Minimum input slew rate >2.5V/S
Heart rate
Measurement Range ADU: 15 bpm ~ 300 bpm
PED/NEO: 15 bpm ~ 350 bpm
Accuracy ±1% or ±1 bpm, whichever is greater
Resolution 1 bpm
PVC
Measurement Range ADU: 0~300 PVCs/ min
PED/NEO: 0~350 PVCs/ min
Resolution 1 PVCs/min
ST value(only applicable to adult˅
Measurement Range -2.0 mV ~ +2.0 mV
Accuracy -0.8 mV ~ +0.8 mV: ±0.02 mV or 10% (), whichever is
greater.
Beyond this range: undefined
Resolution 0.01 mV
HR averaging method
Method 1 Heart rate is computed by excluding the minimum and
maximum values from the 12 most recent RR intervals and
averaging the residual 10 RR intervals.
Method 2 If each of three consecutive RR intervals is greater than
1200ms, then the four most recent RR intervals are
averaged to compute the HR.
Range of Sinus and SV Rhythm
Tachy ADU: 120 bpm ~ 300 bpm
PED/NEO: 160 bpm ~ 350 bpm
Normal ADU: 41 bpm ~ 119 bpm
PED/NEO: 61 bpm ~159 bpm
Brady ADU: 15 bpm ~ 40 bpm
PED/NEO: 15 bpm ~ 60 bpm
Range of Ventricular Rhythm
Ventricular Tachycardia The interval of 5 consecutive ventricular beats is less than
600 ms
