2.2 Specifications 2.3 Product Diagram
WINBOT
2. Package Contents and Technical Specifications
Model WA30
Working voltage 22.2V DC Rated power 60W
Remote Control
Rated output voltage 3V DC
Power Adapter OH-1048A2701700U1-U
Input
100-240V AC,
50/60Hz,1.5A
Output 27V DC, 1.7A
Note: Technical and design specications may be changed in the course
of continuous product improvement.
Handle
Charging Port
Safety Pod Status Indicator Light
Safety Pod Port
WINBOT Status Indicator Light/
START/ PAUSE Button
