ELST82 Specification Sheet

ELCO Lighting©
ELCO Lighting©
DIMENSIONS
PRODUCT SPECIFICATIONS
INSTALLATION
CATALOG NUMBER
2042 East Vernon Avenue, Vernon, CA 90058 • Tel: [phone] Fax: [phone] • www.elcolighting.com
© ELCO LIGHTING 2013 All Rights Reserved. Rev. April 2012. ELCO Lighting reserves the right to make specification and design changes without notice.
ELCO
LIGHTING
PROJECT INFORMATION:
Project Name:
Fixture Type:
Date:
ELST82
Diecast Brick Light
with Grill Faceplate
Example: ELST82W (White)
ELST82B (Black)
ELST82BZ (Bronze)
Faceplate: 9 3/4" x 3 5/8"
Housing: 8 1/2"W x 3"H x 4 1/8"D
Cutout: 8 3/4" x 3 1/4"
FInish: Black, White, Bronze
• 5.3W, 120V, 60Hz, driver included, non-dimmable.
LED module contains 24 high efficacy LED chips
3000°K, 3W, 340 lm, CRI 75.
Description: LED diecast aluminium housing
with diffused glass lens suitable for use on stairs,
wall bases, or any indoor or outdoor applications
requiring safe illuminationin dark areas.
Mounting: Housing equipped with two
side brackets. Also (2) 1/2" knockouts
for easy wiring.
Faceplate: Faceplate is secured to the
housing by 2 screws.
Labels:
• U.L. listed for wet locations
• U.L. listed for poured concrete
• U.L. listed for direct contact with insulation (Type IC)
9 3/4"9 3/4"
3 5/8"3 5/8"
8 1/2"8 1/2"
3"3"
4 1/8"4 1/8"
