User manual Canopy rangehood ERCE9025BK ERCE9025SA ERCE9025BA
WE’RE THINKING OF YOU hank you for purchasing an Electrolux appliance. T You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time. Welcome to Electrolux.
IMPORTANT SAFETY INSTRUCTIONS This manual explains the proper use of your new Electrolux rangehood. Please read this manual carefully before using the product. This manual should be kept in a safe place for handy reference. This rangehood is a domestic appliance which has been manufactured and tested to comply with Australian and New Zealand Standard AS/NZS 60335.2.31.
PRODUCT DESCRIPTION 1 1 2 2 3 4 5 6 7 8 Screws x 4 Telescopic flue cover set Flexible flue pipe Upper flue cover mounting bracket Lower flue cover mounting bracket Flue transition duct Main body and fan housing assembly Grease filters 3 4 5 6 7 7 Additional items required for installation • • • Fixings required to attach rangehood body and anti-tilt points. Fixings required to attach flue cover mounting brackets to the wall. Duct tape or cable ties.
DIMENSIONS 290mm 320mm 550mm 1090mm (maximum) 235mm 55mm 900mm 500mm ø150mm NOTE: The fan housing flue transition duct is 150mm in diameter. (See page 10 for optional ducting accessories).
RANGEHOOD INSTALLATION 1. Using a spirit level mark a vertical centre line on the wall where the rangehood is to be positioned, and a horizontal line at the base position (refer Fig. A). NOTE: The height of the underside of the rangehood body must be a minimum of 650mm* to a maximum height of 800mm. 3. Install flue cover wall mounting brackets with suitable fixings. Install suitable screws for rangehood mounting points (to support a total weight of 30kg) to the wall as marked (Fig. B).
Depending on the preferred installation/ducting mode, follow step 6a or 6b below. 6a. Recirculating mode (Fig. D). Using the centre line, secure the recirculating T-piece to the wall with suitable screws/fixings (optional kit AR610RK). Install flexible pipe between T-piece and the exhaust transition duct. Use cable ties or suitable duct tape to secure flexible pipe to T-piece and transition duct (Fig. F).
FLUE COVER INSTALLATION Separate the inner and outer flue covers, and carefully remove the protective coating from both. Carefully reassemble the upper and lower flue covers sections by sliding the inner into the outer flue cover. Carefully lower the assembled upper and lower flue covers onto the top of the rangehood body, and insert the flue cover in approximately 5mm. Fix upper flue cover to the wall mounting bracket with screws supplied. Ensure that the upper section is extended.
USING THE RANGEHOOD Touch control operation Stainless steel surface Clean stainless steel surfaces using non-abrasive cleaning products that are specifically for use on stainless steel. To ensure best results also use an even pressure and follow the grain of the stainless steel. Use of a soft cloth reduces the risk of scratching. If the cloth is wet ensure that a dry soft cloth is used to wipe down the surface again reducing the risk of any surface rust appearing.
OPTIONAL DUCTING ACCESSORIES AR150RC AR150F AR610FS AR150W AR610RK AR610CF Part Numbers Description AR150RC 150mm G/Bond roof cowl AR150F 150mm G/Bond flue 1200mm AR150WV 150mm Wall vent + flexi duct AR610RK Recirculating kit (tee piece and carbon filter) AR610CF Replacement carbon filter AR610FS Stainless steel exhaust cover extension 1200mm NOTE: Accessories are to be purchased separately.
Warranty FOR SALES IN AUSTRALIA AND NEW ZEALAND APPLIANCE: RANGEHOOD This document sets out the terms and conditions of the product warranties for Electrolux Appliances. It is an important document. Please keep it with your proof of purchase documents in a safe place for future reference should you require service for your Appliance. 1.
Electrolux Home Products Australia telephone: 1300 363 640 fax: 1800 350 067 email: customercare@electrolux.com.au web: www.electrolux.com.au Electrolux Home Products New Zealand telephone: 0800 234 234 fax: 0800 363 600 email: customercare@electrolux.co.nz web: www.electrolux.co.nz The Thoughtful Design Innovator.
