Use and Care Guide

10
Reversing the Door
27. Remove Phillips head screw for door
stop on bottom of freezer door (see
Figure 17A).
28. Remove Phillips head screw for door
closer (see Figure 17B).
29. Flip door closer 180˚ and reinstall part
on the opposite side of door with
screw (see Figure 17C).
30. Place door stop over the door closer
and reattach with screw (see Figure
17C).
31. Use a putty knife to gently remove
the center hinge hole plug (top of
freezer door) and reinstall on the
opposite side of the door.
32. Gently lower freezer door onto the
bottom hinge pin and close door.
33. Remove washer from middle hinge
and flip hinge 180°. Place washer
onto top hinge pin of middle hinge
(see Figure 18).
22. Stand refrigerator upright.
23. Use a putty knife to gently remove
the center hinge screw plugs and
reinstall on the opposite side of the
cabinet (see Figure 15).
Pry Plug
Up With
Putty Knife
Plugs
Move two plugs
Figure 15
Remove the
Screw Cap
With A
Putty Knife
A
B
Remove Sticker
Add Screw
Add Screw Cap
Remove
Screw
Add
Screw
C
Figure 16
Door Closer
Door Stop
Screw
180°
A
C
A
B
Figure 17
Washer
Figure 18
24. Use a putty knife to gently remove
the screw cap (see Figure 16A).
25. Use screwdriver to remove Phillips
head screw (see Figure 16B) and use
a gray plug from the door reversal kit
to cover the hole.
26. Remove sticker on the other side
(see Figure 16C) and insert screw
and tighten. Cover with screw cap.
