- For Administrator For Microsoft Windows CE.NET Version F Please confirm the version of the software built in eClient, and refer to the suited User's Manual (Refer to the User's Manual Version List on next page). This is the manual for the following software version. * Microsoft Windows CE: 4.10 Rev. 2.7.2 or later * Microsoft Terminal Server Client: Ver. 7.3.0 or later * ICA Client: Ver. 7.
User’s Manual Version List A handling description changes with versions of the software built in eClient. Please refer to below. NOTE • The version of software built in eClient can be checked with a [System]-[ICA] tab of [Terminal Properties]. OS: Microsoft Windows CE .NET Software Microsoft Windows CE Microsoft Windows Terminal Server ICA Client Software F (This Manual) 4.10 Rev.2.7.2 or later Version 7.3.0 or later Version 7.23 or later E 4.10 Rev.2.7.1 or later Version 7.2.
SAFETY SYMBOLS This manual uses the safety symbols below. They denote critical information. Please read them carefully. WARNING Failure to abide by the information in a WARNING may result in serious injury and can be life threatening. CAUTION Failure to abide by the information in a CAUTION may result in moderate injury and/or property or product damage. Indicates a prohibited action. Indicates to ground for safety. Copyright© 2003-2004 EIZO NANAO CORPORATION. All rights reserved.
TABLE OF CONTENTS 1. INTRODUCTION ..................................................................................... 5 1-1. General Description ......................................................................................5 1-2. Features ........................................................................................................5 1-3. Package Contents..........................................................................................6 1-4. Controls & Connectors .................
1. INTRODUCTION Thank you very much for purchasing the EIZO eClient 630L/630L-N. 1-1. General Description The eClient 630L/630L-N connects with a Windows Terminal Server*, which installed Microsoft Windows NT Server 4.0 Terminal Server Edition or Windows 2000 Server/Advanced Server/Datacenter Server, and this product is used as a terminal using them.
1-3. Package Contents Please make sure that all the items listed are in the package. Please contact your local dealer for assistance if any of the listed items are missing or damaged. • eClient 630L/630L-N • Mouse (FDM-310) • Power Cord • Screw (M4 x 12 mm) x 4 • User’s Manual (includes Limited Warranty) • 2 Stickers of the Brightness Control Guide NOTE • A keyboard is not included. Please purchase it separately. Please use the enclosed mouse.
1-4. Controls & Connectors Front (1) (2) (1) (2) (3) (4) Power button Power Indicator Color Green 630L/630L-N status • Operation • Screen saver mode Yellow Off (3) (4) Power save mode • Power off (Wake on LAN standby) Speakers Volume Control NOTE • When turning off/on the unit, leave the unit off for a few seconds before turning it on again. 1.
Rear (16) (17) (14) (15) (13) (6) (8) (10) (12) (5) (7) (9) (11) (5) (6) (7) (8) (9) (10) (11) (12) (13) (14) (15) (16) (17) *1 *2 8 Mouse Connector Keyboard Connector Serial Port (RS-232C) Parallel Connector Power Connector Ethernet Connector (10 Base-T, 100 Base-TX) Headphone Connector Microphone Connector USB Port (Downstream) x 2 PC Card Slot Security Lock*1 Holes for Mounting an Arm Stand*2 Stand (Detachable) This allows for connection of a security cable.
2. CONNECTING THE eClient 630L/630L-N This chapter explains how to connect the eClient 630L/630L-N to a WTS. 2-1. Setting up the eClient 630L/630L-N Please observe the following cautions when connecting the 630L/630L-N. WARNING Place the eClient 630L/630L-N on a strong, stable surface. A unit placed on an inadequate surface may fall, resulting in injury or equipment damage. If the unit falls, disconnect the power immediately and have the unit checked by a qualified service engineer before using it again.
1. In case of connecting the WTS through LAN: Connect the eClient 630L/630L-N to the network with an Ethernet cable. In case of a dial-up or dial-in connection: Connect the eClient 630L/630L-N to a modem or a modem card. NOTE • Please remove the lid on the side of the 630L/630L-N before connecting a LAN card or a modem card. 2. Plug a keyboard and a mouse into the eClient 630L/630L-N. If using other devices, please connect them to the appropriate connectors. 3.
3. SETTING UP the eClient 630L/630L-N This chapter presents how to prepare for a connection with a WTS when the eClient 630L/630L-N starts up for the first time. 1. Turn on the eClient 630L/630L-N. The power indicator turns green and a picture appears on the screen. NOTE • When no picture is displayed, or when the message (No keyboard connected. / No mouse connected.) is shown on the screen, please refer to “8. Troubleshooting” on page 59. 2. “eClient Setup Wizard” is displayed.
3. End User License Agreement page is displayed. Read the content and click [Accept] to continue. 12 3.
4. Set up the network environment. [Terminal Name] ................Type the name to identify this unit on the network. Click [Network Properties] and set up connection information according to the connection method to WTS/Web server. Connection method Reference page • In case of connecting the WTS/Web through Built-in p.14 LAN • In case of connecting with a NE2000 compatible LAN p.14 card: • In case of connecting with a Cisco wireless LAN card/ p.
Example; In case of connecting with a NE2000 compatible LAN card In case of connecting the WTS/Web through Built-in LAN: (1) Double-click [Built-in LAN] icon. [IP Address] ........................Type the IP address of the unit. [Name Servers]....................Type the IP address of each server when DNS or WINS is used. [Advanced]..........................Type the transmission speed and MAC Address of a network. In case of connecting with a NE2000 compatible LAN card: (1) Double-click [NE 20001] icon.
In case of connecting with a Cisco wireless LAN card/Agere wireless LAN card: (1) Double-click [CISCO1]/[WLAGS461] icon. [IP Address] ........................Type the IP address of the unit. [Name Servers] ...................Type the IP address of each server when DNS or WINS is used. [Wireless Networks] ...................................Set the connection setting with a wireless LAN card. NOTE • In case of selecting [Obtain an IP address via DHCP], deactivate the built-in LAN by the procedure below.
In case of a dial-up connection: (1) Double-click [Make New Connection] icon. (2) Type a name for the connection and select the connection type (Dial-Up Connection). (3) Select a model, set up the TCP/IP settings and Security settings. (4) Type the phone number for the connection. (5) In case of a dial-up connection, the information of local location needs to be set up. Set up the information in the later procedure 8.
5. Set up the desktop area. [Desktop Area and Refresh Frequency] ...................................Set the resolution/refresh rate. (630L/630L-N supports 1024 x 768 @60 Hz only). [Desktop Colors] ................Set the desktop color (256 Colors / High color) of the following. - Windows CE desktop (before WTS connection) - Windows desktop (after a WTS connection with RDP protocol) NOTE • [High Color] setting after WTS connection can be available only when connecting with WTS, which version is 5.
6. Set up the browser connection. Set up if you are setting up a web browser connection. (1) Select [Internet Options] icon and click [Open]. [General].............................Set up the browser. [Connection] .......................Set up the connection method to the browser. [Security].............................Set up the security for the connection to the browser. [Advanced]..........................Set up the display method of the browser. 7. Set up the printer.
8. Setup the Local sender’s setting Setup if you are connecting to WTS/Web server by dial-up connection. (1) Select [Dialing] icon and click [Open] icon. [Location name]..................Choose the sender’s location (click [New] to add a new sender’s location). [Local Settings are:] ............Setup the local settings. 9. The last page of the “eClient Setup Wizard” is displayed. Click [Finish]. Click [Yes] if a “Terminal Settings change” dialog box is displayed.
4. ADDING & CHANGING A CONNECTION NAME This chapter shows how to add, delete, and modify connection names to a WTS. All the settings are managed in the “Terminal Connection Manager”. 4-1. Adding a Connection Name These are settings for the server connection. Each protocol has different settings. Please install the appropriate settings.
In Use of RDP Protocol 1. Display [Terminal Connection Manager]. Click the [Configure] tab and [Add...] to set the connection information of the WTS. 2. Protocol selection dialog box is displayed. Select the “Microsoft Remote Desktop Client” (RDP). 3. “WTS Connection Wizard” is displayed. (Setup as following the wizard.) (1) Type the connection name and the name of the Server. (2) Setup to enable an Automatic Logon to the WTS after connecting if you want.
In Use of the ICA protocol 1. Display [Terminal Connection Manager]. Click the [Configure] tab and [Add...] to set the connection information of the WTS. 2. “New Connection” dialog box is displayed on the screen. Select the “Citrix ICA Client” (ICA). 3. “Specify Connection Type” is displayed. (Setup as following the wizard.) (1) Choose a connection type (Network Connection / Dial-In) for the remote application. (2) Setup a server or modem according to a connection type.
Clicking [Finish] to return to the “Terminal Connection Manager” dialog box, the registered connection name is displayed in the [Connection Name]. NOTE • Please repeat the step 2 to 3 when you adding another connection name. 4-2. Setting an Autostart Connection This function configures a connection to start automatically each time the eClient 630L/630L-N is turned on. (This function is available for a LAN connection.) Select the desired connection name for Autostart Connection and click [Startup...].
5. LOGON & LOGOFF This chapter shows how to log on to and log off from a WTS. 5-1. Logon to a WTS / Logoff from a WTS Logon to a WTS 1. Follow the direction from (1) to (3), depending on the environment of the eClient 630L/630L-N. (1) To connect and log on to a WTS through local network: Go to step 2. (2) To connect and log on to a WTS with dial-up connection: Click an active button of a small window on the right bottom of the screen. Clicking the button makes a dial-up connection.
Multi Session You can log on to the WTS with the several connection names, and switch the active sessions. 1. Logon with a Connection Name, as following the previous steps. 2. Press [Ctrl] + [Alt] + [End] keys after logon. 3. “Terminal Connection Manager” is displayed. Select another Connection Name to log on to, and click [Connect]. (Or double click the connection name.) Repeat the step 2 to 3 to log on to another connection name.
Logoff from the WTS If your eClient 630L/630L-N starts its operation with a desktop 1. Logoff from the WTS. (1) Close all applications. (2) Select [Start] on the taskbar. (3) Microsoft Windows NT Server 4.0 Terminal Server Edition: Select [Logoff]. Microsoft Windows 2000 Server / Advanced Server / Datacenter Server: Select [Shut Down...] and select [Logoff] of the [Shut Down Windows] dialog box. (4) Click [OK] on the Logoff Window. The session ends and automatically logs off from the WTS.
If your eClient 630L/630L-N starts its operation with an application 1. Log off from the WTS. Close applications to log off from the WTS. “Terminal Connection Manager” is displayed. If a dial-up connection is running, click the active button of the window on the right bottom of the screen. Clicking the button disconnects the dial-up connection. 2. Shut down the eClient 630L/630L-N. (Please refer to the previous page for shutting down the eClient 630L/630L-N.
5-2. Opening/Closing a Local Web Browser Opening a Local Web Browser 1. Please follow the directions relevant on the environment of the eClient 630L/630L-N. (1) If the web server is on the same network (Intranet): Go to step 2. (2) If the web server is not on the same network, and a dial-up connection is needed (Internet): Click an active button of a small window on the right bottom of the screen. Clicking the button makes a dial-up connection. Check the clock’s running, and go to step 2. 2.
Closing a Local Web Browser 1. Close the local web browser. Select [Close] under the [File] on the menu bar and close the local web browser. Return to the “Terminal Connection Manager” dialog box. If a dial-up connection is being made, click the active button of the window on the right of the screen. Clicking the button disconnects the dial-up connection. 2. Shut down the eClient 630L/630L-N. There are three ways to shut down the unit.
6. USING THE TERMINAL PROPERTIES This chapter presents how to modify all settings of the eClient 630L/630L-N using the “Terminal Properties”. To display the “Terminal Properties” during logging on, press F2 in the “Terminal Connection Manager” dialog box. 30 6.
Settings and adjustments of “Terminal Properties” Tab name Contents Remarks General Product information, Terminal Name Reset Reset the terminal to factory-default settings Local Resources*1 Remote computer sound Sound output after WTS connection Local devices Local devices reference after WTS connection Desktop Area and Refresh Frequency Resolution and refresh rate of Desktop Area Display Display the Product information Refer to p.32 p.33 p.
6-1. General Product Information [General] tab shows the product name, Product ID, Windows CE Revision, version, and Terminal name. Resetting to Default (1) Select the [Reset the terminal to factory-default property settings] check box. (2) The “System Settings Change” dialog box is displayed, click [Yes]. (3) “Terminal Properties” is displayed. Click [OK]. Confirmation window is displayed, click [Yes] to restart the terminal. “eClient Setup Wizard” will be displayed after restarting the terminal. 32 6.
6-2. Local Resources (RDP protocol only) Sound settings [Remote computer sound]...Sound settings after WTS connection (Remote computer means WTS). Device settings [Local devices] ....................Select the applicable device check box when using the device connected from the WTS after WTS connection. NOTE • Sound settings and [Disk drives], [Serial ports] of Local devices can be available only when connecting with WTS, which version is 5.1 or later. 6.
6-3. Display Resolutions / Desktop Colors [Desktop Area and Refresh Frequency] ...................................Set the resolution/refresh rate. (630L/630L-N supports 1024 x 768 @60 Hz only). [Colors]...............................Set the desktop color (256 Colors / High color) of the following.
Power save [Screen Saver] .....................Set the screen saver and power save settings. Select the check box, and set an idle period into the [Wait] box. NOTE • Power saving system After the Screen Saver idle period passed, eClient shift to the power save mode. The power consumption is lower than 7 W in the power save mode. • Do your part to conserve energy, turn off the unit when you are finished using it.
6-4. Experience (RDP protocol only) WTS connection [Performance] .....................Specify your connection speed to WTS connection. Choose your connection speed from the pull-down menu or select the setting check box. NOTE • This setting can be available only when connecting with WTS, which version is 5.1 or later. [Reconnect if connection is dropped] ...................................Reconnect automatically if connection is dropped. [Display the connection bar] ...................................
6-5. Control Panel Dialing [Location name]..................Choose the sender’s location (click [New] to add a new sender’s location). [Local Settings are:] ............Setup the local settings. 6.
Keyboard [Input Locale] .....................Selects a keyboard language. [NumLock Key] ..................Enables/cancels NumLock function on start-up. [Check Input Devices].........Enables/cancels checking the connection state of a keyboard and a mouse on start-up. When a keyboard and/or mouse are not connected on start-up, the error message is displayed. When you use neither a mouse nor a keyboard intentionally and you do not display an error message on start-up, uncheck this function.
Mouse [Buttons] .............................Assigns the primary mouse button and the secondary mouse button. [Motion] .............................Adjusts the speed at which the pointer moves on your screen and how fast the mouse pointer accelerates as you move the mouse. Volume & Sounds [Volume] ............................Select the check boxes to enable sounds for events, applications, and notifications. [Sounds] .............................Select sounds for each case. 6.
Date / Time NOTE • Date and time will return to the default settings if the power cord is unplugged. [Date/Time] ........................Set date, current time, or time zone. [NTP Server] .......................Synchronize time with the NTP Server. Select when to synchronize time with the NTP server (on every boot up or every time clicking the [Synchronize] button.
Certificates Lists the certificates stored in the 630L/630L-N. A certificate can be registered, if an external disk is connected to this product, a certificate file can be imported. NOTE • When using the Secure Gateway, select its certificate and click [Add]. By clicking the button, the certificate can be used. (The certificate’s icon changes from to .) DHCP Settings [General] ............................This allows the user to receive IP information from a DHCP server. [DHCP Options].................
Add-on Add-on lists all application software installed in eClient. To remove software, select it and click [Remove]. NOTE • Neither Microsoft Terminal Server Client nor Citrix ICA Client Software is removed. Internet Options [General].............................Setup the browser. [Connection] .......................Setup the connection method to the browser. [Security].............................Setup the security for the connection to the browser. [Advanced]..........................
Printers NOTE • The eClient 630L/630L-N supports an LPTx port and a COM1 port. • Use a RDP protocol to set the printer’s adjustment. • If you are using the ICA protocol, please refer to the instruction manual of the Citrix MetaFrame. Adding another printer settings Select [Add Printer] icon, and click [Open]. “Printer Properties” dialog box is displayed. Setup as following the wizard (See page 18 for the details). Deleting a printer settings Select the printer icon, and click [Delete].
Network and Dial-up Connections Set up connection information according to the connection method to WTS/Web server (See page 14 for the details). 44 6.
6-6. ICA Settings (ICA Protocol only) NOTE • The settings will affect all the settings with ICA protocol. ICA Client information [ICA Client Software] .........Version of the Citrix ICA Client ICA Client Configurations [ICA Client Configurations] ...................................You can set the configuration for the ICA Connection. ICA Client Feature Settings [Configure ICA Client Feature Settings] ...................................You can configure ICA Client Feature Settings.
6-7. Server FTP Service NOTE • Before setting the FTP service, specify the [Password] in the [Control Panel] tab surely. [FTP Service].......................If using this eClient as a FTP server, select the FTP Server ON/OFF check box and set the user name, which is used for accessing the product from the other eClient, in the user list. 46 6.
6-8. Security Security Settings [Terminal Security Enable] ...................................This enables settings on network information of the WTS invisible to prevent from undesirable change.
[Single Button Connect Enable] ...................................(Select the [Terminal Security Enable] check box to enable this check box.) The procedure to connect to the WTS can be restricted. When this check box is selected, the “Single Button Connect” dialog box is displayed when the eClient 630L/630L-N starts up. Clicking [Connect] in the “Single Button Connect” dialog box, the selected connection in the [Startup…] (see page 23) of “Terminal Connection Manager” starts up.
6-9. System Product Information [Software] ...........................Microsoft Windows CE Version, Revision Window Terminal Server Client Revision (Please refer to the page 50 on [Update...].) [Hardware] .........................Serial Number of the unit [Network] .........................Network information 6.
7. SOFTWARE UPDATING/INSTALLATION You can update the built-in/add-on software and install new add-on software. Updating/Installation is performed in the “Terminal Properties”. (Built-in Software) OS: Microsoft Windows CE.NET / BSQUARE’s JEM-CETM Java Solutions Applications: Microsoft Terminal Server Client (Microsoft RDP Client) / Citrix ICA Client NOTE • Before updating, please complete the following: - Copy the update/install file to the accessible file folder of the FTP Server.
2. “Software Update” dialog box is displayed. [Server:] .............................Type IP address or full domain name of the FTP Server. [User Name:]/[Password:] ...Type the user name and password to connect the FTP. [File Name:] ........................Type the folder and copied file name located in the FTP Server. [Example] Type the folder and file name as indicated below if the file is in the “update folder” in the “software folder” \software\update\*.
3. Preventing from update failure, check if the settings are correct and the network environment is suitable. Click [Network Test]. If the settings are correct, the following message is displayed. Click [OK]. 4. Click [Download]. • In case of updating the built-in software The following message is displayed when you successfully download the software. Click [OK] and restart the eClient 630L/630L-N.
Using the 630L/630L-N as a FTP server The firmware file can be updated by the 630L/630L-N set as a FTP server when two or more 630L/630L-N exists on the same network NOTE • This updating is available for OS file (NK.bin) only. FTP Server Update U p 630L/630L-N (FTP Server) 1. 630L/630L-N Update a 630L/630L-N firmware. Refer to the previous section for the updating procedure. 2. Set the FTP Server setting of the 630L/630L-N updated on Step 1. (Refer to page 46 for the FTP service settings.) 3.
8. PRACTICAL SETUP 8-1. 630L/630L-N settings By utilizing the DHCP Option function of the DHCP Server, necessary information are supplied by the DHCP Server, and each setting is automatically set every time the 630L/630L-N is turned on. The following information can be obtained by the eClient 630L/630L-N.
NOTE • Making a Registry File to Connect to a WTS/Web Server. • Please refer to the example below, make a registry file, and save it in Unicode format. Please change the italic bold phrases as necessary. - ConnectionName: Type the connection name in the “Terminal Connection Manager”. - TerminalServerAddress: Type the IP address or the full domain name of the WTS. - URL: Type the URL of the Web Server. (Including “http://”.) [HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\WBT] ....... "SetupWizardEnabled"=dword:0 ..
(for Web Connection) [HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\WBT] "SetupWizardEnabled"=dword:0 ...................... Specifies whether starting up “eClient Setup Wizard” or not. (0; not starting up, 1; starting up) [HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\WBT\Clients\ Registration\Web\Connections\Web1] "StartCmdLineArgs"="URL" .......................... Specifies the URL (including http://) to access. [HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\WBT\Shell] "EnableAutoConnect"=dword:1 .......................
eClient 630L/630L-N Settings Please confirm the following settings in the [Control Panel] tab of [Terminal Properties]. [Network and Dial-up Connections] tab - In case of the connection to the WTS/Web server through built-in LAN • IP address setting selecting of [Obtain an IP address via DHCP] - In case of the connection with a LAN card • IP address setting selecting of [Specify an IP address] and typing “255.255.255.255”.
8-2. Short cut command by keyboard Function Brightness 58 Increase Short cut command [Alt] key and [+] key Decrease [Alt] key and [-] key Display “Terminal Connection Manager” dialog box (after WTS / Web connection) Press [Ctrl] + [Alt] + [End] Display “Terminal Properties” dialog box Press [F2] in the “Terminal Connection Manager” dialog box. Canceling the security settings Press [Shift] + [F2] in the “Terminal Connection Manager” dialog box.
9. TROUBLESHOOTING This page presents problem that can be corrected by the user. If a problem persists even after applying the suggested remedies, contact an EIZO dealer. Problems Points to check with possible solutions 1. No picture is displayed on the screen. Check if the power is OFF. Check brightness setting. Minimum settings will cause screen to be blank. Try pressing a key on the keyboard, or clicking the mouse. (The monitor may be in a power saving mode.) 2.
10. CLEANING Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime. NOTE • Never use thinner, benzene, alcohol (ethanol, methanol, or isopropyl alcohol), abrasive cleaners, or other strong solvents, as these may cause damage to the cabinet or LCD panel. Cabinet To remove stains, wipe the cabinet with a soft, lightly moistened cloth using a mild detergent. Do not spray wax or cleaner directly onto the cabinet.
Mouse If you find that the pointer on the screen doesn’t move smoothly, your mouse needs to be cleaned. Periodically clean the mouse for your operation. (1) Turn off the 630L. (2) Turn the mouse upside down and remove the mouse trackball cover. Press the cover towards “Open” while pulling the other side of the cover. Press (3) Remove the trackball. (4) Wipe the trackball with a soft cloth with neutral detergent. (5) Clean all the rollers, getting all the lint off of them.
11. SPECIFICATIONS Processing Unit Display Device CPU National Semiconductor Geode GX1, 300 MHz Memory RAM: 64 MB, ROM: 32 MB LAN 10 BASE-T/100BASE-TX, Wake On LAN supported Speakers Output Level: LCD Panel 38 cm (15 inch) TFT color LCD panel Anti-Glare Hard Coating (Viewing Angle: Horizontal: 160°, Vertical: 150°) Dot Pitch 0.297 mm x 0.297 mm Resolution 1024 x 768 Viewable Image Size 304.1 mm (H) x 228.1 mm (V) (11.9” (H) x 8.
Certifications and Standards 100-120 VAC range TÜV/NRTL, c-TÜV, FCC class A, CB, TÜV Rheinland ® *2 Ergonomics Approved, EPA ENERGY STAR program, TCO’99 200-240 VAC range CE, CB, TÜV Rheinland/GS, TÜV Rheinland/Ergonomic ® *2 Approved, EPA ENERGY STAR program, TCO’99 *1 Monaural microphone connector is not available now. *2 Applicable to only gray (standard color) version. Dimensions mm (inches) 25˚ 55 (2.2) 3 (0.1) 230 (9.0) 160 (6.3) 390 (15.4) 238.5 (9.4) 123.5 (4.9) 78.5 (3.1) 135 (5.3) 75 (3.
12. REFERENCE 12-1. Attaching an Arm Stand The eClient 630L/630L-N can be used with an arm stand by removing the tilt stand and attaching the arm stand to the terminal. NOTE • Use an arm stand that satisfies the following. - When using the eClient 630L/630L-N with an arm stand, the arm stand must be VESA approved: - Use an arm stand with a 75 mm x 75 mm hole spacing on the arm mounting pad. - Use an arm stand that is able to support an object weighing 8.0 kg. - A GS approved arm stand.
INDEX A M ADDING & CHANGING A CONNECTION NAME ...................... 20 Add-on .................................................... 42 Administration Console........................... 48 Attaching an Arm Stand .......................... 64 Automatic Logon .............................. 21, 22 Autostart Connection .............................. 23 Making a Registry File ............................ 55 Mouse ................................................. 6, 39 Multi Session.............................
