Copyright© by Edimax Technology Co, LTD. all rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of this company.
CATALOG Chapter I: Product Information…………………………………………………………1 1-1 Introduction and safety information .............................................................. 1 1-2 Safety Information......................................................................................... 1 1-3 System Requirements .................................................................................. 2 1-4 Package Contents ........................................................................................
CHAPTER III: Soft-AP Function.........................................................….…………51 3-1 Switch to AP Mode and Basic Configuration......................................................... 51 3-2 Security Setting .................................................................................................... 55 3-3 Access Control...................................................................................................... 57 3-4 Connection Table .........................................
Chapter I: Product Information 1-1 Introduction and safety information Thank you for purchasing this high-speed wireless network card! Excepting common wireless standards 802.11b/g, this wireless network card is also able to access 802.11n wireless networks - data transfer rate is 150Mbps, and that’s three times faster than 802.11g wireless network! With easy-to-install USB 2.
KEEP THIS NETWORK CARD OUT THE REACH OF CHILDREN! 4. This network card will become hot when being used for long time (This is normal and is not a malfunction). DO NOT put the network card on a paper, cloth, or other flammable objects after the network card has been used for a long time. 5. There’s no user-serviceable part inside the network card. If you found that the network card is not working properly, please contact your dealer of purchase and ask for help.
1-5 Familiar with your new wireless network card 1. USB Connector 2. Link/Activity LED 3. WPS Button 2 1 3 LED Name Light Status Description The network card has linked to a wireless Link/ On access point and is receiving or transferring data.
CHAPTER II: Driver Installation and Configuration 2-1 Network Card Installation Please follow the following instructions to install your new wireless network card: 1. Insert the USB wireless network card into an empty USB 2.0 port of your computer when computer is switched on. Never use force to insert the card, if you feel it’s stuck, flip the card over and try again.
2. The following message will appear on your computer, click ‘Cancel / Close’. Under Windows XP Under Windows Vista 3. Software Installation, This wizard can be run in Windows 2000/XP/Vista. The following procedures are operated in Windows XP. You can install the Wireless Adapter by EZMAX Setup Wizard in the CD-ROM including in the package. The wizard is an easy and quick configuration tool for internet connection with series process.
If you lose the CD ROM or you prefer the traditional setup procedure, please follow the instruction as following step. 4. Execute ‘Setup.exe’ program inside the CD then the programs will appear. Please read the end user license agreement and click ‘I accept the terms of the license agreement’ then click ‘Next’ button, to accept license agreement.
5. It is recommend installing driver and utility if the network card is installing the first time. If you want to update the driver only, choose ’Install driver only’. Click ‘Next’ to continue. 6. You can choose the configuration tool used to configure the wireless network card here. It’s recommended to select ‘Edimax Configuration Tool’, which provides fully access to all functions of this wireless network card.
7. Now you’ll see the following message, please click ‘Install’ to start utility installation. If you see ‘Found New Hardware’ message again, please ignore it and wait. 8. Please wait while the install procedure is running. When you see this message, please click ‘Finish’ to complete the driver installation process.
9. After installation is complete, wireless configuration utility will be shown in the desktop of your computer automatically. You will also see an icon at the lower-right corner of your windows system. If you put the mouse cursor on the icon, the status of wireless card will be displayed as a popup balloon. HERE! 10. When you want to configure your wireless connection, please right click on this icon, and a popup menu will appear. You can click ‘Launch Config Utility’ to start configuration program.
11. Please note that if you stopped config utility by ‘Exit’ function, you’ll not be able to maintain the wireless link to the access point you wish to use. In this case, you can start config utility again by clicking ‘Edimax Wireless Utility’ icon from ‘Start’ -> ‘All Programs’ -> ‘Edimax Wireless’, as shown below.
2-2 Connect to Wireless Access Point After the driver is correctly installed, it will try to connect to any unencrypted wireless access point automatically. If you want to connect to a specific wireless access point, or the access point you wish to connect uses encryption, you have to configure the wireless network card and input required parameters, to get connected to the wireless access point you wish to connect.
2-2-1 Using Edimax Utility Please follow the following instructions to use Edimax configuration utility to connect to wireless access point. 1. Right-click the Edimax configuration utility icon located at lower-right corner of computer desktop and then click ‘Launch Config Utility’. Edimax setup utility (RaUI) will launch, and begin to scan for all wireless access points automatically. Menu Setup Area More / Less button RaUI consists two parts: Menu and setup area.
You can click ‘More / Less’ button again, and setup utility window will resume to its original size. Tip: If a setup item requires more information to complete the setup procedure, the setup utility window will expand automatically.
2-2-1-1 Scan for Other Wireless Devices There are two kinds of wireless connection mode: Infrastructure and Ad-Hoc. Infrastructure mode is used by wireless access points, which is able to establish wireless connection for you and other wireless / wired network clients.
Scan results will be displayed here, please check if the wireless device (access point or another computer) with the SSID you wish to connect is shown here. Scan result includes 6 types of information, they are: A B C D E A The SSID (Service Set Identifier) of wireless device. If nothing is displayed here, it means the SSID of this wireless device is hidden. If a symbol appears in front of the name of wireless device, means you’ve established connected with that wireless device.
If you can not see the access point you wish to connect here, please click ‘Rescan’ button to scan for access point again, until the one you preferred is displayed. You may have to click ‘Rescan’ for more than two times before you can see the access point you wish to use here.
There are 4 types of technical information: General: Displays basic information about this access point, such as SSID, MAC Address, authentication / encryption type, channel etc. WPS: If this access point supports WPS (Wi-Fi Protected Setup), related information will be displayed here. CCX: If this access point supports CCX (Cisco Compatible eXtension), related information will be displayed here. 802.11n: If this access point complies with 802.11n draft, related information will be displayed here.
2-2-1-2 Connect to an Access Point If the wireless access point you wish to connect is found, you can establish connection with it by clicking ‘Connect’ button. Instructions will be given as follow: 1. Click the wireless access point or network device you wish to connect, it will be highlighted, then click ‘Connect’. If the access point you selected does not use encryption, you’ll be connected to this wireless access point within one minute.
2. If the wireless access point does not have SSID, you’ll be prompted to input it now. Please ask the owner of wireless access point for the exact SSID and input it here, then click ‘OK’ when ready. If the SSID you provided here is wrong, you’ll not be able to connect to this access point. 3. If the wireless access point uses encryption, you will be prompted to input its WEP key or WPA preshared key.
4. Please ask the owner of the wireless access point you want to connect, and input the correct key here and then click ‘OK’. By checking ‘Show Password’ box, the encryption key you inputted here will be displayed. If the value you inputted here is wrong, you will not be able to connect to this wireless access point. Authentication type will be selected by the authentication type of the access point automatically, please don’t change it. However, if you’re connecting to an access point uses 802.
21
2-2-1-3 Add an Access Point to Profile If you will connect to some specific wireless access point frequently, you can add their information to the profile. Just like the telephone directory, the profile saves all information of access points, and you can recall them anytime you wish to establish connection. You can add a found access point to profile, or input all information of an access point by yourself.
Here are descriptions of every setup item: Item Name Profile Name SSID Network Type Description You can give this profile a name. Every profile needs a unique name. Please input the SSID of this access point. If you selected an access point from the list, and its SSID is not hidden, the SSID will be filled automatically; however, you can modify the SSID by yourself. Please select the network type: Ad hoc or Infrastructure.
Channel You can select the radio channel number for Ad-Hoc mode here. Please select CAM (constantly awake mode, keep wireless radio activity even when not transferring data), or PSM (Power saving mode, switches radio off when not transferring data). Power Save Mode It’s recommended to choose ‘PSM’ if you’re using this network card with notebook computer to help the battery live longer. RTS Threshold Check this box to set the RTS threshold by yourself.
will be selected automatically, and please do not change it. If you select ‘LEAP’, you’ll be prompted to input LEAD specific settings: Please input LEAP identity, password, domain name, and select encryption type. You can check ‘Show Password’ box so the password you inputted will be displayed as you type, but not replace by asterisk. Encryption Select the encryption type of the wireless access point or wireless device you wish to connect.
To set 802.1x authentication for the access point. Please click ‘802.1X’ tab: Here are descriptions of every setup item: Item Name EAP Method Description Select 802.1x EAP method from dropdown menu. Please ask the administrator of the access point you wish to connect to select a correct EAP method. Select 802.1x tunnel authentication type from dropdown menu. Please ask the administrator of the access point you wish to connect to select a correct tunnel authentication method.
load .pac credential file; to remove a loaded credential file, click ‘Remove’. Session Resumption You can enable or disable session resumption here. If you don’t know if you should enable session resumption or not, please ask your 802.1x authentication administrator. Input 802.1x username (ID) and password and other information if it ID \ Password is required here. Click ‘Show Password’ to show the password you tab typed.
2-2-2 Using Windows Zero Configuration Windows XP and Vista has a built-in wireless network configuration utility, called as ‘Windows Zero Configuration’ (WZC). You can also use WZC to configure your wireless network parameter: 1. Right-click Edimax configuration utility icon and select ‘Use Zero Configuration as Configuration utility’. 2. Right click Windows Zero Configuration icon and select ‘View Available Wireless Networks’.
3. Click ‘Start’ button (should be located at the bottom-left corner of windows desktop), click ‘Control Panel’, then click ‘Network and Internet Connections’ in Control Panel. 4. Click ‘Network Connections’.
5. Right-click ‘Wireless Network Connection’ (it may have a number as suffix if you have more than one wireless network card, please make sure you right-click the ‘Edimax 802.11n Wireless LAN Card), then select ‘View Available Wireless Networks’. 6. All wireless access points in proximity will be displayed here. If the access point you want to use is not displayed here, please try to move your computer closer to the access point, or you can click ‘Refresh network list’ to rescan access points.
7. If the access point is protected by encryption, you have to input its security key or passphrase here. It must match the encryption setting on the access point. If the access point you selected does not use encryption, you’ll not be prompted for security key or passphrase. 8. If you can see ‘Connected’ message, the connection between your computer and wireless access point is successfully established.
2-3 Profile Management If you need to connect to different wireless access points at different time, like of access point of your home, office, cybercafe, or public wireless service, you can store the connection parameters (encryption, passphrase, security etc, etc.) as a profile for every access point, so you don’t have to input these parameters every time when you want to connect to a specific wireless access point.
2-3-1 Add a profile If you want to click new profile, click ‘Profile’ menu, then click ‘Add’ button. You’ll be prompted to input detailed information of access point, as described in Section 2-2-1-3.
2-3-2 Edit an existing profile If you have added a profile before, and you wish to change the content of the profile, you can use this function. Please select a profile from the list first, then click ‘Edit’ button. You’ll be provided with the contents of selected profile, and you can edit them. Click ‘OK’ to save changes, or click ‘Cancel’ to discard changes.
2-3-3 Delete an existing profile If you no longer need a profile, you can delete it. Select the profile you wish to delete from the list, and click ‘Delete’ button to delete it.
2-3-4 Activate a profile When you want to connect to a specific wireless device in the profile list, you can select it and click ‘Activate’ button, to establish connection with it. 1. When you selected a profile and click ‘Activate’ button to activate the profile, a icon will be displayed in front of the profile to show that the connection is failed; When the connection is successfully established, a icon will be displayed.
2-4 Advanced Settings This wireless network card provides several advanced settings for experienced wireless users. You can change these settings to increase data transfer performance, or change operation mode. Please follow the following instructions to set advanced wireless settings: 1. Right-click the Edimax configuration utility icon located at lower-right corner of computer desktop and then click ‘Launch Config Utility’. 2.
Here are descriptions of every setup item: Item Name Description Wireless mode Display the wireless operation mode of the network card. Enable Tx Burst Check this box to accelerate the data transmit rate. It may not work with all wireless access point and wireless devices. Enable TCP Window Size Check this box and the configuration utility will adjust TCP window size automatically to get better performance.
2-5 View Network Statistics The configuration utility provides information about network statistics and link status. If you want to know how your wireless network card works, you can use these functions to get detailed information about the wireless connection you’re using. Please follow the following instructions to check network statistics: 1. Right-click the Edimax configuration utility icon located at lower-right corner of computer desktop and then click ‘Launch Config Utility’. 2.
2-6 WMM Setting This wireless network card provides WMM (Wi-Fi Multimedia) function, which can improve the performance of certain network applications, like audio/video streaming, network telephony (VoIP), and others. When you enable the WMM function of this network card, you can define the priority of different kinds of data, to give higher priority to applications which require instant responding. Therefore you can improve the performance of such network applications.
In ‘WMM Setup Status’ block, current WMM settings will be displayed. And here are descriptions of every setup item: Item Name WMM Enable Description Check this box to enable WMM function. Please click ‘Apply’ button on the right of this check box after you check or uncheck this box, so corresponding settings in this window will be activated or deactivated respectively. Check this box to enable WMM power saving mode to save energy, and let your computer’s battery live longer.
2-7 WPS Configuration Wi-Fi Protected Setup (WPS) is the latest wireless network technology which makes wireless network setup become very simple. If you have WPS-enabled wireless access point, and you want to establish a secure connection to it, you don’t have to configure the wireless access point and setup data encryption by yourself.
2-7-1 WPS Button (Push-Button) With WPS button, it is easy to connect with a secure wireless network. If the wireless AP/Router supports WPS feature, just press the WPS button of the wireless AP/Router first. After press the WPS button on the wireless adaptor. The wireless adaptor will scan and connect with the AP/Router automatically, no need any further setup process and security setting ...etc. in the adaptor utility. 2-7-2 WPS Setup - PBC (Push-Button Configuration) 1.
You can also set ‘Config Mode’ to ‘Registrar’. In this mode, this wireless network card will wait for other WPS-enabled access points to send WPS pairing requests. Please refer to the instruction given by your wireless access point’s user manual to understand how to send WPS requests. 4. Before you start to establish the wireless connection by using WPS, you can click ‘Rescan’ button to search for WPS-enabled access points near you again, to make sure the WPS function of your access point is activated.
You can click ‘PBC’ button few more times to try again. When an access point is connected, you can click ‘Disconnect’ to disconnect your wireless network card from a connected access point, or select another WPS-enabled wireless access point, then click ‘Connect’ to establish connection to selected access point, if there are more than one WPS-enabled access point found. You can also click ‘Rotate’ button, and next access point on the list will be selected to establish connection.
2-7-3 WPS Setup - PIN If the wireless access point you wish to connect supports PIN, please follow the following instructions to establish connection to it: 1. Right-click the Edimax configuration utility icon located at lower-right corner of computer desktop and then click ‘Launch Config Utility’. 2. Click ‘WPS Configuration’ menu, and the following settings will appear. 3. The PIN code of your wireless network card is an eight-digit number located at the upper-right position of configuration utility.
4. Click ‘PIN’ button now, and wait for few seconds to one minute. If a wireless access point with correct PIN code is found, you’ll be connected to that access point. 5. You may have to click ‘PIN’ for few more times to try again. If you still can not connect to access point by this way, please make sure the PIN code you provided to access point is correct.
2-8 Radio On/Off You can switch the wireless radio transceiver on and off by the utility, so if you want to disable wireless network function, you don’t have to remove the network card physically. 1. Right-click the Edimax configuration utility icon located at lower-right corner of computer desktop and then click ‘Launch Config Utility’. 2. To switch wireless radio on/off, please click ‘Radio On/Off’ button.
2-9 About The ‘About’ tab provides you the information about version number of the configuration utility, driver, and other important information about your wireless network card. Please follow the following instructions to see these information: 1. Right-click the Edimax configuration utility icon located at lower-right corner of computer desktop and then click ‘Launch Config Utility’. 2. Click ‘About’ tab, and the following information will appear.
2-10 On-line Help If you need to know the directions of how to use specific function in the utility, please click ‘Help’ button. On-line help documents will be presented in Windows help format. Click this button to view on-line help documents.
CHAPTER III: Soft-AP Function Excepting become a wireless client of other wireless access points, this wireless card can act as a wireless service provider also! You can switch this wireless card’s operating mode to ‘AP’ mode to simulate the function of a real wireless access point by software, and all other computers and wireless devices can connect to your computer wirelessly, even share the internet connection you have! Please follow the instructions in following chapters to use the AP function of your w
A configuration window will appear after you switch the operation mode to ‘AP’, which asks you to assign an existing network card with internet connection. If your computer has another network card which is connected to Internet, please select it from ‘Name’ dropdown menu, and click ‘Enable ICS’; if your computer does not have another network card with Internet connection, please click ‘Not enable ICS’.
Here are descriptions of every setup item: Item Name Description SSID Please input the SSID (the name used to identify this wireless access point) here. Up to 32 numerical characters can be accepted here, excepting space. Channel Please select the wireless channel you wish to use. The number of channels available here will vary depends on the setting of ‘Country Region Code’. Wireless Mode Use Mac Address Security Setting Country Region Code Select the operation mode of the access point here.
0: FCC (US, Canada, and other countries uses FCC radio communication standards) 1: ETSI (Europe) 2: SPAIN 3: FRANCE 4: MKK 5: MKKI (TELEC) 6: ISERAL (Channel 3 to 9) 7: ISERAL (Channel 5 to 13) Please note that only change the country code if you are in different country. For example: when operating this product in US, only channels 1~11 can be operated. Selection of other channels is not permitted under FCC regulations.
3-2 Security Setting This wireless card supports wireless encryption in AP mode, which will encrypt the data being transferred over the air to enhance data security level. It’s recommended to enable data encryption unless you wish to open your computer (and its internet connection) to the public.
Here are descriptions of every setup item: Item Name Description Authentication Type Please select a wireless authentication type you wish to use. Available options are ‘Open’, ‘Shared’, WPA-PSK’, ‘WPA2-PSK’, and ‘WPA-PSK / WPA2-PSK’. If you want to disable wireless data encryption, you must select ‘Open’. Encryption Type Please select an encryption mode. The available options in this setting item will vary depending on the authentication type you select.
3-3 Access Control If you’re not going to open your computer and wireless resources to the public, you can use MAC address filtering function to enforce your access control policy, so only wireless clients with MAC address you defined by this function can be connected to your software access point.
Here are descriptions of every setup item: Item Name Description Select the policy type of your access rule. Disable: Allow any wireless client with proper authentication settings to connect to this access point. Access Policy Allow All: Only allow wireless clients with MAC address listed here to connect to this access point. Reject All: Reject wireless clients with MAC address listed here to be connected to this access point.
3-4 Connection Table If you want to see the list of all wireless clients connected to this access point, please select ‘Mac Table’ tab from the utility. Here are descriptions of every field: Item Name MAC Address AID Description Displays the MAC address of this wireless client. The serial number of this wireless connection. Power Saving Mode Displays the capability of power-saving function of this wireless client.
3-5 Event Log This software access point will log all wireless-related activities as a log. Click ‘Event Log’ tab, and the event log will be displayed. You can click ‘Clear’ to remove all entries in the log.
3-6 Statistics If you want to know detailed information about how your software access point works, click ‘Statistics’ tab, and the event log will be displayed. You can click ‘RESET COUNTERS’ button to reset all counters to zero.
3-7 About The ‘About’ tab provides you the information about version number of the configuration utility, driver, and other important information about your wireless access point.
4-1 Specification Standards: IEEE 802.11b/g Interface: USB 2.0 (USB 1.1 Compatible) Frequency Band: 2.4000 ~ 2.4835GHz (Industrial Scientific Medical Band) Data Rate: 11b: 1/2/5.
4-2 Troubleshooting If you encounter any problem when you’re using this wireless network card, don’t panic! Before you call your dealer of purchase for help, please check this troubleshooting table, the solution of your problem could be very simple, and you can solve the problem by yourself! Scenario I can’t find any wireless access point / wireless device in ‘Site Survey’ function. Solution 1. Click ‘Rescan’ for few more times and see if you can find any wireless access point or wireless device. 2.
list. The network is slow / having problem when transferring large files 1. Move closer to the place where access point is located. 2. Disable ‘Tx Burst’ in ‘Advanced’ tab. 3. Enable ‘WMM’ in ‘QoS’ tab if you need to use multimedia / telephony related applications. 4. Disable ‘WMM – Power Save Enable’ in ‘QoS’ tab. 5. There could be too much people using the same radio channel. Ask the owner of the access point to change the channel number. Please try one or more solutions listed above.
4-3 Glossary 1. What is the IEEE 802.11g standard? 802.11g is the new IEEE standard for high-speed wireless LAN communications that provides for up to 54 Mbps data rate in the 2.4 GHz band. 802.11g is quickly becoming the next mainstream wireless LAN technology for the home, office and public networks. 802.11g defines the use of the same OFDM modulation technique specified in IEEE 802.11a for the 5 GHz frequency band and applies it in the same 2.4 GHz frequency band as IEEE 802.11b. The 802.
What does IEEE 802.11 feature support? The product supports the following IEEE 802.11 functions: z CSMA/CA plus Acknowledge Protocol z Multi-Channel Roaming z Automatic Rate Selection z RTS/CTS Feature z Fragmentation z Power Management 3. What is Ad-hoc? An Ad-hoc integrated wireless LAN is a group of computers, each has a Wireless LAN card, Connected as an independent wireless LAN. Ad hoc wireless LAN is applicable at a departmental scale for a branch or SOHO operation. 4.
7. What is TKIP? TKIP is a quick-fix method to quickly overcome the inherent weaknesses in WEP security, especially the reuse of encryption keys. TKIP is involved in the IEEE 802.11i WLAN security standard, and the specification might be officially released by early 2003. 8.
11. What is DSSS? What is FHSS? And what are their differences? Frequency-hopping spread-spectrum (FHSS) uses a narrowband carrier that changes frequency in a pattern that is known to both transmitter and receiver. Properly synchronized, the net effect is to maintain a single logical channel. To an unintended receiver, FHSS appears to be short-duration impulse noise. Direct-sequence spread-spectrum (DSSS) generates a redundant bit pattern for each bit to be transmitted.
13. What is WMM? Wi-Fi Multimedia (WMM), a group of features for wireless networks that improve the user experience for audio, video and voice applications. WMM is based on a subset of the IEEE 802.11e WLAN QoS draft standard. WMM adds prioritized capabilities to Wi-Fi networks and optimizes their performance when multiple concurring applications, each with different latency and throughput requirements, compete for network resources.
15. What is GI? GI stands for Guard Interval. It’s a measure to protect wireless devices from cross- interference. If there are two wireless devices using the same or near channel, and they are close enough, radio interference will occur and reduce the radio resource usability. 16. What is STBC? STBC stands for Space-Time Block Coding, which is a technique used to transfer multiple copies of data by multiple antenna, to improve data transfer performance.
4-4 FCC and CE Compliance Statements Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Federal Communication Commission (FCC) Radiation Exposure Statement This equipment complies with FCC radiation exposure set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna shall not be less than 20cm (8 inches) during normal operation. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
R&TTE Compliance Statement This equipment complies with all the requirements of DIRECTIVE 1999/5/EC OF THE EUROPEAN PARLIAMENT AND THE COUNCIL of March 9, 1999 on radio equipment and telecommunication terminal Equipment and the mutual recognition of their conformity (R&TTE) The R&TTE Directive repeals and replaces in the directive 98/13/EEC (Telecommunications Terminal Equipment and Satellite Earth Station Equipment) As of April 8, 2000.
