EDC2086PDW ZH 滚筒干衣机 EN TUMBLE DRYER MS MESIN PENGERING 用户手册 USER MANUAL MANUAL PENGGUNA 2 17 34
www.electrolux.com 内容 1. 安全信息............................................................................................................. 3 2. 安全说明............................................................................................................. 4 3. 产品说明............................................................................................................. 5 4. 控制板................................................................................................................. 6 5. 程序表.
中文 1. 3 安全信息 在安装和使用本机之前,请认真阅读随附的操作说明。对 于因安装和使用不当而造成的伤害和损坏,制造商不承担 任何责任。请始终将本操作说明随机器保存,以供将来参 考。 1.1 儿童和残弱人士安全 警告! 存在窒息、受伤或永久性残疾的危险。 • • • • • • • • 本器具可供 8 岁及以上儿童和肢体不健全、感官或精神 上有障碍或缺乏相关经验及知识的人士使用,前提是他 们在使用本器具时受到监督或得到安全使用指导,同时 了解使用过程中可能涉及的危险。 请勿让儿童玩耍本机。 除非有成人始终在旁监督,否则 3 岁以下儿童应远离本 机。 请确保所有包装物远离儿童。 所有洗衣剂都应远离儿童。 机门处于打开状态时请让儿童和宠物远离本机。 如果本机配备了儿童安全装置,建议您启用它。 清洁和用户维护不应由儿童在无人监督的情况下完成。 1.
www.electrolux.
中文 2.2 电气连接 • 警告! 存在火灾和触电危险。 • • • 设备必须接地。 请确保铭牌上的电气信息与供电情况 相匹配。如果不匹配,请联系电气技 师。 始终使用正确安装的防电击插座。 请勿使用多插头扩展适配器和延长电 缆。 断开设备与电源的连接时,请勿拉动电 源线,请始终拉动电源插头。 请勿用潮湿的双手碰触电源线或电源 插头。 仅针对英国与爱尔兰。本机随附有 13 安培的电源插头。如果必须更换电源 插头中的保险丝,请使用 13 安培的 ASTA (BS 1362) 保险丝。 设备符合欧盟 E.E.C. 指令。 • • • • • • • • 2.4 养护和清洁 警告! 存在人员受伤或设备受损的 危险。 • • 请勿使用喷淋水或蒸汽来清洁本设备。 请使用湿软布清洁本设备。只可使用 中性清洁剂。请勿使用研磨剂、磨料清 洁垫、溶剂或金属物件。 2.5 处置 2.
www.electrolux.com 用户可以将装载门安装到另 一侧。它可以帮助轻松地放 入和取出衣物,或者适用于安 装本机时有限制的情况(参见 单独手册)。 4. 控制板 1 2 3 4 5 6 8 7 1 程序旋钮 2 显示屏 3 时间 触摸板 7 Start/Pause(开始/暂停) 触摸板 8 On/Off(开关)按钮 4 Delay(延迟) 触摸板 5 DELICATE(纤细衣物) 触摸板 6 板 Wool Load(毛织品装载量) 触摸 4.
中文 指示灯 7 描述 延时启动 儿童安全防护锁 声音信号 程序持续时间 - 烘干持续时间 - 延迟启动持续时间 程序 待洗物品类型 5. 程序表 负荷(最大)1) / 衣 物标记 棉织物 EXTRA DRY(额 外烘干) 烘干水平:额外烘干。 8 公斤/ Strong Dry(强力 烘干) 烘干水平:强力烘干。 8 公斤/ 烘干水平:衣橱干。 8 公斤/ Cupboard Dry (衣橱干)2) 3) Iron Dry(熨干) 2) 烘干水平:适用于烫熨。 8 公斤/ Synthetic(合成纤维) EXTRA DRY(额 外烘干) 烘干水平:额外烘干。 Cupboard Dry(衣 烘干水平:衣橱干。 橱干) 2) Iron Dry(熨干) 烫) Easy Iron(易 烘干水平:适用于烫熨。 没有必要熨烫的易于护理织品。烘干结果 因衣物类型不同而异。将衣物放入本机之 前,先将它们抖开。程序完成后,立即取 出衣物并将其放在衣架上。 用于烘干一件或两件棉被和枕头(内有羽 Duvets(羽绒被) 毛、绒毛或人工合成的填充料)。 3.5 公斤/ 3.
www.electrolux.
中文 9 6.
www.electrolux.com 7. 设置 3. 同时按住触摸板 (A) 和 (D)。儿童安全 防护锁指示灯亮起。 儿童安全防护锁指示灯亮起。 A B 无法在某程序运行期间禁用 儿童安全防护锁选项。按下 同样的触摸板,直至儿童安全 防护锁指示灯熄灭。 C D E A) 时间 7.2 蜂鸣器打开/关闭 触摸板 B) Delay(延迟) 触摸板 C) DELICATE(纤细衣物) 触摸板 触摸 D) Wool Load(毛织品装载量) 板 E) Start/Pause(开始/暂停) 触摸板 7.1 Child lock(儿童安全防护锁) 功能 要禁用或启用声音讯号,请同时按下触摸 板 (B) 与 (C) 大约 2 秒钟。 7.3 调整剩余的衣物潮湿度 要改变剩余衣物的默认潮湿度: 1. 按下开关按钮,启动本机。 2. 等候约 8 秒钟。 3. 同时按住按钮(A) 和 (B)。 其中一个指示灯会亮起: 此选项可阻止儿童在程序运行期间玩耍本 机。程序旋钮与触摸板锁定。 只有电源开关未锁定。 启用儿童安全防护锁选项: 1. 按下开关按钮,启动本机。 2.
中文 11 倒计时完成时,程序将会启动。 当防皱阶段完成时: 9.3 更换程序 • 指示灯 • • 指示灯 亮起,但不闪烁。 Start/Pause(开始/暂停) 指示灯熄灭。 1. 按下电源开关,关闭本机 2. 按下开关按钮,启动本机。 3. 设置程序。 9.4 程序结束时 程序完成时: • 会响起间歇的声音讯号。 • 指示灯 闪烁。 • 指示灯 闪烁。 • Start/Pause(开始/暂停) 指示灯亮起。 本机会继续运行,防皱阶段还会持续大约 30 分钟。 1. 2. 3. 4. 亮起,但不闪烁。 按下电源开关,关闭机器。 打开箱门。 取出衣物。 关闭本机机门。 请始终在程序完成时清洁过 滤器,并倒空储水器。 9.5 待机功能 为了降低能耗,此功能会在以下情况下自 动关闭设备: • • 在您未启动程序 5 分钟后。 在程序结束 5 分钟后。 10.
www.electrolux.com 11. 养护和清洁 11.1 清洁过滤器 1. 2. 2 1 3. 4. 5.1) 6. 1 2 1) 必要时请使用热水清洁滤网。 11.2 排干储水器中的水 1. 2. 3. 4.
中文 13 您可以将储水器中的水用作 蒸馏水的替代物(例如,用于 蒸汽熨烫)。在使用这种水 前,先用过滤器去除残留脏 物。 11.3 清洁冷凝器 1. 2. 3. 4. 2 1 1 2 11 2 1 5. 6. 7. 8. 12 3 11.4 清洁烘干槽 警告! 清洁前,先断开本机的电源连 接。 使用标准的中性肥皂洗涤剂清洁烘干槽与 烘干槽骨架的内壁。用软布擦干清洁过的 表面。 警告 请勿使用研磨剂或钢丝绒来 清洁烘干槽。 11.
www.electrolux.com 使用湿布进行清洁。用软布擦干清洁过的 表面。 警告 请勿使用家具清洁剂或具有 腐蚀性的清洁剂来清洁本机。 11.6 清洁气流槽 使用吸尘器清除气流槽中的绒毛。 12.
中文 机门打开时的最大宽度 950 毫米 可调高度 850 毫米(+ 15 毫米 - 机脚调节量) 烘干槽容量 118 升 最大衣物量 8 公斤 电压 230-240 伏 频率 50 Hz 保险丝要求 13 安 总功率 2800 瓦 能效等级 B 能耗 1) 4,82 千瓦时 年能耗 2) 560 千瓦时 保持开机 (left—on) 模式下的功耗 0,55 瓦 停机 (off) 模式下的功耗 0,55 瓦 使用类型 家用 允许的环境温度 + 5°C 到 + 35°C 15 防止固体颗粒和潮气侵入的防护等级由防 IPX4 护盖板确保(低压设备无防潮功能时除外) 1) 参照 EN 61121。8 公斤棉质衣物,在 1000 rpm 转速下进行离心脱水。 2) 每年能耗(千瓦时)基于以下条件计算:160 个标准棉质衣物烘干程序在满负荷和部分负荷 情况下的干燥周期;以及低功率模式下的能耗。每个周期的实际能耗将取决于机器的使用方式 备(392/2012 号欧盟法规)。 13.
www.electrolux.com 程序 转速/残余含水量 Cupboard Dry(衣橱 1200 rpm / 40% 干) 800 rpm / 50% 烘干时间 能耗 50 最少 1,47 千瓦 时 57 最少 1,68 千瓦 时 14.
ENGLISH 17 CONTENTS 1. SAFETY INFORMATION.................................................................................... 18 2. SAFETY INSTRUCTIONS...................................................................................20 3. PRODUCT DESCRIPTION................................................................................. 21 4. CONTROL PANEL............................................................................................. 22 5. PROGRAMME TABLE...................................
1. www.electrolux.com SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damages. Always keep the instructions with the appliance for future reference. 1.1 Children and vulnerable people safety WARNING! Risk of suffocation, injury or permanent disability.
ENGLISH • • • • • • • • • • • • • • 19 The appliance can be installed as freestanding or below the kitchen counter with correct space (Refer to the Installation leaflet). Do not install the appliance behind a lockable door, a sliding door or a door with a hinge on the opposite side, where the appliance door can not be fully opened. The ventilation openings in the base (if applicable) must not be obstructed by a carpet. Connect the mains plug to the mains socket only at the end of the installation.
www.electrolux.com • • • • • or pillows fitted with foam rubber pads should not be dried in the tumble dryer. Fabric softeners, or similar products, should be used as specified by the fabric softener instructions. Remove all objects from pockets such as lighters and matches. Never stop a tumble dryer before the end of the drying cycle unless all items are quickly removed and spread out so that the heat is dissipated.
ENGLISH 2.3 Use WARNING! Risk of injury, electrical shock, fire, burns or damage to the appliance. • Use this appliance in a household only. • Do not dry the damaged items which contain padding or fillings. • Only dry fabrics which are applicable to dry in the tumble dryer. Follow the instructions on the fabric label. • If you have washed your laundry with a stain remover start an extra rinse cycle before you start the dryer. • Do not drink or prepare food with the condensed water/distilled water.
www.electrolux.com The load door can be installed by the user in the opposite side. It can help to easily put and remove the laundry or if there is a limit to install the appliance (see separate leaflet). 4. CONTROL PANEL 1 2 3 4 5 6 8 1 Programme knob 2 Display 3 Time touchpad 4 8 On/Off button Touch the touchpads with your finger in the area with the symbol or name of the option. Do not wear gloves when you operate with the control panel.
ENGLISH Indicators 23 Description Filter Delay start Child lock Acoustic signals Programme duration - Time Drying duration - Delay start duration 5. PROGRAMME TABLE Programmes Type of load Load (max.)1) / Fabric mark Cotton Extra Dry Drying level: extra dry. 8kg/ Strong Dry Drying level: strong dry. 8kg/ Cupboard Dry2) 3)Drying level: cupboard dry. Iron Dry 2) Drying level: applicable for iron. 8kg/ 8kg/ Synthetic Extra Dry Drying level: extra dry.
www.electrolux.com Programmes Delicates Type of load Delicate fabrics. Load (max.)1) / Fabric mark 2kg/ Wool fabrics. Gentle drying washable woollens. Remove immediately the items when the programme is completed. 1kg Wool4) For drying sport shoes only with Drying Rack (see separate user manual provided with Drying Rack). 1 pair of sport shoes Refresh Refreshing a textiles that were in storage. 1kg Time Drying With this programme you can use the option Time and set the programme duration.
ENGLISH 25 6.2 Wool Load 6.3 Delicate This option is applicable only to the Wool programme. To get laundry more dried With this option you can set a delicate drying programme that has a low temperature. Use this option with a fabrics press the Wool Load touchpad again and again to increase the programme duration. that have the symbol (e.g. acrylic, viscose). on the fabric label 6.
www.electrolux.com 7. SETTINGS It is possible to deactivate the child lock option while a programme operates. Press and hold the same touchpads until the child lock indicator goes off. A B C D E A) Time touchpad B) Delay touchpad C) Delicate D) Wool Load E) Start/Pause touchpad touchpad touchpad 7.1 Child lock function This option prevents children to play with the appliance while a programme operates. The programme knob and the touchpads are locked. Only the on/off button is unlocked. 7.
ENGLISH 2. Press the on/off button to activate the appliance. 3. Set the correct programme and options for the type of load. The display shows the programme duration. 4. Press the Start/Pause touchpad. The programme starts. 9.2 Starting the programme with delay start 1. Set the correct programme and options for the type of load. 2. Press the delay start button again and again until the display shows the delay time you want to set.
www.electrolux.com • Use an applicable programme for cotton jersey and knitwear to prevent the items to shrink. • Make sure that the laundry weight is not more than the maximum weight that is in the programme table. Fabric label • Dry only the laundry that is applicable for tumble dryer. Refer to the fabric label on the items. Description Laundry that is applicable for tumble dryer. Laundry that is applicable for tumble dryer. Set the programme with standard temperature.
ENGLISH 11.2 Draining the water container 1. 2. 3. 4. You can use the water from the water container as an alternative to distilled water (e.g. for steam ironing). Before you use the water, remove dirt residues with a filter. 11.3 Cleaning the condenser 1. 2. 3. 4.
www.electrolux.com 5. 6. 7. 8. 1 2 12 3 11.4 Cleaning the drum WARNING! Disconnect the appliance before you clean it. Use a standard neutral soap detergent to clean the inner surface of the drum and drum ribs. Dry the cleaned surfaces with a soft cloth. CAUTION! Do not use abrasive materials or steel wool to clean the drum. Use a moist cloth to clean. Dry the cleaned surfaces with a soft cloth.
ENGLISH Problem Possible solution The appliance door does not close. Make sure that the installation of the filter is correct. 31 Make sure that the laundry does not catch between the appliance door and the rubber seal. The appliance stops during operation. Make sure that the water container is empty. Press Start/Pause to start the programme again. The display shows a long programme duration. 1) Make sure that the weight of the laundry is applicable to the duration of the programme.
www.electrolux.
ENGLISH Programme Spun at / residual humidity 800 rpm / 50% Drying time 57 min. 33 Energy consumption 1,68 kWh 14. ENVIRONMENT CONCERNS Recycle the materials with the symbol . Put the packaging in applicable containers to recycle it. Help protect the environment and human health and to recycle waste of electrical and electronic appliances. Do not dispose appliances marked with the symbol with the household waste. Return the product to your local recycling facility or contact your municipal office.
www.electrolux.com KANDUNGAN 1. MAKLUMAT KESELAMATAN.......................................................................... 35 2. MAKLUMAT KESELAMATAN.......................................................................... 38 3. PERIHALAN PRODUK..................................................................................... 39 4. PANEL KAWALAN........................................................................................... 40 5. JADUAL PROGRAM........................................
1. MAKLUMAT KESELAMATAN Sebelum pemasangan dan penggunaan perkakas, baca arahan yang diberikan dengan teliti. Pengilang tidak bertanggungjawab sekiranya pemasangan dan penggunaan yang salah menyebabkan kecederaan dan kerosakan. Sentiasa simpan arahan dengan perkakas untuk rujukan pada masa hadapan. 1.1 Keselamatan kanak-kanak dan individu yang mudah terdedah kepada bahaya AMARAN Risiko lemas, cedera atau kecacatan kekal.
www.electrolux.com 1.2 Keselamatan Umum • • • • • • • • • • Jangan tukar spesifikasi perkakas ini. Jika mesin pengering diletakkan di atas mesin basuh, gunakan kit susunan. Kit susunan, tersedia daripada vendor anda yang dibenarkan, hanya boleh digunakan dengan perkakas yang dinyatakan dalam arahan, yang diberikan bersama-sama dengan aksesori. Baca arahan dengan teliti sebelum pemasangan (Rujuk risalah Pemasangan).
• • • • • • • • • • • Jangan gunakan perkakas jika bahan kimia industri telah digunakan untuk pembersihan. Lapkan lin yang terkumpul di sekeliling perkakas. Jangan jalankan perkakas ini tanpa penapis. Bersihkan penapis lin sebelum dan selepas setiap penggunaan. Jangan keringkan item yang tidak dibasuh di dalam mesin pengering.
www.electrolux.com 2. MAKLUMAT KESELAMATAN 2.1 Pemasangan • • • • • • • • • • Keluarkan semua pembungkusan. Jangan pasang atau gunakan perkakas yang rosak. Patuhi arahan pemasangan yang diberikan dengan perkakas. Sentiasa berhati-hati apabila anda mengalihkan perkakas kerana ia berat. Sentiasa pakai sarung tangan keselamatan. Jangan pasang atau gunakan perkakas apabila suhu kurang daripada 5°C atau lebih tinggi daripada 35°C.
pembersihan pelelas, pelarut atau objek logam. 2.5 Pelupusan • • • AMARAN Risiko kecederaan atau lemas. Putuskan sambungan perkakas daripada bekalan sesalur. Potong kabel sesalur dan buangkannya. Keluarkan pengancing pintu untuk mengelakkan kanak-kanak dan haiwan peliharaan daripada tertutup di dalam perkakas. 3. PERIHALAN PRODUK 1 2 3 4 11 5 10 6 9 7 8 Pintu muatan boleh dipasang oleh pengguna dalam sisi bertentangan.
www.electrolux.com 4. PANEL KAWALAN 1 2 3 4 5 6 8 7 1 Tombol program 2 Paparan 3 Pad sentuh Masa 4 Pad sentuh Tunda 5 Pad sentuh Bahan halus 6 Pad sentuh Muatan Wul Sentuh pad sentuh dengan jari anda di kawasan yang terdapat simbol atau nama opsyen. Jangan pakai sarung tangan apabila anda mengendalikan dengan panel kawalan. Pastikan panel kawalan sentiasa bersih dan kering. 7 Pad sentuh Mula/Jeda 8 Butang Hidup/Mati 4.
Penunjuk Perihalan Tempoh program - Tempoh Pengeringan Masa - Tempoh mula tunda 5. JADUAL PROGRAM Program Jenis muatan Muatan (maks.)1) / Tanda fabrik Kapas Ekstra Kering Tahap pengeringan: ekstra kering. 8kg/ Kering Kuat Tahap pengeringan: kering kuat. 8kg/ Kering Almari2) 3)Tahap pengeringan: kering almari. Tahap pengeringan: boleh diguna pakai Kering Seterika 2) untuk seterika. 8kg/ 8kg/ Sintetik ka Ekstra Kering Tahap pengeringan: ekstra kering. 3.
www.electrolux.com Program Jenis muatan Fabrik wul. Mengeringkan dengan lem‐ but kain bulu biri yang boleh dibasuh. Keluarkan item dengan segera apabila program selesai. Muatan (maks.)1) / Tanda fabrik 1kg Wul4) Untuk mengeringkan kasut sukan sahaja dengan Rak Pengeringan (lihat manual Sepasang kasut pengguna yang berasingan yang dise‐ sukan diakan dengan Rak Pengeringan). sa Segar semula Menyegarkan semula tekstil yang dalam simpanan.
6.2 Muatan Wul 6.3 Bahan halus Opsyen ini boleh diguna pakai hanya untuk program Wul. Untuk memastikan kain cucian lebih kering, tekan pad Dengan opsyen ini, anda boleh menetapkan program pengeringan bahan halus yang mempunyai suhu rendah. Gunakan opsyen ini dengan lagi dan lagi sentuh Muatan Wul untuk meningkatkan tempoh. pada fabrik yang mempunyai simbol label fabrik (cthnya. akrilik, viskos). 6.
www.electrolux.com 7. TETAPAN A B C D E A) Masa Pad sentuh B) Tunda Pad sentuh C) Bahan halus Pad sentuh D) Muatan Wul Pad sentuh E) Mula/Jeda Pad sentuh 7.1 Fungsi kunci keselamatan kanak-kanak Opsyen ini mengelakkan kanak-kanak daripada bermain dengan perkakas semasa program berjalan. Tombol program dan pad sentuh dikunci. Hanya butang hidup/mati tidak dikunci. Mengaktifkan opsyen kunci keselamatan kanak-kanak: 1. Tekan butang hidup/mati untuk mengaktifkan perkakas. 2. Tunggu lebih kurang 8 saat.
• Mulakan program singkat (cthnya. 30 minit) dengan kain cucian lembap. 9. PENGGUNAAN HARIAN 9.1 Mulakan program tanpa mula tunda 9.4 Pada akhir program Apabila program selesai: 1. Sediakan kain cucian dan muatkan perkakas. • Isyarat akustik selang-seli berjalan. AWAS Pastikan bahawa apabila anda menutup pintu, kain cucian tidak tersekat di antara pintu perkakas dengan pengedap getah. 2. Tekan butang hidup/mati untuk mengaktifkan perkakas. 3.
www.electrolux.com 10. PETUA DAN PETUNJUK 10.1 Menyediakan kain cucian • • • • • • • • Tutup zip. Tutup kancing bagi penutup duvet. Jangan biarkan tali leher atau reben tanpa diikat (cthnya. reben apron). Ikatkannya sebelum anda memulakan program. Keluarkan semua item daripada saku. Jika item mempunyai lapisan dalaman yang dibuat daripada kapas, terbalikkannya.
3. 4. 5.1) 6. 1 2 1) jika perlu, basuh penapis dengan air panas. 11.2 Menyalirkan bekas air 1. 2. 3. 4. Anda boleh menggunakan air daripada bekas air sebagai alternatif untuk air suling (cthnya. untuk seterika wap). Sebelum anda menggunakan air, buangkan sisa kotoran dengan penapis.
www.electrolux.com 11.3 Membersihkan pemeluwap 1. 2. 3. 4. 2 1 1 2 11 1 2 5. 6. 7. 8. 12 3 11.4 Membersihkan dram AMARAN Putuskan sambungan perkakas sebelum anda membersihkannya. Gunakan detergen sabun neutral yang biasa untuk membersihkan permukaan dalaman dram dan rusuk dram. Keringkan permukaan yang dibersihkan itu dengan kain lembut. AWAS Jangan gunakan bahan pelelas atau sabut keluli untuk membersihkan dram. 11.
AWAS Jangan gunakan agen pencuci perabot atau agen pencuci yang boleh menyebabkan pengakisan untuk membersihkan perkakas. 11.6 Membersihkan slot aliran udara Gunakan pembersih vakum untuk mengeluarkan bulu kapas daripada slot aliran udara. 12. MENYELESAIKAN MASALAH Masalah Penyelesaian yang mungkin Anda tidak dapat mengaktifkan perkakas. Pastikan bahawa palam sesalur disam‐ bungkan pada soket sesalur. Periksa fius di dalam kotak fius (pema‐ sangan domestik). Program tidak bermula. Tekan Mula/Jeda.
www.electrolux.com Jika hasil pengeringan tidak memuaskan • • • • Program yang ditetapkan adalah salah. Penapis tersumbat. Pemeluwap tersumbat. Terlalu banyak kain cucian di dalam perkakas. • • • Dram kotor. Tetapan yang salah bagi sensor kekonduksian. Slot aliran udara tersumbat. 13.
Tahap perlindungan daripada kemasukan IPX4 zarah pepejal dan lembapan dipastikan oleh penutup perlindungan, kecuali di tempat peralatan voltan rendah tiada per‐ lindungan daripada lembapan 1) Dengan merujuk kepada EN 61121. 8kg kapas diempar pada 1000 putaran per minit (rpm). 2) Penggunaan tenaga setahun dalam kilowatt-jam (kWh), berdasarkan 160 kitaran penger‐ ingan program kapas standard pada muatan penuh dan separa serta penggunaan mod kuasa rendah.
