goes out. 2 Power ON 4 Attach the Cleaning Pad Note: Make sure the white side of the Cleaning Pad attaches to the Velcro. Note: Keep objects away from WINBOT’s Fan to avoid blockage. EN 12 Make sure the Cleaning Pad does not cover the Squeegee or Edge Detection Sensors.
3. Operating and Programming 5 Spray Cleaning Solution Note: It is recommended to use WINBOT with WINBOT Cleaning Solution from ECOVACS. Using tap water or other cleaners could have an adverse effect on cleaning performance. Using other cleaning solutions could potentially nullify the warranty. 1 Step 2 Step After spraying, wipe the bottom of WINBOT with a dry cloth. Note: The spray volume can be subject to the condition of dirt.
3. Operating and Programming Warning: When using WINBOT to clean windows, Safety Pod must be used to guarantee the safety function of WINBOT.
3.
3. Operating and Programming 2 Step Make sure Safety Pod is attached at least 1.6 meters above ground, and the robot is suggested to be placed within an 1-meter radius of Safety Pod. 3 Step Note: WINBOT has successfully attached to the window when the WINBOT Status Indicator Light glows a continuous BLUE and beeps. Note: The Fan does not start until Safety Pod is firmly pressed on the glass and keep it away from hair or any debris..
3. Operating and Programming 4 Step Deep Cleaning Mode AUTO Cleaning Mode This mode is applicable for glass of more concentrated dirt or dust. This is the most commonly used mode and is good for regular cleaning. OR 9 Note: WINBOT automatically chooses the suitable cleaning path in “N” or “Z” Cleaning Mode depending on the shape of the window. Pause Note: Direct WINBOT to move using the Direction Control Buttons on the Remote Control when Paused.
3. Operating and Programming 10 Stop When WINBOT completes its cleaning cycle, it returns to the place it started and beeps. 1 3 Step Step Note: Remove WINBOT from the window after the fan stops working. Polish away any marks left on the glass from the robot’s removal with a dry cloth. If you want to stop the WINBOT during cleaning, please first press Start/Pause Button once to pause WINBOT and then press and hold this button for more than 5 seconds to remove WINBOT.
4. Maintenance Before performing cleaning and maintenance on WINBOT, Power OFF WINBOT and disconnect it from the Power Adapter. 4.1 Cleaning Pad 4.2 Fan, Sensors and Squeegee Fan Side Rollers Wash with mild detergent . Do NOT use a wet Cleaning Pad on WINBOT or it may slip on the window. Washing the Cleaning Pad regularly can extend its service life. If the Cleaning Pad becomes worn or no longer fits exactly within the Velcro area, replace it with a new one to achieve best cleaning performance.
4. Maintenance Edge Detection Sensors 4.3 Driving Treads 1 Step Squeegee 2 Step EN 20 Inspect the Driving Treads by using the Direction Control buttons on the Remote Control. Stop the Driving Treads if dirt is seen on the Treads.
4. Maintenance 4 Step 4.4 Safety Pod Note: Remove the Safety Pod’s battery if the robot will not be used for a long time. In case of battery leakage, please remove the battery and dispose of it according to local laws and regulations.
4. Maintenance 4.5 Regular Maintenance To keep WINBOT running at peak performance, perform the maintenance and replacement according to the following frequency. Robot Robot Part Maintenance Frequency Replacement Frequency Cleaning Pad After each use Every 40 washings After each use / Fan Side Rollers WINBOT Edge Detection Sensors Squeegees Driving Treads Note: ECOVACS manufactures various replacement parts and assemblies. Please contact Customer Service for more information on replacement parts.
5. Status Indicator Light and Sounds Indicator WINBOT Status Indicator Light flashes BLUE 1. WINBOT is charging. 2. WINBOT has been paired with Safety Pod already and ready to be placed on the glass. WINBOT Status Indicator Light glows a continuous BLUE 1. WINBOT has successfully adhered itself to the glass and is ready to clean. 2. The Safety Pod is in preparation. WINBOT Status Indicator Light flashes RED The robot’s battery is low. Charge WINBOT as described in Section 3.2.
6. Troubleshooting No. 1 2 EN 24 Malfunction The robot’s fan does not work Remote Control does not work Possible Causes Solutions Safety Pod malfunction Check the Safety Pod Status Indicator Light on the WINBOT, and refer to Section 5 for details. When WINBOT is cleaning, only the START/ PAUSE Button works on the Remote Control. Pause WINBOT by pressing the START/PAUSE button on the robot or Remote Control. Other buttons on the Remote Control will function when WINBOT is paused.
6. Troubleshooting No. 3 Malfunction WINBOT Status Indicator Light flashes BLUE after the product is placed on the glass. Possible Causes Solutions The Cleaning Pad is attached incorrectly and is covering the fan or the Edge Detection Sensors. Remove the Cleaning Pad and re-attach it making sure it is placed exactly within its Velcro area and does not cover the fan or the Edge Detection Sensors. Edge Detection Sensor malfunction. A.
6. Troubleshooting No. 4 5 EN 26 Malfunction WINBOT Status Indicator Light of the product glows a continuous RED Safety Pod Status Indicator Light of the product glows a continuous RED Possible Causes Solutions WINBOT has moved over a problem area and is losing suction. A. Press the RESET Button on the Remote Control. Use the Direction Control buttons on the Remote Control to move WINBOT away from the problem area and at least 10cm/4〃 from window corners and obstacles. Restart WINBOT. B.
6. Troubleshooting No. Malfunction Possible Causes Solutions There is too much dirt and debris on the window. A. Spray additional Cleaning Solution on the Cleaning Pad. B. Clean the Driving Treads as described in section 4. C. Replace the Cleaning Pad and restart the cleaning cycle. D. Use the Remote Control to control the cleaning by pressing Direction Buttons. * WINBOT is intended to be used for maintenance cleaning on common windows.
Ecovacs Robotics Co., Ltd No. 18 You Xiang Road, Wuzhong District, Suzhou City, Jiangsu Province, P.R.
