Product Sheet

The Einhell TC-LW 2000 hand lever winch is suitable for pulling and tensioning loads with a maximum tensile load of 2,000 kg and a maximum useable
distance of 1.6 meters. The product is supplied with a 3.3 meter twist-free wire cable (Ø 6 mm) and a guide roller with load hook which has a retention
latch. The retention latch prevents the load from being unhooked accidentally. An automatic brake secures the load in every position. There is a safety
clip to prevent a complete unrolling of the cable. The winch comes with a tensioning spring for releasing the retaining catch easily. The hand lever
winch is not suitable for lifting and lowering loads.
Hand Lever Winch
TC-LW 2000
Item No.: 2260150
Ident No.: 11018
Bar Code: 4006825643244
Features & Benefits
3.3 m twist-free wire cable (Ø 6 mm)-
Incl. guide roller with load hook & retention latch-
Retention latch prevents the load being unhooked accidentally-
An automatic brake secures the load in every position-
Tensioning spring for releasing the retaining catch easily-
Suitable for pulling and tensioning loads-
Not suitable for lifting and lowering loads-
The max. payload with guide roller is 2000kg-
Safety clip prevents complete unrolling of the cable-
Technical Data
- Max. useable distance 1.6 m
- Steel cable diameter 6 mm
- Steel cable length 3.3 m
- Automatic brake yes
- Max. payload with guide roller 2000 kg
Logistic Data
- Product weight (kg) 5.21
- Gross weight (kg) 5.53
- Dimensions single packaging 141 x 98 x 675 mm
- Pieces per export carton 4 Pieces
- Gross weight of export carton 22 kg
- Dimensions export carton 705 x 215 x 290 mm
- Container quantity (20"/40"/40"HC) 1920 | 3840
Illustrations can contain accessories, which are not included in standard extent of delivery
Illustration similar (in design), production-wise modifications reserved
GS mark belongs to the product itself only, excluded accessory
