EKC4461AEW EN COOKER USER MANUAL
www.electrolux.com CONTENTS 1. SAFETY INFORMATION............................................................................................ 3 2. SAFETY INSTRUCTIONS.......................................................................................... 4 3. PRODUCT DESCRIPTION.........................................................................................7 4. BEFORE FIRST USE..................................................................................................8 5.
ENGLISH 1. 3 SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damages. Always keep the instructions with the appliance for future reference. 1.1 Children and vulnerable people safety WARNING! Risk of suffocation, injury or permanent disability.
www.electrolux.com • • • • • • • • • Metallic objects such as knives, forks, spoons and lids should not be placed on the hob surface since they can get hot. If the glass ceramic surface/ glass surface is cracked, switch off the appliance to avoid the possibility of electric shock. Internally the appliance becomes hot when in operation. Do not touch the heating elements that are in the appliance. Always use oven gloves to remove or put in accessories or ovenware.
ENGLISH • The sides of the appliance must stay adjacent to appliances or to units with the same height. • Do not install the appliance on a platform. • Do not install the appliance adjacent to a door or under a window. This prevents hot cookware to fall from the appliance when the door or the window is opened. • Make sure to install a stabilizing means in order to prevent tipping of the appliance. Refer to Installation chapter. 2.2 Electrical Connection WARNING! Risk of fire and electrical shock.
www.electrolux.com • To prevent damage or discoloration to the enamel: – do not put ovenware or other objects in the appliance directly on the bottom. – do not put water directly into the hot appliance. – do not keep moist dishes and food in the appliance after you finish the cooking. – be careful when you remove or install the accessories. • Discoloration of the enamel has no effect on the performance of the appliance. It is not a defect in the sense of the warranty law.
ENGLISH 7 3. PRODUCT DESCRIPTION 3.1 General overview 7 1 2 3 4 5 3 2 1 5 4 3 2 1 2 3 4 5 6 7 Control panel and hob Air vents for the cooling fan Heating element Lamp Shelf support, removable Fan Shelf positions 4 5 6 1 3.2 Cooking surface layout 1 145 mm 180 mm 180 mm 6 1 Cooking zone 1200 W 2 Steam outlet - number and position depends on the model 3 Cooking zone 1700 W 4 Cooking zone 1200 W 5 Residual heat indicator 6 Cooking zone 1700 W 3 2 145 mm 5 4 3.
www.electrolux.com 3.4 Accessories • Wire shelf For cookware, cake tins, roasts. • Grill- / Roasting pan To bake and roast or as pan to collect fat. • Trivet For roasting and grilling. Use the trivet only with the Grill- / roasting pan. 4. BEFORE FIRST USE WARNING! Refer to Safety chapters. 4.3 Changing the time You cannot change the time of day if the Duration 4.1 Initial Cleaning Remove all accessories and removable shelf supports from the appliance. Refer to "Care and cleaning" chapter.
ENGLISH Use the residual heat to decrease energy consumption. Deactivate the cooking zone approximately 5 - 10 minutes before the cooking process is completed. 9 5.2 Residual heat indicator WARNING! There is a risk of burns from residual heat. The indicator comes on when a cooking zone is hot. Turn the knob to a necessary heat setting. To complete the cooking process, turn the knob to the off position. 6. HOB - HINTS AND TIPS WARNING! Refer to Safety chapters. 6.
www.electrolux.com cleaning, rub the hob dry with a soft cloth. 8. OVEN - DAILY USE 1. Turn the knob for the top / main oven functions to select an oven function. 2. To deactivate the oven turn the knob for the top / main oven functions to the off position. WARNING! Refer to Safety chapters. 8.1 Cooling fan When the appliance operates, the cooling fan activates automatically to keep the surfaces of the appliance cool.
ENGLISH 11 8.4 Main oven functions Symbol 100 - 250 Oven function Application Off position The appliance is off. Oven Lamp To activate the lamp without a cooking function. Defrost To defrost frozen food. Thermaflow® To bake on 1 shelf position and to dry food. Set the temperature 20 - 40 °C lower than for Conventional Cooking. 8.5 Inserting the oven accessories Deep pan: Push the deep pan between the guide bars of the shelf support.
www.electrolux.com 2. Put the deep pan into the oven on the necessary shelf position. You can use the trivet to grill flat dishes in large quantities and to toast. 2. Put the deep pan into the oven on the necessary shelf position. 1. Put the trivet into the deep pan so that the supports of the wire shelf point down. 9. OVEN - CLOCK FUNCTIONS 9.1 Display The electronic programmer works only with the main oven. A B C A) Function indicators B) Time display C) Function indicator 9.
ENGLISH 13 9.3 Clock functions table Clock function Application Time of day To set, change or check the time of day. Minute Minder To set countdown time. This function has no effect on the operation of the appliance. Duration To set the cooking time of the oven. End To set the time of day when the oven should deactivate. For the Minute Minder function the display shows the time left. 3. When the time ends the indicator of the clock function flashes and an acoustic signal sounds.
www.electrolux.com 10.2 Main oven The main oven is particularly suitable for cooking larger quantities of food. 10.3 Baking • Your oven can bake or roast differently to the appliance you had before. Adapt your usual settings (temperature, cooking times) and shelf positions to the values in the tables. • The manufacturer recommends that you use the lower temperature the first time. • If you cannot find the settings for a special recipe, look for the one that is almost the same.
ENGLISH 10.
www.electrolux.com Food Temperature (°C) Time (min) Shelf position Souffles 170 - 180 20 - 30 2 Vegetables: Baked Jacket Potatos 180 - 190 60 - 90 2 Vegetables: Roast Potatos 180 - 190 60 - 90 2 Yorkshire Pudding Large 220 - 210 25 - 40 2 Yorkshire Pudding Individual 210 - 220 15 - 25 2 Roasting Meat, Poultry Refer to the Roasting table 2 10.
ENGLISH Food Temperature (°C) Pastry: Puff Follow manufacturer`s instructions. Reduce the temperature for Fan oven by 20°C 3 Plate Tarts 180 - 190 25 - 45 3 Quiches/Flans 170 - 180 25 - 45 3 Scones 210 - 230 8 - 12 1–3 Roasting: Meat, Poultry 160 - 180 Refer to the Roasting table 2 10.7 Roasting • Use heat-resistant ovenware to roast (refer to the instructions of the manufacturer).
www.electrolux.com Food Temperature (°C) Time (min) Duck 180 - 200 25 - 35 minutes per 0.5 kb (1 lb) and 25-30 minutes over Pheasant 170 -190 35 - 40 minutes per 0.5 kb (1 lb) and 35-40 minutes over Rabbit 170 - 190 20 minutes per 0.5 kb (1 lb) and 20minutes over 10.9 Grilling in general • Grill only flat pieces of meat or fish. • Always preheat an empty oven with the grill functions for 5 minutes. WARNING! Always grill with the oven door closed.
ENGLISH 10.11 Defrosting • Remove the food packaging. Put the food on a plate. • Do not cover it with a bowl or a plate. This can extend the defrost time. 19 • Use the first oven shelf level. The one on the bottom. 11. OVEN - CARE AND CLEANING WARNING! Refer to Safety chapters. 11.1 Notes on cleaning • Clean the front of the appliance with a soft cloth with warm water and a cleaning agent. • To clean metal surfaces, use a usual cleaning agent. • Clean the appliance interior after each use.
www.electrolux.com 11.4 Removing the shelf supports 2. Hold the door trim on the top edge of the door at the two sides and push inwards to release the clip seal. To clean the oven, remove the shelf supports. 1 1. Pull the front of the shelf support away from the side wall. 2 1 2. Pull the rear end of the shelf support away from the side wall and remove it. 3. Pull the door trim to the front to remove it. 4. Remove the glass panels. To install panels, do the same steps in reverse. 11.
ENGLISH To replace the glass panels, do the same steps in reverse. Before you lower the trim, attach the A trim part to the door. Refer to the graphic. 1. Deactivate the appliance. 2. Remove the fuses from the fuse box or deactivate the circuit breaker. The back lamp The lamp glass cover is at the back of the cavity. 11.7 Replacing the lamp Put a cloth on the bottom of the interior of the appliance. It prevents damage to the lamp glass cover and the cavity.
www.electrolux.com Problem Possible cause Remedy Steam and condensation You left the dish in the oven Do not leave the dishes in settle on the food and in the for too long. the oven for longer than 15 cavity of the oven. - 20 minutes after the cooking process ends. 12.2 Service data If you cannot find a solution to the problem yourself, contact your dealer or an Authorised Service Centre. the front frame of the appliance cavity. Do not remove the rating plate from the appliance cavity.
ENGLISH 13.3 Levelling of the appliance 23 • The recommended cross-section area is six square millimetres (6 mm²). • When you refit the mains terminal cover, make sure that the lower tabs are located inside the bottom edge of the aperture, before you fix the two screws into the top edge of the mains terminal cover. • Make sure that the cover is securely fastened. Use small feet on the bottom of appliance to set the appliance top surface level with other surfaces.
867307059-A-072014 www.electrolux.
