EN FRONT LOAD DRYER FR SÉCHEUSE Á CHARGEMENT FRONTAL ES SECADORA DE CARGA FRONTAL USE & CARE GUIDE GUIDE D’UTILISATION ET D’ENTRETIEN GUÍA DE USO Y CUIDADO 136936001 March 2017
Important Safety Instructions Product Record WARNING Please read all instructions before using this dryer. Recognize safety symbols, words and labels Safety items throughout this manual are labeled with a WARNING or CAUTION based on the risk type as described below: Record Your Model and Serial Numbers The model and serial numbers of your dryer are found on the serial plate located inside the door opening. Record and retain these numbers.
Important Safety Instructions 3 208-240 v Electric Dryer 10-30R 3-wire (fused 30 amp) UL-approved service cord must be installed on electric dryers (not provided with unit except those manufactured for sale in Canada). 14-30R 4-wire (fused 30 amp) Avoid fire hazard or electrical shock. Do not use an adaptor plug or extension cord or remove grounding prong from electrical power cord. Failure to follow this warning can cause serious injury, fire or death.
Important Safety Instructions PROTECT CHILDREN • Do not allow children to play on or in the dryer. Close supervision of children is necessary when the dryer is used near children. As children grow, teach them the proper, safe use of all appliances. • Destroy the carton, plastic bag and other packing materials after the dryer is unpacked. Children might use them for play. Cartons covered with rugs, bedspreads or plastic sheets can become airtight chambers. • Keep laundry products out of children’s reach.
Features Drum Light 5 LED Display Control Lock Water Container Reversible Door Door Latch Lint Filter Moisture Sensor Door Strike Condenser Access Door Latch Condenser Access Door Adjustable Leveling Legs Drying Rack* *Not all models come with drying rack and stacking kit from the factory. They may be purchased as accessories.
Operating Instructions Normal Operating Sounds You may or may not hear the following sounds from your new dryer: A. SUSPENSION ROLLERS The dryer drum is supported by a set of suspension rollers. At times there may be a thumping or rolling sound when the dryer starts. This may happen if the dryer has not been in use for a period of time, or after a heavy load has remained in the dryer drum for an extended period, creating a temporary flat spot on the edge of the roller.
Operating Instructions 7 Operating Your Dryer WARNING To reduce the risk of fire, electric shock or injury to persons, read the IMPORTANT SAFETY INSTRUCTIONS in this Use and Care Guide before operating your dryer. 1 Prepare load for drying. • Dry items of similar fabric, weight and construction in the same load. • Separate dark items from light-colored items. Separate items that shed lint from those that attract lint. • Check for stains which may not have been removed in washing.
Operating Instructions Start/Pause My Favorites 1 2 3 4 5 1 Power Button 3 My Favorites Button 5 Temperature Button 2 Cycle Selection 4 Cycle Options / Cycle Status Display 6 Start/Pause Button This manual covers many models and not all cycles, options, or features listed are available on every model. Console shown above for reference only. Your model may differ. Cycle Selection Press the Power button to turn on the unit.
Operating Instructions 9 Specialty Cycle Selection Cycle Settings To scroll through the specialty cycles, continue to press the specialty cycles icon. The selected cycle will be shown on the text display. Appropriate temperature, dryness level and options will be displayed for each cycle. The settings can be changed before the cycle is started. If changes are attempted after the cycle starts a signal will beep and “Not possible” will be displayed.
Operating Instructions Drying System Maintenance Procedures Water Container Full (if direct drain kit not installed) When the “Water Container Full” indicator comes on, follow these steps to empty the container: 1. Support the container as you pull it out. 2. Hold container level to prevent water from spilling. 3. Dump water container in sink or drain. Lint Filter Plugged When the “Lint Filter Plugged” indicator comes on, follow these steps to clean the filter: 1.
Operating Instructions 11 Other Features chime indicator cycle count down/ delay start timer delay start Start/Pause My Favorites My Favorites maintenance indicators status display My Favorites After some time of initial usage, the dryer will automatically remember the 3 most used cycles with their settings and options. To cycle through this list continue to press the My Favorites button. Press Start after your desired cycle appears.
Operating Instructions Dryer Settings Chart Start/Pause My Favorites These Temperatures, Dryness Level, and Options are available with the following cycles: time dry wool fast dry jeans towels touch up mixed load casual delicates heavy duty normal specialty cycles temperature max medium low dryness max normal less damp options wrinkle release dry time delay start chime = A
Care and Cleaning 13 WARNING To reduce risk of fire or serious injury to persons or property, comply with the basic warnings listed in the Important Safety Instructions and those listed below. • Before cleaning the dryer interior, unplug the electrical power cord to avoid electrical shock hazards. • Do not use any type spray cleanser when cleaning the dryer interior. Hazardous fumes or electrical shock could occur. INSIDE • Clean the lint filter after every load.
Care and Cleaning Cleaning Condenser 4. Grab the condenser handle and pull straight out. Clean Condenser When the “Clean Condenser” indicator comes on, follow these steps to remove and clean the condenser assembly: 1. Open the dryer door and locate the condenser access door latch release. 5. Rinse condenser in sink. Clean with mild soap and water if necessary. 2. While pressing release, open the condenser access door. 3. Rotate the two latches to lower the condenser screen. 6.
Solutions to Common Problems 15 Common Drying Problems Many drying problems involve poor soil and stain removal, residues of lint and scum, and fabric damage. For satisfactory washing results, follow these suggestions provided by The Soap and Detergent Association. PROBLEM POSSIBLE CAUSES SOLUTIONS PREVENTIVE MEASURES Greasy, oily stains • Fabric softener sheet. • Rub fabric softener stains with bar soap. Rinse and rewash. • Add a few bath towels to small loads for proper tumbling.
Solutions to Common Problems Avoid Service Checklist Before calling for service, review this list. It may save both time and expense. The list includes common occurrences that are not the result of defective workmanship or materials in this dryer. OCCURRENCE POSSIBLE CAUSE SOLUTION Dryer does not start. Electrical power cord is not securely plugged in or plug may be loose. Make sure the plug fits tightly in wall outlet. House fuse blown or circuit breaker tripped.
Major Appliance Warranty Information 17 For the applicable warranty period as set forth below, as measured from your original date of purchase, Electrolux will repair or replace any parts of this appliance that prove to be defective in materials or workmanship when such appliance is installed, used and maintained in accordance with the provided instructions. Warranty Periods: • All parts — One year including labor. In addition, your appliance is covered by a one year, parts only, limited warranty.
