QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Overview The ML350 Gen9 is the 2P premium server which delivers a class-leading combination of performance, availability, expandability, manageability, reliability and serviceability making it the choice for remote offices, growing businesses and data centers. Front view details for Rack (SFF) and Tower (LFF) 1. Optional HDD cage Drive Cage Bays (Rack shown with blanks. Tower shown with 16 LFF Optional drives) 2.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Overview Rear View (Tower Model) 1. Power supply Power LED 2. Power supply Power connection 3. HP Flexible Slot 4 Power Supply (Optional - 500w Power Supply shown) 4. Power supply Power LED 5. Power supply Power connection 6. HP Flexible Slot 3 Power Supply (Optional - 500w Power Supply shown) 7. Power supply Power LED 8. Power supply Power connection 9. HP Flexible Slot 2 Power Supply (Optional - 500w Power Supply shown) 10. Power supply Power LED 11.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Overview Interior View (Rack Model) 1. System fans: Three (3) fans are standard Optional Five (5) systems fans are shown. 2. Twenty four DIMM slots: DDR4 Registered (RDIMM) or Load Reduced Registered (LRDIMM) memory 3. Nine (9) PCIe expansion slots (8 PCIe Gen3 and 1 PCIe Gen2) 4. Two (2) processors and heatsinks (Second Processor is Optional) 5. Optional HP Flexible Smart Array or Smart HBA (not shown here) 6.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Standard Features NOTE: For more information regarding Intel Xeon processors, please see the following : http://www.intel.com/xeon Intel® Xeon® processor E5-2600 v3 product family is designed to deliver the best combination of performance, built-in capabilities, and cost-effectiveness.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Standard Features Memory One of the following depending on Model Type HP SmartMemory DDR4 Registered (RDIMM) or Load Reduced (LRDIMM) DIMM Slots Available 24 (12 DIMM slots per processor, 4 channels per processor, 3 DIMMs per channel) Maximum Capacity 768GB (24 x 32GB LRDIMM @2133MHz) (LRDIMM) Maximum Capacity 384GB (24 x 16GB RDIMM @2133MHz) (RDIMM) NOTE: 64GB LRDIMMs, feature support to be available on March 2015.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Standard Features Internal Storage Devices Optical Drives One of the following depending on model Hard Drives Hard Drive Bays Maximum Internal Storage One of the following depending on model Power Supply One of the following depending on model Hot Plug LFF SAS Hot Plug LFF SATA Hot Plug SFF SAS Hot Plug SFF SATA Hot Plug SFF SATA SSD Hot Plug SFF SAS SSD Hot Plug LFF SATA SSD Optional SATA 9.5mm DVD-ROM Optical Drive Optional SATA 9.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Standard Features Interfaces Serial 1 Video 1 (rear) Network RJ-45 (Ethernet) 4 HP iLO Remote Management Network Port 1 Gb Dedicated SD Slot 1 (internal) NOTE: The Micro-SD slot is not a hot-pluggable device. Customers should not attempt to plug an MicroSD card into the Micro-SD slot while the server is powered. USB 2.0 Ports 5 (2 front, 2 rear, 1 internal) USB 3.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Standard Features Graphics 16 bit color: maximum resolution of 1600 x 1200 Integrated Matrox G200 video standard 32 bit color: maximum resolution of 1280 x 1024 16 MB Flash 256 MB DDR3 HP Server UEFI/Legacy ROM HP Server UEFI /Legacy ROM Unified Extensible Firmware Interface (UEFI) is an industry standard that provides better manageability and more secured configuration while interacting with your server at boot time.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Standard Features Server utilities HP Smart Update Optimize firmware and driver updates with HP Smart Update solutions. Learn more at http://www.hp.com/go/smartupdate. HP Systems Insight Manager (HP SIM) HP SIM allows you to monitor the health of your HP ProLiant Servers and HP Integrity Servers, and also provides you with basic support for non-HP servers. HP SIM also integrates with HP SUM to provide quick and seemless firmware updates.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Standard Features Warranty This product is covered by a global limited warranty and supported by HP Services and a worldwide network of HP Authorized Channel Partners resellers. Hardware diagnostic support and repair is available for three years from date of purchase. Support for software and initial setup is available for 90 days from date of purchase.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Optional Features Embedded Management iLO Advanced HP iLO Advanced licenses offer smart remote functionality without compromise, for all HP ProLiant servers. The license includes the full integrated remote console, virtual keyboard, video, and mouse (KVM), multiuser collaboration, console record and replay, and GUI-based and scripted virtual media and virtual folders. You can also activate the enhanced security and power management functionality.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Optional Features HPC Interconnects NOTE: High Performance Computing (HPC) interconnect technologies are available for this server under the HP Cluster Platform product portfolio. These high-speed interconnects are fully supported by HP when they are part of these configure to order clusters. Solutions can be defined with a lot of flexibility with the help of configuration tools.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Service and Support Service and Support HP Technology Services for Industry Standard Servers HP Technology Services delivers confidence, reduces risk and helps customers realize agility and stability. Connect to HP to help prevent problems and solve issues faster. Our support technology lets you to tap into the knowledge of millions of devices and thousands of experts to stay informed and in control, anywhere, any time.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Service and Support Get connected to HP to improve your support experience Prevent problems with innovative, automated monitoring tools and proactive services. Combining Proactive Care Services with our remote support technology such as Insight Online provides you with expert advice and personalized, cloud-based automated IT support, helping to prevent unplanned down time and solve problems quickly. For more information, visit: http://www.hp.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Pre-configured Models For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information - Factory Integrated Models" section. 1. Pre-configured models ship with the configurations below. Options can be selected from the Core or Additional options section of this QuickSpecs. 2. HP does not allow factory integration of options into pre-configured models. Any additional options purchased will be shipped separately.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Pre-configured Models [SKU Number] Model Name Processor Number of Processors Memory Network Controller Storage Controller Hard Drive Internal Storage Optical Drive Bay Optical Drive PCI-Express Slots Power Supply Fans Management Energy Star Accessories Form Factor Warranty Country Code Key Energy Star Models Performance Models 765821-xx1 765822-xx1 HP ProLiant ML350 Gen9 2xE5-2630v3 2P 32GB-R HP ProLiant ML350 Gen9 2xE5-2650v3 2P 32GB-R P440ar 8SFF 2x800W
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Configuration Information - Factory Integrated Models This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for information on configurable product offerings and requirements. 1. Factory Integrated Models must start with a CTO Server. 2.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Configuration Information - Factory Integrated Models HP Power Supplies Memory Configuration Tool at: http://www.hp.com/go/ddr4config Select one or more power supplies from Core Options-Power Supplies section below: Prior to selecting a power supply option, it is highly recommended that you review your server configuration in the HP Power Advisor tool to determine the right size power supply for your server configuration.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Configuration Information - Factory Integrated Models To assist in the installation of the server into the rack, an optional installation tool is available by contacting your local services representative (p/n 695539-001). See HP Rack Options in Additional Options section of this QuickSpecs for more rack kit choices. Caution: HP recommends that a minimum of two people are required for all Rack Server installations.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Core Options NOTE: Some options may not be integrated at the factory. To ensure only valid configurations are ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for additional information. HP Unique Options HP Processors HP ML350 Gen9 8SFF Hard Drive Cage Kit NOTE: Add'l 8SFF Hard Drive Cage, allowing for up 48SFF Drive Bays.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Core Options HP ML350 Gen9 Intel® Xeon® E5-2640v3 (2.6GHz/8-core/20MB/90W) FIO Processor Kit HP ML350 Gen9 Intel® Xeon® E5-2630v3 (2.4GHz/8-core/20MB/85W) Processor Kit HP ML350 Gen9 Intel® Xeon® E5-2630v3 (2.4GHz/8-core/20MB/85W) FIO Processor Kit HP ML350 Gen9 Intel® Xeon® E5-2620v3 (2.4GHz/6-core/15MB/85W) Processor Kit HP ML350 Gen9 Intel® Xeon® E5-2620v3 (2.4GHz/6-core/15MB/85W) FIO Processor Kit HP ML350 Gen9 Intel® Xeon® E5-2630Lv3 (1.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Core Options HP ML350 Gen9 Intel® Xeon® E5-2683v3 (2GHz/14-core/35MB/120W) FIO Processor Kit HP ML350 Gen9 Intel® Xeon® E5-2699v3 (2.3GHz/18-core/45MB/145W) Processor Kit HP ML350 Gen9 Intel® Xeon® E5-2699v3 (2.3GHz/18-core/45MB/145W) FIO Processor Kit HP ML350 Gen9 Intel® Xeon® E5-2698v3 (2.3GHz/16-core/40MB/135W) Processor Kit HP ML350 Gen9 Intel® Xeon® E5-2698v3 (2.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Core Options HP 3TB 6G SAS 7.2K rpm LFF (3.5-inch) SC Midline 1yr Warranty Hard Drive HP 2TB 6G SAS 7.2K rpm LFF (3.5-inch) SC Midline 1yr Warranty Hard Drive HP 1TB 6G SAS 7.2K rpm LFF (3.5-inch) SC Midline 1yr Warranty Hard Drive SATA Hot Plug SFF (2.5-inch) Midline (MDL) Drives 652766-B21 652757-B21 652753-B21 HP 1TB 6G SATA 7.2K rpm SFF (2.5-inch) SC Midline 1yr Warranty Hard Drive HP 500GB 6G SATA 7.2K rpm SFF (2.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Core Options 6G SATA Hot Plug SFF (2.5-inch) Enterprise Value Solid State Drives HP 800GB 6G SATA Value Endurance SFF 2.5-in SC Enterprise Value 3yr Wty Solid State Drive HP 600GB 6G SATA Value Endurance SFF 2.5-in SC Enterprise Value 3yr Wty Solid State Drive HP 480GB 6G SATA Value Endurance SFF 2.5-in SC Enterprise Value 3yr Wty Solid State Drive HP 300GB 6G SATA Value Endurance SFF 2.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Core Options HP 600GB 6G SATA Value Endurance LFF 3.5-in SC Converter Enterprise Value 3yr Wty Solid State Drive HP 480GB 6G SATA Value Endurance LFF 3.5-in SC Enterprise Value 3yr Wty Solid State Drive HP 300GB 6G SATA Value Endurance LFF 3.5-in SC Converter Enterprise Value 3yr Wty Solid State Drive HP 240GB 6G SATA Value Endurance LFF 3.5-in SC Enterprise Value 3yr Wty Solid State Drive HP 1.6TB 6G SATA Value Endurance LFF 3.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Core Options HP Power Supplies HP Computation and Graphics Accelerators HP Flex Slot Platinum Hot-plug Power supplies HP 500W Flex Slot Platinum Hot Plug Power Supply Kit 720478-B21 HP 800W Flex Slot Platinum Hot Plug Power Supply Kit HP 1400W Flex Slot Platinum Plus Hot Plug Power Supply Kit HP ML350 Gen9 X4 Redundant Power Supply Enablement FIO Kit NOTE: The x4 Redundant Power Supply Enablement (RPS) Kit only supports the HP 800 W and HP 1400 W Flex Sl
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Additional Options NOTE: Some options may not be integrated at the factory. To ensure only valid configurations are ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for additional information.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Additional Options HP PCIe Workload Accelerator Options Value Endurance (VE) PCIe Workload Accelerators HP 6.4TB FH/HL Value Endurance (VE) PCIe Workload Accelerator HP 3.2TB HH/HL Value Endurance (VE) PCIe Workload Accelerator HP 1.6TB HH/HL Value Endurance (VE) PCIe Workload Accelerator HP 1.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Additional Options HP Tape Backup HP H240ar 12Gb 2-ports Int FIO Smart Host Bus Adapter NOTE: Provides support for up to 8 internal SAS/SATA drives without using a PCIe slot. NOTE: FIO indicates factory integrated option via CTO.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Additional Options HP StoreEver MSL6480 Scalable Expansion Module NOTE: Please see the QuickSpecs for Technical Specifications and additional information: http://h18000.www1.hp.com/products/quickspecs/14604_div/14604_div.html (Worldwide).
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Additional Options HP Data Center Racks HP 11000 G2 Series Racks HP 11648 1075mm Pallet Universal Rack H6J87A HP 11648 1075mm Shock Universal Rack H6J88A HP 11642 1075mm Pallet Universal Rack H6J65A HP 11642 1075mm Shock Universal Rack H6J66A HP 11642 1200mm Pallet Universal Rack H6J67A HP 11642 1200mm Shock Universal Rack H6J68A HP 11636 1075mm Pallet Universal Rack H6J77A HP 11636 1075mm Shock Universal Rack H6J78A HP 11622 G2 1075mm Pallet Universal Rack
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Additional Options HP Power Distribution Units (PDUs) HP Basic Power Distribution Unit (bPDU) HP 4.9kVA 24A High Voltage NA/JP Core Modular Power Distribution Unit 252663-D74 HP 8.3kVA 40A High Voltage NA/JP Core Modular Power Distribution Unit 252663-D75 HP 7.3kVA 32A High Voltage INTL Core Modular Power Distribution Unit 252663-B33 HP 17.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Additional Options HP ML350 Gen9 5U FIO Rail Kit NOTE: Rack CTO server only 790357-B21 HP ML350 Gen9 Tower to Rack Conversion Kit HP Rack Mount Consoles HP TFT7600 G2 KVM Console Rackmount Keyboard US Monitor HP TFT7600 G2 KVM Console Rackmount Keyboard Intl Monitor HP TFT7600 G2 KVM Console Rackmount Keyboard DE Monitor HP TFT7600 G2 KVM Console Rackmount Keyboard UK Monitor NOTE: Please see the HP Rack Console QuickSpecs for information on additional opt
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Additional Options HP Uninterruptible Power HP Tower UPS Systems (UPS) HP T750J JP Uninterruptible Power System HP T1000 G3 1000VA INTL Tower Uninterruptible Power System HP T1500 G3 1400VA NA Tower Uninterruptible Power System HP T1500 G3 1400VA INTL Tower Uninterruptible Power System HP T1000 G3 1000VA NA Tower Uninterruptible Power System HP T1000J JP Uninterruptible Power System HP T1500J JP Uninterruptible Power System HP Rack-mountable UPS HP R1.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Memory Memory Subsystem Architecture Each Intel® Xeon® E5-2600v3 family processor socket contains four memory channels per installed processor with three DIMMs per channel for a total of twelve (12) DIMMs or a grand total of twenty-four (24) DIMMs for the server. Memory Population guidelines General Memory Population Rules and Guidelines: Install DIMMs only if the corresponding processor is installed.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Memory There are four (4) channels per processor; eight (8) channels per server There are three (3) DIMM slots for each memory channel; twenty-four (24) total slots Memory channels1 and 3 consists of the three (3) DIMMs that are furthest from the processor Memory channel 2 and 4 consists of the three (3) DIMMs that are closest to the processor Intel Gen9 Supported Memory Bandwidth for HP ProLiant Gen8 Intel® Xeon®E5-2600v3 Series Processor Family Memory Band
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Memory Memory Speed by Processor Model Processor Models Supported Memory Speeds E5-2609v3, E5-2603v3, 1600MHz E5-2640v3, E5-2630v3, E5-2620v3, E5-2630Lv3, E5-1866MHz 2623v3, E5-2637v3, E5-2690v3, E5-2680v3, E5-2670v3, E5-2133MHz 2660v3, E5-2650v3, E5-2650Lv3, E5-2697v3, E52695v3, E5-2667v3, E5-2643v3, E5-2683v3, E52699v3, E5-2698v3, Standard and Maximum Pre-Configured Models Memory Capacity (Preconfigured Models) Standard Memory E5-2609v3, 8GB (1x8GB) E5
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Storage 48 SFF hot-plug drive model A Optional Slim DVD-ROM/DVD-RW 1-8 8 x SFF SATA/SAS/SSD Hot Pluggable Hard Drive Bays A Optional Slim DVD-ROM/DVD-RW 1-8 8 x LFF SATA/SAS/SSD Hot Pluggable Hard Drive Bays 24 LFF hot-plug drive model DA - 15035 Worldwide QuickSpecs — Version 4 — 12.1.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Technical Specifications System Unit Tower Dimensions 18.27 x 8.62 x 30.28 in (46.4 x 21.9 x 76.9 cm) Rack Dimensions 8.58 x 17.51 x 29.37 in (21.8 x 44.5 x 74.6 cm) Tower Weight Minimum: Maximum: Minimum: 66.14lb(30kg) 121.30lb (55kg) 57.3lb(26kg) Maximum: Range Line Voltage 112.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Technical Specifications altitude derating of 1.0°C per every 125 m (1.8°F per every 410 ft) above 900 m (2953 ft) to a maximum of 3050 m (10,000 ft). The approved hardware configurations for this system are listed at the URL: http://www.hp.com/servers/ashrae. Extended Ambient Operating Support Non-operating Relative Humidity Altitude Acoustic Noise -30° to 60°C (-22° to 140°F). Maximum rate of change is 20°C/hr (36°F/hr).
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Technical Specifications HP Dynamic Smart Array B140i Controller (EMC) Normative Standards Number of PCI links Four PCI link rate 4 Gb/s Storage protocol suppor SATA SAS/SATA peak data transfer rate 6 Gb/s CISPR 22; EN55022; EN55024; FCC CFR 47, Pt 15; ICES-003; CNS13438; GB9254; K22;K24; EN 61000-3-2; EN 61000-3-3; EN 60950-1; IEC 60950-1 NOTE: Product conformance to cited product specifications is based on sample (type) testing, evaluation, or
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Technical Specifications Environment-friendly Products and Approach End-of-life Management and Recycling Hewlett-Packard offers end-of-life HP product return, trade-in, and recycling programs in many geographic areas. For trade-in information, please go to: http://www.hp.com/go/green. To recycle your product, please go to: http://www.hp.com/go/green or contact your nearest HP sales office.
QuickSpecs HP ProLiant ML350 Generation9 (Gen9) Summary of Changes Date 12/1/2014 10/13/2014 Version History From Version 3 to 4 From Version 2 to 3 Action Changed Added Changed 9/23/2014 From Version 1 to 2 Changed Description of Change Changes made throughout the QuickSpecs. 6G SATA Enterprise Value G1 Solid State Drives were added to Core Option section.
