User’s Manual Color LCD Monitor
English SAFETY SYMBOLS This manual uses the safety symbols below. They denote critical information. Please read them carefully. WARNING Failure to abide by the information in a WARNING may result in serious injury and can be life threatening. CAUTION Failure to abide by the information in a CAUTION may result in moderate injury and/or property or product damage. Indicates a prohibited action. Indicates to ground for safety. Copyright© 2005-2006 EIZO NANAO CORPORATION All rights reserved.
English TABLE OF CONTENTS PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 1. 2. 3. 4. INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 1-1. Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 1-2. Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
English PRECAUTIONS IMPORTANT! z This product has been adjusted specifically for use in the region to which it was originally shipped. If operated outside the region to which it was originally shipped, the product may not perform as stated in the specifications. z To ensure personal safety and proper maintenance, please read this section and the caution statements on the unit (refer to the figure below).
English WARNING Keep small objects or liquids away from the unit. Small objects accidentally falling through the ventilation slots into the cabinet or spillage into the cabinet may result in fire, electric shock, or equipment damage.If an object or liquid falls/spills into the cabinet, unplug the unit immediately. Have the unit checked by a qualified service engineer before using it again. Place the unit at the strong and stable place.
English WARNING The equipment must be connected to a grounded main outlet. Not doing so may cause in fire or electric shock. Use the correct voltage. z The unit is designed for use with a specific voltage only. Connection to another voltage than specified in this User’s Manual may cause fire, electric shock, or equipment damage. z Do not overload your power circuit, as this may result in fire or electric shock. Handle the power cord with care.
English CAUTION Handle with care when carrying the unit. Disconnect the power cord and cables when moving the unit. Moving the unit with the cord attached is dangerous. It may result in injury. When handling the unit, grip the bottom of the unit firmly with both hands ensuring the panel faces outward before lifting. OK Dropping the unit may result in injury or equipment damage. Do not block the ventilation slots on the cabinet. z Do not place any objects on the ventilation slots.
English LCD Panel In order to suppress the luminosity change by long-term use and to maintain the stable luminosity, use of a monitor in lower brightness is recommended. The screen may have defective pixels. These pixels may appear as slightly light or dark area on the screen. This is due to the characteristics of the panel itself, and not the product. The backlight of the LCD panel has a fixed life span. When the screen becomes dark or begins to flicker, please contact your dealer.
English 1. INTRODUCTION Thank you very much for choosing an EIZO Color Monitor. 1-1. Features z [Horizontal scanning frequency] 24.8 - 80 kHz [Vertical scanning frequency] 50.0 - 75.1 Hz [Resolution] 1280 dots x 1024 lines z Auto Screen Adjustment function incorporated (p. 18) z BrightRegulator function incorporated (p. 19) z Support to sRGB (p. 31) standard 1-2. Package Contents Please contact your local dealer for assistance if any of the listed items are missing or damaged.
English 1-3. Controls & Connectors Front (1) Control Panel (2) (3) (4) (5) (6) (7) (1) ScreenManager® (2) Sensor*1 (3) Control Button (Left)*2 (4) Enter Button (5) Control Button (Right)*2 (6) Power Button (7) Power Indicator*3 Green Operation Orange Power saving Off Power off *1 When using the BrightRegulator function, the sensor detects the surrounding brightness, see page 19. *2 Pressing the Control buttons without displaying ScreenManager will display the Brightness Adjustment (p.
English Rear (10) (11) (12) Bottom (8) (8) Power Connector (9) D-Sub mini 15 pin Input Connector (9) (10) 4 Holes for Mounting an Arm-Stand*4 (11) Security Lock Slot*5 (12) Stand *4 The LCD monitor can be used with an optional arm stand by removing the stand, see page 22. *5 Allows for connection of a security cable. This lock supports Kensington’s MicroSaver security system.
English 2. CABLE CONNECTION 2-1. Before Connecting Before connecting your monitor to the PC, change the display screen settings (resolution (p. 30) and frequency) in accordance with the charts below. NOTE z When your computer and display support VESA DDC, the suitable resolution and the refresh rate are set by just plugging your display into the computer without any manual settings.
English 2-2. Connecting the Signal Cable NOTE z Be sure that the power switches of both the PC and the monitor are OFF. 1. Plug the signal cable into the connector at the rear of the monitor and the other end of the cable into the video connector on the PC. After connecting, secure the connection with the screw-in fasteners.
English 2. Plug the power cord into the power connector on the rear of the monitor. Then, plug the other end of the cord into a power outlet. WARNING Use the enclosed power cord and connect to the standard power outlet of your country. Be sure to remain within the rated voltage of the power cord. Not doing so may result in fire or electric shock. The equipment must be connected to a grounded main outlet. Not doing so may result in fire or electric shock. 3.
English 3. SCREENMANAGER 3-1. How to use the ScreenManager Main Menu Control Panel Power Button Enter Button Left Control Button (To select the desired sub menu to the left / downward and adjust) 1. Right Control Button (To select the desired sub menu to the right / upward and adjust) Entering the ScreenManager Press the Enter Button once to display the main menu of the ScreenManager. 2. 3.
English 3-2. ScreenManager Adjustments and Settings The following table shows all the ScreenManager’s adjustment and setting menus. Main menu Sub menu Reference Auto Adjustment Screen Screen Screen Clock Adjust the Clock (p. 31). Phase Adjust the Phase (p. 30). Hor. Position Adjust the Horizontal Position. Ver. Position Adjust the Vertical Position. Color Mode 4-4. Color Adjustment (p. 21) Color 4-1. Auto Screen Adjustment (p.
English 3-3. Useful Functions Adjustment Lock Use the “Adjustment Lock” function to prevent any accidental changes. Locked function z Settings in the ScreenManager Unlocked function z BrightRegulator function z Adjusting the brightness by the left/right control button z Turning the power on and off by the Power button [To lock] (1) Switch off the monitor’s Power by the power button. (2) Press on the Enter button while switching on the monitor’s power.
English 4. ADJUSTMENT Adjust the screen by refering from “4-1. Auto Screen Adjustment” to “44. Color Adjustment”. 4-1. Auto Screen Adjustment Screen flickering is suppressed and the proper position is adjusted automatically in the following cases. z When the monitor is input the input signal from the computer that has never been connected the monitor. z Changing the monitor’s resolution or refresh rate When the screen is flicking or the position is not proper.
English 4-3. Brightness Adjustment BrightRegulator Function BrightRegulator function adjusts the brightness of the screen automatically depending on the surrounding brightness. The brightness of backlight is adjusted as the sensor on the lower side of the monitor detects the surrounding brightness (Default: this function is set “Enable”.) [To deactivate this function] (1) Select in the ScreenManager menu. (2) Select “Disable”. NOTE z Do not block the sensor (p.
English 4-4. Color Adjustment The menu in the ScreenManager enables to change the color of the screen. By using the , the adjustment mode can be selected from (to adjust the color settings according to your preference) and (p. 31) mode. Perform the “Range Adjustment” (p. 18) before making the color adjustments. NOTE z Allow the LCD monitor to stabilize for at least 20 minutes before making image adjustments.
English 4-5. Power-save Setup NOTE z Do your part to conserve energy, turn off the monitor when you are finished using it. Disconnecting the monitor from the power supply is recommended to save energy completely. This monitor complies with the “VESA DPMS” (p. 31) [Procedure] Set the PC’s power saving settings. [Power saving system] PC Monitor Power Indicator Operation Operation Green Power saving Orange Power saving STAND-BY SUSPEND OFF Operate the mouse or keyboard to return to a normal screen.
English 5. ATTACHING AN ARM STAND The LCD monitor can be used with an optional arm stand. Using our optional arm or stand is recommended. (Ask your local dealer for information.) NOTE z If you will use the arm or stand of other manufacturers, confirm the followings to the manufacturers before selecting.
English 4. Attach an arm stand to the LCD monitor securely. Attach the removed stand cover again to the monitor. Arm-stand 4 Mounting Screws : M4 x 12 mm 5.
English 6. TROUBLESHOOTING If a problem persists even after applying the suggested remedies, contact an EIZO dealer. z No picture problems → See No.1 ~ No.2 z Imaging problems → See No.3 ~ No.8 z Other problems → See No.9 Problems 1. 2. No picture z Indicator status: Off z Indicator status: Orange Following messages appear. z 3. 4. 24 Whenever an error signal message appears, the signal frequency will be displayed in red. (Example) Display position is incorrect.
English Problems 5. Afterimages appear. Points to check with Possible Solutions Do you use the screen saver or timer when displaying the same image for extended periods of time? Afterimages are particular to LCD monitors. Avoid displaying the same image for extended periods of time. 6. The screen has defective pixels (e.g. slightly light or dark). This is due to the characteristics of the panel itself, and not the LCD product. 7. Fingerprints remain on the screen.
English 7. CLEANING Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime. NOTE z Never use thinner, benzene, alcohol (ethanol, methanol, or isopropyl alcohol), abrasive cleaners, or other strong solvents, as these may cause damage to the cabinet or LCD panel. Cabinet To remove stains, wipe the cabinet with a soft, lightly moistened cloth using a mild detergent. Do not spray wax or cleaner directly into the cabinet.
English 8. SPECIFICATIONS LCD Panel 43.2 cm (17.0 inch), TFT color LCD panel with Anti-Glare Hard Coating Viewing Angle: H: 170°, V: 155° (CR ≥ 5) Dot Pitch 0.264 mm Horizontal Scan Frequency 24.8 ~ 80 kHz (Automatic) Vertical Scan Frequency 50.0Hz ~ 75.1 Hz (Automatic) Resolution 1280 dots x 1024 lines Dot Clock (Max.) 135 MHz Display Colors 16 million colors (max.) Display Area 337.9 mm (H) x 270.3 mm (V) (13.3” (H) x 10.6” (V)) (Viewable image size: 432 mm (17.
English Default settings Brightness Color 100% Color Mode Custom Temperature Off (Normal white ; approx. 6500K) Gain 100% Off Timer Disable Menu Position Center BrightRegulator Enable Language English Dimensions 1(0.04) mm (inches) 30 59.5(2.34) 1(0.04) 3.9(0.15) 17.4(0.69) 5 369(14.5) 339.8(13.4) 28.6(1.13) 128(5.0) 64.5(2.54) 385.2(15.2) 75.5(2.97) 14.6(0.57) 3.9(0.15) 231.7(9.1) 85.2(3.35) 78.2(3.08) 272.2(10.7) 14(0.55) 42.9(1.69) 150(5.9) 28 8.
English Pin Assignment D-Sub mini 15 pin connector 3 4 5 10 15 9 1 2 8 7 6 14 13 12 11 Pin No. Signal Pin No. Signal Pin No. Signal 1 Red video 6 Red ground 11 Ground Shorted 2 Green video 7 Green ground 12 Data (SDA) 3 Blue video 8 Blue ground 13 H. Sync 4 Ground 9 No pin 14 V. Sync 5 No pin 10 Ground Shorted 15 Clock (SCL) 8.
English 9. GLOSSARY Clock With the analog input signal display, the analog signal is converted to a digital signal by the LCD circuitry. To convert the signal correctly, the LCD monitor needs to produce the same number clock pulse as the dot clock of the graphics system. When the clock pulse is not correctly set, some vertical bars of distortion are displayed on the screen.
English sRGB (Standard RGB) “International Standard for Red, Green, and Blue color space” A color space was defined with the aim of the color matching between applications and hardware devices, such as monitors, scanners, printers and digital cameras. As a standard default space, sRGB allows Internet users to closely match colors.
APPENDIX/ANHANG/ANNEXE Preset Timing Chart Timing-Übersichten Synchronisation des Signaux Based on the signal diagram shown below 19 factory presets have been registered in the monitor’s microprocessor. Der integrierte Mikroprozessor des Monitors unterstützt 19 werkseitige Standardeinstellungen (siehe hierzu die nachfolgenden Diagramme). 19 signaux ont été enregistrés en usine dans le microprocesseur du moniteur, conformément au diagramme de synchronisation ci-dessous.
Frequencies Sync Polarity Dot Clock MHz H kHz V Hz H V VESA 1024 × 768 @70 Hz 75.000 56.48 70.07 Nega. Nega. VESA 1024 × 768 @75 Hz 78.750 60.02 75.03 Posi. Posi. VESA 1152 × 864 @75 Hz 108.000 67.50 75.00 Posi. Posi. VESA 1280 × 960 @60 Hz 108.000 60.00 60.00 Posi. Posi. VESA 1280 × 1024 @60 Hz 108.000 63.98 60.02 Posi. Posi. VESA 1280 × 1024 @75 Hz 135.000 79.98 75.03 Posi. Posi.
[Applicable to gray cabinet version.] Congratulations! The display you have just purchased carries the TCO’03 Displays label. This means that your display is designed, manufactured and tested according to some of the strictest quality and environmental requirements in the world. This makes for a high performance product, designed with the user in focus that also minimizes the Impact on our natural environment.
[Applicable to black cabinet version only] Congratulations! You have just purchased a TCO’99 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products.
Environmental Requirements Flame retardants Flame retardants are present in printed circuit boards, cables, wires, casings and housings. Their purpose is to prevent, or at least to delay the spread of fire. Up to 30% of the plastic in a computer casing can consist of flame retardant substances. Most flame retardants contain bromine or chloride, and those flame retardants are chemically related to another group of environmental toxins, PCBs.
For U.S.A, Canada, etc. (rated 100-120 Vac) Only FCC Declaration of Conformity We, the Responsible Party EIZO NANAO TECHNOLOGIES INC. 5710 Warland Drive, Cypress, CA 90630 Phone: (562) 431-5011 declare that the product Trade name: EIZO Model: FlexScan P1700 is in conformity with Part 15 of the FCC Rules.
Hinweise zur Auswahl des richtigen Schwenkarms für Ihren Monitor Dieser Monitor ist für Bildschirmarbeitsplätze vorgesehen. Wenn nicht der zum Standardzubehör gehörige Schwenkarm verwendet wird, muss statt dessen ein geeigneter anderer Schwenkarm installiert werden.
Recycle Auskunft Die Rucknahme dieses Produktes nach Nutzungsende ubernimmt EIZO in Deutschland zusammen mit dem Partner eds-r gmbh rucknahmesysteme. Dort werden die Gerate in ihre Bestandteile zerlegt, die dann der Wiederverwertung zugefuhrt werden. Um einen Abholtermin zu vereinbaren und die aktuellen Kosten zu erfahren, benutzen Sie bitte folgende Rufnummer: 02153-73 35 00. Weitere Informationen finden Sie auch unter der Internet-Adresse: www.eizo.de.
