INSTRUCTION BOOKLET MIXED FUEL COOKER CSIG 503 W Please read this instruction booklet before using the appliance 1
Important Safety Information You MUST read these warnings carefully before installing or using the appliance. If you need assistance, contact our Customer Care Department on 08705 950950 Installation ● This cooker must be installed by qualified personnel, according to the manufacturer’s instructions and to the relevant British Standards. ● Unstable or misshapen pans should not be used on the hob burners as unstable pans can cause an accident by tipping or spillage.
Contents For the User For the Installer Important Safety Information .............. 2 Instructions for the Installer ............. 20 Description of the Cooker .................... 4 Important Safety Requirements ......... 21 Control Panel ...................................... 5 Installation ........................................ 22 The Oven Cavity ......................................... 5 Accessories ................................................5 Electrical connections ....................
Description of the Cooker Cooker lid Semi-rapid burner Auxiliary burner Semi-rapid burner Rapid burner NORMAL Control panel RAPID SIMMER NORM GAS OVEN & ELECTRIC GRILL TIMER GRILL O Oven door Storage drawer 4
Control Panel 2 1 NORMAL RAPID SIMMER NORM GAS OVEN & ELECTRIC GRILL TIMER GRILL O 3 1. 2. 3. 4. 5. 6. 7. 8. 9.
Operation Hob burners To light a burner, push in and turn the relevant control knob anticlockwise to maximum position. At the same time push the electric ignition button which is marked with a little spark. Then adjust the flame as required. If the burner does not ignite, turn the control knob to zero, and try again. i When switching on the mains, after installation or a power cut, it is quite normal for the spark generator to be activated automatically.
Gas oven and Electric grill Oven Function Control Knob ● Oven switched off 140 AX M 0 240 Grill - The heat comes only from the top 16 Range of temperature regulation for gas oven element 200 ● -MAX Minute minder 10 15 20 30 The Minute minder will not affect the oven operation in any way, if it is in use. 40 Turn the Minute Minder knob clockwise to the maximum time position, then turn it back to the required time.
Using the Oven • Always cook with the oven door closed. i • Stand clear when opening the drop down oven door. Do not allow it to fall open - support the door using the door handle, until it is fully open. • The oven has four shelf levels, and is supplied with two shelves. The shelf positions are counted from the bottom of the oven as shown in the diagram. It is important that these shelves are correctly positioned as shown in the diagram. • Do not place cookware directly on the oven base.
Using the Gas oven Before using your oven Switch the oven to MAX. and leave it to run empty for about 30 minutes to remove any unpleasant smell. During cooking, the door should be opened as little as possible to avoid heat loss, and excessive fuel consumption. ☞ To ignite the oven gas burner: 1. Open the oven door. 2. Hold a flame to the right-hand side hole (see fig.) 3. Press the oven control knob and turn it anticlockwise until the maximum temperature is reached. 4.
Gas Oven Cooking Charts This chart is intended as a guide only. It may be necessary to increase or decrease the temperature to suit your individual requirements. Only experience will enable you to determine the correct setting for your personal requirements.
Gas Oven Cooking Charts This chart is intended as a guide only. It may be necessary to increase or decrease the temperature to suit your individual requirements. Only experience will enable you to determine the correct setting for your personal requirements.
Grilling Grilling must be carried out with the oven door closed. The grill pan handles must be removed from the pan. ☞ How to Use the Grill 1. Turn the oven control function knob to . The grill pilot light will come on. 2. Adjust the grid and grill pan runner position to allow for different thicknesses of food. Position the food close to the element for faster cooking and further away for more gentle cooking. Preheat the grill for a few minutes before sealing steaks or toasting.
Maintenance and Cleaning Before any maintenance or cleaning can be carried out, you must DISCONNECT the cooker from the electricity supply. The Hob Top The hob is best cleaned whilst it is still warm, as spillage can be removed more easily than if it is left to cool. Regularly wipe over the hob top using a soft cloth well wrung out in warm water to which a little wasing up liquid has been added.
Cleaning the Oven The oven should be kept clean at all times. A build-up of fats or other foodstuffs could result in a fire, especially in the grill pan. Cleaning materials Before using any cleaning materials on your oven, check that they are suitable and that their use is recommended by the manufacturer. Cleaners that contain bleach should NOT be used as they may dull the surface finishes. Harsh abrasives should also be avoided.
Oven Shelves To clean the oven shelves, soak in warm soapy water and remove stubborn marks with a well wetted soap impregnated pad. Rinse well and dry with a soft cloth. Oven lamp replacement Disconnect the appliance. Unscrew the lamp and substitute it with another suitable for higher temperature (300°C) having the following specifications: Voltage: 230-240V (50Hz) Power: 15W Connection: E14 FO 0424 Cleaning around the flame spreader the small flap.
Something Not Working If the appliance is not working correctly, please carry out the following checks, before contacting your local Parkinson Cowan Service Centre. IMPORTANT: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee.
Service and Spare Parts If you require spare parts or an engineer contact your local Service Force Centre by telephoning: 08705 929 929 Your call will be routed to the Service Centre covering your post code area. The addresses of Parkinson Cowan Service Force Centres are detailed on the following pages.
PARKINSON COWAN SERVICE FORCE To contact your local Parkinson Cowan Service Force Centre telephone 08705 929 929 CHANNEL ISLANDS GUERNSEY Guernsey Electricity PO Box 4 Vale , Guernsey Channel Islands JERSEY Jersey Electricity Company PO Box 45 Queens Road St Helier Jersey Channel Islands JE4 8NY SCOTLAND ABERDEEN (M05) AUCHTERMUCHY (M03) BLANTYRE (M07) DUMFRIES (M01) DUNOON (M 67) GLASGOW (M04) INVERNESS (M06) ISLE OF ARRAN (OWN SALES) ISLE OF BARRA (OWN SALES) ISLE OF BUTE (M66) 18 8 Cornhil
PARKINSON COWAN SERVICE FORCE To contact your local Parkinson Cowan Service Force Centre telephone 08705 929 929 MIDLANDS BIRMINGHAM (M18) BOURNE (M44) BRIDGNORTH (M72) 66 Birch Road East, Wyrley Road Industrial Estate Witton Birmingham B67DB Manning Road Ind Estate Pinfold Road Bourne PE10 9HT 1 Underhill Street Bridgnorth Salop WV16 4BB GLOUCESTER (M23) 101 Rycroft Street Gloucester GL1 4NB HEREFORD (M31) Unit 3 Bank Buildings Cattle Market Hereford HE4 9HX HIGHAM FERRERS (M51) The Old Barn Westf
Instructions for the Installer Technical Data Model Number: CSIG 503 W Appliance Class 2 sub class 1 and Class 1 APPLIANCE CATEGORY: II 2H3+ APPLIANCE GAS SUPPLY: Natural gas G20 20mbar Oven Dimensions Height Depth Width Oven Capacity Grill Element Oven light Total rating Supply voltage (50 Hz) Oven burner 900 mm 600 mm 497 mm 1.7 Cu. ft 1,827 W 15 W 1,843 W 230-240 V 3,000 W Hob TYPE OF GAS CHARACTERISTICS VALUE = 37.78 MJ/m3 Ws - 50.7 MJ/ m3 NOMINAL THERMAL POWER kW VALUE = 49.
Important Safety Requirements This appliance must be installed in accordance with the Gas Safety (Installation and Use) Regulations (current addition) and the I.E.E. Wiring Regulations. Detailed recommendations are contained in the following British Standard Codes of Practice - B.S. 6172, B.S. 5440: Part 2 and B.S. 6891: Current Editions.
Installation 1. Positioning the Appliance (Fig. 1) D The appliance is designed to be flush fitted with 2mm clearance at each side to allow for it to be pulled forward for cleaning etc. 420 115 780 787 C Note A: E B Note B: The hotplate side trims should be flush with the cabinets and must not be below. Adjustable levelling feet at the front and rear are provided on the base of the appliance.
300 mm. WALL FACE 100 mm. 480 mm. BACK OF COOKER ENGAGEMENT EDGE FOR STABILITY BRACKET LEVELLING FEET BASE OF COOKER A PENCIL LINE ON THE FLOOR 295 mm. SIDE VIEW OF THE COOKER PLAW VIEW OF THE COOKER FO 0179 Fig. 2 Fitting the Stability Bracket (Not supplied) If the cooker has to be installed with a flexible supply pipe, it is necessary that a stability device is fitted. (See safety Requirements: Page 21).
Electrical connections Any electrical work required to install this cooker should be carried out by a qualified electrician or competent person, in accordance with the current regulations. THIS COOKER MUST BE EARTHED. Permanent Connection In the case of a permanent connection, it is necessary that you install a double pole switch between the cooker and the electricity supply (mains), with a minimum gap of 3 mm.
Commissioning When the hob has been fully installed it will be necessary to check the minimum flame setting. To do this, follow the procedure below. - Turn the gas tap to the MAX position and ignite. - Set the gas tap to the MIN flame position then turn the control knob from MIN to MAX several times. If the flame is unstable or is extinguished follow the procedure below. a Procedure: ☞ Re-ignite the burner and set to MIN. Remove the control knob.
Conversion from Natural to LPG Gas IMPORTANT The replacement/conversion of the gas hob should only be undertaken by a CORGI registered engineer. It is important to note that this model is designed for use with natural gas but can be converted for use with butane or propane gas providing the correct injectors are fitted. The gas rate is adjusted to suit.
Minimum level adjustment of gas oven burner After setting the oven on maximum temperature with door closed for about 10 minutes, turn the knob on minimum. To reach the thermostat by-pass screw and adjust the minimum level, act as follows: – take out the knobs; – remove the front panel; – in case of conversion from natural gas to LPG, tightly screw the by-pass screw of thermostat (see fig.); – to convert from LPG to natural gas, unscrew the bypass screw, until a regular small flame is reached.
