FRIDGE/FREEZER MODEL NO. EBD 900 MODEL No. PART NO.
IMPORTANT SAFETY INFORMATION It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is left with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant safety information. This information has been provided in the interest of safety.
CONTENTS Important Safety Information 2 Maintenance and Cleaning 12 Description of the appliance 4 Internal cleaning 12 Electrical Requirements 5 External cleaning 12 Installation When the appliance is not in use 12 6 Changing the light bulb 12 Positioning 6 Defrosting 12 Rear spacers 6 Something Not Working 14 Door Reversal 7 Operation 8 How to obtain after sales service quickly 15 Before use 8 Technical Specifications 16 Setting the temperature 8 The freezer compartme
DESCRIPTION OF THE APPLIANCE D E F G H I A- Dairy compartment B- Can storage shelves C- Bottle storage shelf D- Thermostat control for fridge and freezer compartments E- Wire shelves F- Glass shelf G- Salad drawers H- Freezing/storage compartment I- Frozen food storage 4 A B C
ELECTRICAL REQUIREMENTS Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. DIMENSIONS Height 165.9 Before switching on, make sure the electricity supply voltage is the same as that indicated on the appliance rating plate. cm Width 49.5 cm Depth 60 cm POWER SUPPLY VOLTAGE AND FREQUENCY 220-240 V / 50 Hz TOTAL POWER ABSORBED 150 W AVERAGE DAILY UNITS ELECTRICITY * 1.
GUARANTEE INSTALLATION This guarantee is offered to you as an extra benefit and does not affect your Iegal rights. Warning IF YOU ARE DISCARDING AN OLD APPLIANCE THAT HAS A LOCK OR CATCH ON THE DOOR, YOU MUST ENSURE THAT IT IS MADE UNUSABLE TO PREVENT YOUNG CHILDREN BEING TRAPPED INSIDE. Depending upon the position which you choose for your appliance, you may wish to reverse the way in which the door opens. To do this, refer to instructions on ÒDoor reversal directionsÓ paragraph.
SOMETHING NOT WORKING Important: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation a charge will be made, even if the appliance is under guarantee. Before contacting your local Service Centre, check the following points: Symptom Solution No power to the appliance Check there is power at the socket. Check there is not a power cut by checking the household lights. Check the fuse has not blown. The light does not come on 2.
OPERATION Before using Remove all securing tapes. Wash inside the appliance with lukewarm water and bicarbonate of soda (5 ml to 0.5 litre of water). Remember to wash the defrost cleaner in hot soapy water at regular intervals. Dry throughly before replacing. No damage can be caused by leaving the switch in this position for any period of time. However should the temperature rise above 16¡C remember to turn the switch off again. Do not use soap or detergent as the smell may linger. Dry thoroughly.
MAINTENANCE AND CLEANING Before any maintenance or cleaning work is carried out, DISCONNECT the appliance from the ELECTRICITY supply. Internal cleaning Changing the light bulb Should the interior light fail to work, first switch off the appliance and disconnect from the electricity supply, then replace the bulb as follows; An accumulation of dust will affect the performance of the appliance and cause excessive electricity consumption. You MUST ensure that the appliance is switched OFF.
HEALTH AND SAFETY GUIDELINES Movable shelves The walls of the refrigerator have runners so that shelves can be positioned as desired. Because of consumer demand, preservatives have been removed from many pre-prepared foods. This together with the changes in shopping habits to a once-a-week shop, mean that safe handling and storage of food is even more important than ever. The following tips should help you to ensure that the food in your home is in as perfect condition as possible.
