Series 5500 Silicone structural glazed curtain wall Installation Instructions Part NO.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions TABLE OF CONTENTS S-5500 SSG SCREW SPLINE CURTAIN WALL SECTION PAGE I. General Notes and Guidelines…………………………………………. 3-4 II. Frame Unit Assembly & Frame Sealing……………………………. 5-16 III. Typical Anchorage Methods…………………………………………...17-25 IV. Glazing Preparation………………………………………………………..26-32 V. Glazing Installation…………………………………………………………33-34 VI.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section I: General Notes and Guidelines I. II. HANDLING / STORING / PROTECTING ALUMINUM - The following precautions are recommended to assure early acceptance of your products and workmanship. A. HANDLE CAREFULLY - Store with adequate separation between components so the material will not rub together. Store the material off the ground. Protect materials against weather elements and other construction trades. B.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions SECTION I: GENERAL NOTES and GUIDELINES F. Follow EFCO framing installation and glazing instructions. G. Verify contents of all material shipments received upon their arrival. Verify quantity and correct finishes. NOTIFY EFCO IMMEDIATELY OF ANY DISCREPANCIES OR DAMAGE THAT MAY HAVE OCCURRED. H. Throughout these instructions the term “SEALANT” will appear.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section II: Frame Unit Assembly & Frame Sealing STEP #1 ASSEMBLE OUTSIDE GLAZED FRAME MEMBERS JAMB FILLER Note: Sealant or gasket must be applied to the ends of each horizontal member before assembly. (See enlargement pages 6-14.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section II: Frame Unit Assembly & Frame Sealing STEP #2 SEAL EXTERIOR REVEAL TUBES A. Plug the ends of the exterior portion of the SSG heads and sills with backer rod. Recess the backer rod at least 1/4” from each end of the reveal tube. B. Apply a generous amount of sealant to cover the hollow portion of the tube as shown below on each end. Apply sealant to each end of the horizontal as shown on page 7.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section II: Frame Unit Assembly & Frame Sealing Apply a generous bead of sealant to the ends of the horizontal mullion to a minimum of 1” back from the face of the horizontal glazing pocket. SSG HEAD & SILL HORIZONTALS WITH REVEAL AT SSG REVEAL JAMBS EFCO CORPORATION 6/2012 PART NO.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section II: Frame Unit Assembly & Frame Sealing Apply a generous bed of sealant to the sides of the vertical mullion where it comes into contact with the head and sill. Note: Tool the sealant smooth on each end of the reveal tube. Immediately clean excess sealant from the frame, or after the sealant partially cures, use a blade to cut the excess sealant flush with the surfaces of the reveals.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section II: Frame Unit Assembly & Frame Sealing Note: Refer to the tooling drawings for the fabrication requirements of the horizontals. Apply a generous bead of sealant to the ends of the horizontal mullion to a minimum of 1” back from the face of the horizontal glazing pocket. Force a heavy bead of sealant between the struts at the glazing pocket.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section II: Frame Unit Assembly & Frame Sealing Apply a generous bead of sealant to the sides of the vertical mullion where it comes in contact with the O. G. horizontal. Work the sealant into the joints filling all the voids, and tool the sealant smooth. Make sure the sealant is cleared from the grooved area in the front of the horizontal where the cover will be engaged.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section II: Frame Unit Assembly & Frame Sealing Note: Refer to the tooling drawings for the fabrication requirements of the horizontals. Apply a generous bead of sealant to the ends of the horizontal mullion to a minimum of 1” back from the face of the horizontal glazing pocket. Seal the void between the struts as shown on page 9. Work the sealant into the joints, and tool the sealant smooth.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section II: Frame Unit Assembly & Frame Sealing Apply H10Z Gasket to each end of the Horizontal. Trim excess gasket after assembly. OR Apply a generous bead of sealant to the ends of the horizontal mullions to a minimum of 1” back from the face of the horizontal glazing pocket. SSG INTERMEDIATE HORIZONTALS AT SSG REVEAL JAMBS Apply H10Z Gasket to each end of the Horizontal. Trim excess gasket after assembly.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section II: Frame Unit Assembly & Frame Sealing Apply backer rod and sealant to the ends of the horizontal mullions as shown on pages 6 and 7. Note: Refer to the tooling drawings for the fabrication requirements of the horizontals. Work the sealant into the joints, and tool the sealant smooth. SSG SILL HORIZONTALS WITH REVEAL AT SSG VERTICAL MULLIONS (HEAD SIMILAR) EFCO CORPORATION 6/2012 PART NO.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section II: Frame Unit Assembly & Frame Sealing Apply H10Z Gasket to each end of the Horizontal. Trim excess gasket after assembly. OR Apply a generous bead of sealant to the ends of the horizontal mullions to a minimum of 1” back from the face of the horizontal glazing pocket. CAPTURED SILL HORIZONTALS AT CAPTURED VERTICALS Apply H10Z Gasket to each end of the Horizontal. Trim excess gasket after assembly.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section II: Frame Unit Assembly & Frame Sealing STEP #3 INSTALL FRAME COMPONENTS A. Snap-in PVC pocket fillers into the optional captured perimeter framing members, if required. B. Plug the ends of the exterior portion of the vertical mullions with backer rod. Recess the backer rod at least 1/4” from each end, and apply a generous amount of sealant to cover the ends of the mullions.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section II: Frame Unit Assembly & Frame Sealing Apply backer rod and seal the ends of the mullions as shown including the glazing reglets. (At the top and bottom of mullions.) SSG HEAD WITH REVEAL SSG JAMB MULLION WITH REVEAL OPTIONAL CAPTURED VERTICAL EFCO CORPORATION 6/2012 PART NO.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section III: Typical Anchorage Methods STEP #1 INSTALL FRAME COMPONENTS A. Refer to the approved shop drawings for job specific conditions, anchor type, anchor bolt sizes, and locations. Install assemblies according to approved shop drawings. The anchor type used must be selected based on the structural requirements and the substrate.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section III: Typical Anchorage Methods STEP #2 INSTALL FRAME COMPONENTS A. Set the first frame into the opening using dead load shims to level the frame, and make all necessary adjustments to properly locate the frame to established benchmarks. B. After the frame is plumb and all adjustments have been made, match drill through the holes in the head and sill into the surrounding substrate, and apply the anchor bolts.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section III: Typical Anchorage Methods ANCHOR BOLTS WITH SLEEVES AS REQ’D. STANDARD HEAD ANCHORAGE ANCHOR BOLTS AS REQ’D. Apply dead load shims at anchors and below verticals. STANDARD SILL ANCHORAGE EFCO CORPORATION 6/2012 PART NO.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section III: Typical Anchorage Methods STEP #4 SPECIAL SEALANT NOTE A. Seal the vertical fillers at the intersection of the heads, sills, and intermediate horizontals immediately before snapping the filler and the vertical mullions together. B. Tool the sealant smooth with the face of the glazing pocket and remove excess sealant from the glazing reglets.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section III: Typical Anchorage Methods STEP #3 INSTALL FRAME COMPONENTS A. Repeating step 2, page 18, set each successive frame into the opening, snapping the verticals and fillers at each frame, until all frames are installed up to the last frame at the opposite jamb. B. Check frequently to ensure the installed framing is in the proper position with regard to established benchmarks. C.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section III: Typical Anchorage Methods STEP #5 INSTALL FRAME COMPONENTS A. Set the last frame in the run into the opening mating the filler with the intermediate vertical until the filler and vertical snap together. B. When the frame is set level and plumb, apply the dead load shims below the verticals, and apply anchors as shown in Step 2 (B), pages 18 and 19. C Snap-in the sill fillers. D.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section III: Typical Anchorage Methods STEP #6 INSTALL FRAME COMPONENTS – BOLTED DEAD LOAD ANCHORS For installations with multi-spans, follow applicable notes from Step 6. When the frame is properly aligned and is level and plumb, match drill the slab through the anchor and install anchor bolts securing the anchor to the building structure. Match drill the mullion through the set of holes in the anchor.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section III: Typical Anchorage Methods BUILDING STRUCTURE Bolt anchor to building structure per approved shop drawings. STEEL ANCHOR PER SHOP DRAWINGS NOTE: The elevation of the structure must be within the adjustment limits of the anchoring system. See approved shop drawings for limitations. BOLTED DEAD LOAD ANCHORS EFCO CORPORATION 6/2012 PART NO.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section III: Typical Anchorage Methods STEP #7 INSTALL FRAME COMPONENTS – WELDED WIND LOAD ANCHORS For installations with multi-spans, follow applicable notes from Step 8. Match drill the mullion through the CENTER of the set of slots in the anchor. NOTE: The holes must be a minimum of 1” from the back of the mullion in order to clear any steel reinforcement located inside the system as may be required on a job specific basis.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section IV: Glazing Preparation STEP #1 PREPARE FRAME FOR GLAZING A. Seal the frame joints at the SSG vertical and perimeter SSG horizontal intersections. Seal the 1/4” joint at the reveal at the head and sill. The joint must be sealed from the top all the way around to the bottom of the reveal, completely filling the joint void. B. Tool off excess sealant from the exposed areas.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section IV: Glazing Preparation STEP #2 PREPARE FRAME FOR GLAZING A. Seal the frame joints at the SSG vertical and captured horizontal intersections. Seal the 1/4” joint at the glazing pocket. The joint must be sealed from the top all the way around to the bottom of the glazing pocket, completely filling the joint void. B.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section IV: Glazing Preparation STEP #3 PREPARE FRAME FOR GLAZING A. Seal the frame joints at the SSG vertical and captured head and sill intersections. Seal the 1/4” joint at the glazing pocket. The joint must be sealed from the top all the way around to the bottom of the glazing pocket, completely filling the joint void. B.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section IV: Glazing Preparation STEP #1 PREPARE FRAME FOR JOINT PLUGS In some instances, projects will require captured and SSG mullions used in combination within the same elevation. Use the following steps as a guide in these situations. A. Fill the gasket and adapter raceways with sealant to close off the void at the joint plug locations. The sealant height should be a minimum of 1” long. B.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section IV: Glazing Preparation STEP #2 INSTALL JOINT PLUGS A. Apply sealant to the contact surfaces of the joint plug as shown. B. Install the mullion joint plugs at the horizontal to vertical intersections as indicated. C. Tool the sealant that was pre-applied to the mullion in Step 4, over the joint plugs and into the joints.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section IV: Glazing Preparation STEP STEP#3 #6INSTALL SEAL JOINT JOINT PLUGS PLUGS (CONTINUED) A. After installation of the joint plugs, reseal the joint connecting the surfaces of the horizontal and vertical mullions with sealant over the joint plug as shown below. B. Provide a downward slope with the sealant, without interfering with the edge of the glass once the glass is set, to allow for drainage of water.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section V: Glazing Installation IMPORTANT NOTE: EFCO recommends using conventional tubular spacers only for insulated glass units with the S-5500. This is due to the possible collapse of the spacer when used with drive-in wedge glazing gaskets. STEP #1 INSTALL GLAZING MATERIALS A. Using suction cups, gently insert a glass edge (or other glazing infill) into the deep pocket of the vertical mullion. B.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section V: Glazing Installation STEP #3 INSTALL ANTI-WALK BLOCKS A. Stretch the anti-walk blocks until they are elongated enough to fit between the glass face and the front face of the glazing pocket. B. Install and position anti-walk blocks in the verticals at the center of each D.L.O.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section VI: Exterior Cover & Drive-In Gasket Installation STEP #1 INSTALL DRIVE-IN GASKETS IN VERTICAL MULLIONS A. Remove the exterior drive-in wedge gasket material from the reel, and allow the gasket to relax and shrink. B. Remove any temporary retainer gaskets previously applied, from the opening at hand. C. The exterior vertical gaskets must be cut vertical D.L.O. plus 1 3/4”.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section VI: Exterior Cover & Drive-In Gasket Installation STEP #2 (Option A) APPLY HORIZONTAL 2 PIECE PRESSURE PLATE AND COVERS Seal horizontal to vertical connection before installing the cover. Run a continuous bead of sealant across the front of the head and sill members prior to installing cover. Note: This seal is not required at the Intermediate Horizontal locations. EFCO CORPORATION 6/2012 PART NO.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section VI: Exterior Cover & Drive-In Gasket Installation STEP #2 (Option A) APPLY HORIZONTAL 2 PIECE PRESSURE PLATE AND COVERS Install Pressure Plate, apply and tool sealant to the horizontal to vertical connection. Install Pressure Plate Cover See page 40 for gasket installation EFCO CORPORATION 6/2012 PART NO.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section VI: Exterior Cover & Drive-In Gasket Installation STEP #2 (Option B) APPLY HORIZONTAL PRESSURE COVERS A. Plug the ends of the horizontal pressure covers including heads, intermediates, and sills with backer rod. Recess the backer rod at least 1/4” from each end, and apply a generous amount of sealant to cover the ends of the covers. B.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section VI: Exterior Cover & Drive-In Gasket Installation STEP #2 (Option B) APPLY HORIZONTAL PRESSURE COVERS C. Apply a bed of sealant to the side of the vertical cover adjacent to where the ends of the horizontal pressure covers will be after installation. The sealant bed should be approximately 2 1/4” high x 1/16” thick and the depth of the vertical cover.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section VI: Exterior Cover & Drive-In Gasket Installation STEP #2 (Option B) APPLY HORIZONTAL PRESSURE COVERS D. Run a continuous bead of sealant in the reglet of the Head and Sill immediately before applying the exterior pressure cover as shown below. Do not block weeps with sealant. (See inset below). E. Slide on and rotate the pressure covers as shown to engage the horizontal cam.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section VI: Exterior Cover & Drive-In Gasket Installation STEP #3 INSTALL DRIVE-IN GASKETS IN HORIZONTAL MULLIONS A. Apply sealant to the vertical gaskets where they will contact the horizontal gaskets on each end behind the pressure covers as shown below. B. Cut the horizontal gaskets D.L.O. plus 1/2”, and insert the gasket in place starting at the center of the D.L.O. Crowd in the excess at the ends.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section VII: Door Framing Installation & Anchorage STEP #1 INSTALL ADJACENT FRAME The following example depicts a typical S-5500 elevation with door framing. The following illustrations show the anchoring of the frame assemblies utilizing the standard method for anchoring of the S-5500.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section VII: Door Framing Installation & Anchorage ANCHORED AS REQUIRED DOOR JAMB ANCHORED AS REQUIRED EFCO CORPORATION 6/2012 PART NO.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section VII: Door Framing Installation & Anchorage STEP #2 ANCHOR FIRST DOOR JAMB The frame directly adjacent to the door opening will have the first door jamb. This jamb is 3/4” longer than the typical mullions and extends below the sill down to the top of the floor slab. To maintain Exterior sealant line, apply silicone to the interior surfaces of the door jamb and tool to the condition.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section VII: Door Framing Installation & Anchorage DOOR JAMB ANCHOR BOLTS AS REQUIRED EFCO CORPORATION 6/2012 ANCHOR CLIP PART NO.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section VII: Door Framing Installation & Anchorage STEP #3 SET DOOR FRAME A. Carefully position the door frame into opening. Extreme care should be taken to protect the filler part of the frame during shipment and handling. Damage to the edges of the filler will be noticeable after it is snapped into the door jamb. B.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section VII: Door Framing Installation & Anchorage STEP #4 ANCHOR DOOR FRAME A. After the frame is set level and plumb, anchor the head of the elevation as required. Refer to previous sections for more information. DOOR JAMB ANCHOR CLIP EFCO CORPORATION 6/2012 PART NO.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section VII: Door Framing Installation & Anchorage STEP #5 ANCHOR DOOR JAMB A. To maintain Exterior sealant line, apply silicone to the interior surfaces of the door jamb and tool to the condition. B. Ensure the clip is flush with the bottom of the mullion and the top of the condition. Attach the anchor clip to the door jamb with screws as shown. C. Drill anchor bolt holes through the clip and into the substrate as required. D.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section VII: Door Framing Installation & Anchorage STEP #6 INSTALL REMAINING FRAMES AND GLAZE CURTAIN WALL A. Set and install the remaining frames as required and instructed in previous sections. B. Prepare and glaze the elevation as shown in Section IV, Section V, and Section VI. EFCO CORPORATION 6/2012 PART NO.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section VII: Door Framing Installation & Anchorage STEP #7 INSTALL VERTICAL SUBFRAMES A. Apply sealant into the glazing gasket reglets of the exterior covers of the door jambs and door header as shown. B. The vertical subframes are cut to run from the condition at the sill through to the bottom of the door header with the head subframe running in between. Apply sealant to each end of the subframe.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section VII: Door Framing Installation & Anchorage STEP #8 INSTALL DOOR HEAD SUBFRAME Unless a concealed overhead closer is used, a subframe will be required at the door head. See the detail below for the optional door header for concealed overhead closer applications. A. The subframe at the door head is cut to run between the vertical subframes. Apply sealant to each end of the subframe.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section VII: Door Framing Installation & Anchorage STEP #9 INSTALL DOOR STOPS A. First, install the door stop at the head. This stop is cut the same length as the door head subframe. B. The vertical door stops are cut to run from the condition at the sill, to the bottom of the door head subframe. The tops of the stops are notched as shown in the drawing inset.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section VIII: Reinforcing STEP #1 INSTALL STEEL REINFORCEMENT At large span or high wind load areas, steel reinforcement may be necessary. Reinforcement requirements will vary from project to project. Refer to the approved shop drawings for reinforcement requirements. A. Slide steel reinforcement in from the end of the mullion.
Series 5500 Silicone Structural Glazed Curtain Wall Installation Instructions Section XI: Perimeter Caulking STEP #1 PREPARE JOINT FOR CAULK APPLICATION A. Perimeter caulk joint application should not begin until the curtain wall elevation has been completely erected and glazed. B. Clean and prime the perimeter caulk joint opening as recommended by the sealant manufacturer’s installation instructions. C. Use the appropriate sized backer rod for the desired caulk joint.
