Series 8700 / 8800 Unitized Curtain Wall Assembly Instructions - Volume 1
Section 2 - Parts Identification : D. Frame Extrusions - 8" System
Profile
Part #
Description
Tooling/Cut Length Formula
Frame Extrusions - 8" System
17G6
8" CAPTURED AND SSG VERTICAL
MULLION
U17G6-001, U17G6-002, U17G6-003,
U17G6-004, U17G6-005, U17G6-006,
U17G6-007, U17G6-008, U17G6-009,
U17G6-010, U17G6-011, U17G6-012,
U17G6-013
17G7
8" CAPTURED AND SSG VERTICAL
MULLION
U17G7-001, U17G7-002, U17G7-003,
U17G7-004, U17G7-005, U17G7-006,
U17G7-007, U17G7-008, U17G7-009,
U17G7-010, U17G7-011, U17G7-012,
U17G7-013
17G8
8" OPTIONAL CAPTURED AND SSG
VERTICAL MULLION
U17G8-001, U17G8-002, U17G8-003,
U17G8-004, U17G8-006, U17G8-007,
U17G8-008, U17G8-009, U17G8-010,
U17G8-012
17G9
8" OPTIONAL CAPTURED AND SSG
VERTICAL MULLION
U17G9-001, U17G9-002, U17G9-003,
U17G9-004, U17G9-006, U17G9-007,
U17G9-008, U17G9-009, U17G9-010,
U17G-012
17H1
8" CAPTURED AND SSG HORIZONTAL
STACK HEAD
CUT TO LENGTH (D.L.O.) AT
TYPICAL FLAT UNITS
17H2
8" CAPTURED AND SSG
INTERMEDIATE HORIZONTAL
CUT TO LENGTH (D.L.O.) AT
TYPICAL FLAT UNITS
