Patient Monitor User Manual Calculation and Titration Table
- 135 -
INF Rate= DOSE / Concentrate
Duration= Amount / Dose
Dose= Rate × Concentrate
DRIP Rate= INF Rate / 60 × DROP Size
21.1.2 Calculation Unit
Each drug has the fixed unit or unit series to calculate. Among the same unit series, the unit
binary varies with the entered parameter value.
The calculation units of the drugs are listed as follows:
Drug Unit
DRUG A, DRUG B, DRUG C, AMINOPHYLLINE,
DOBUTAMINE, DOPAMINE, EPINEPHRINE, ISUPREL,
LIDOCAINE, NIPRIDE, NITROGLYCERIN
g, mg, mcg
DRUG D, PITOCIN, HEPARIN Ku, mu, Unit
DRUG E mEq
When defining a drug, select Drug A, Drug B, Drug C, Drug D, and Drug E based on the unit
series.
NOTE:
1 The drug calculation is displayed as invalid value before the user edits the drug name
and patient weight, and the user can’t enter any value.
2 Drip Rate and Drop Size are invalid in the neonatal mode.
21.2 Titration Table
After completing the drug calculation, the user can open the Titration on the Drug Dose
interface.
The user can change the following items in the titration table:
z Basic
z Step
z Dose Type
The data in the trend table will vary with the changes above. And the user can perform the
following:
z Scroll up and down the screen by selecting and pressing the symbol and displayed
on the trend graph.
z Record the data displayed in the current window by selecting Record.
