Rev042314 EA www.elitescreens.com 1

Lunette Series

Home Theater Curved Fixed Frame Projection Screen

User’s Guide

Important Safety and Warning Precautions

Please follow these instructions carefully to ensure proper maintenance and safety with your Lunette

Series Fixed Frame Curved Screen

1. When hanging the screen up, please make sure that no other objects – such as power switches, outlets,

furniture, ladders, windows, etc., occupy the space designated for your Fixed-Frame screen.

2. Regardless if the screen is hung on or installed into the wall, make sure that the proper mounting anchors

are used and that the weight is supported appropriately by a strong and structurally sound surface just as

any large and heavy picture frame should.

(Please consult a home improvement specialist for the best advice on installation.)

3. Frame parts are made of high quality velour-surfaced aluminum and should be handled with care.

4. When not in use, cover over the screen with a furniture sheet to protect it from dirt, grime, paint, or any

other impurities.

5. When cleaning, use a soft cloth moistened with warm water to remove any marks on the frame or

screen surface.

6. Never attempt to use any solutions, chemicals, or abrasive cleaners on the screen surface.

7. In order to avoid damaging the screen, avoid touching it directly with your fingers, writing

stationary, tools, or any other sharp or abrasive objects.

8. Spare parts should be placed out of reach of small children in accordance with household safety guidelines.

CAUTION:

The projection screen frame is made of high-quality aluminum alloy and should be handled with

care.

Use a soft cloth with warm water to remove any spots on the screen material surface.

To avoid damaging the screen material, never attempt to use any solutions, chemicals, or

abrasive cleaners on the screen itself, and never attempt to touch screen with your fingers or

sharps/abrasive objects.

Summary of content (9 pages)

PAGE 1
Lunette Series Home Theater Curved Fixed Frame Projection Screen User’s Guide Important Safety and Warning Precautions Please follow these instructions carefully to ensure proper maintenance and safety with your Lunette Series Fixed Frame Curved Screen 1. When hanging the screen up, please make sure that no other objects – such as power switches, outlets, furniture, ladders, windows, etc., occupy the space designated for your Fixed-Frame screen. 2.
PAGE 2
Hardware and Parts List A. Dry-wall anchor B. 1.77” L-Bracket G. Fix Plate K. Butterfly Screw C. 3.54” L-Bracket J. Elbow Joint D. Lower bracket E. M5 Screw F. Wood screw H. Center Support Bar Note: Center support bar may be packed in a plastic tube with the screen material. L. Tension Rods M. Screen Material N. Vertical Upright Frame O. Horizontal Curved Frame Rev042314 EA www.elitescreens.
PAGE 3
Frame Assembly 1. Insert both Elbow Joints (J) into each Horizontal Curved Frame (N) and join all four frame parts together as shown below. 2. After making sure that all four corners join at right angles (forming a perfect rectangle), fasten the four angles together by using x8 M5 screws (E). Minimal gap is normal here 3. Layout the Screen Material and Tension Rods on a clean and dry surface. Then, gently roll out the screen material over the back of the fixed frame.
PAGE 4
. Insert Tension Rods through the sleeves. The longer rods are used on the horizontal edges of the screen material, and the shorter rods are used on the vertical edges, as seen below. 5. Slip the screen tension rods into the grooves running along the back of the frame. Clip on the Fix Plates to the back of the frame to secure the rods into place forming a tight and flat surface. See Attaching the Fix Plates section below for details. Tension Rod Fix Plate Viewing Surface Rev042314 EA www.
PAGE 5
Black backing for AcousticPro models This procedure only applies to AcousticPro models. Disregard this section if your Fixed Frame does not include an acoustic transparent screen material. The purpose of the black backing material is to block out any light penetration that may reflect off of anything mounted behind the screen, which can cause distortion to the projected image. The black backing is held in place by the Velcro that is on the fix plates.
PAGE 6
Attaching the Fix Plates 1. Make sure that the material and frame are both lying face down on a clean, dry, and nonabrasive surface. 2. Center the material inside the frame. Please note the material will be noticeably smaller than the frame, as the material must be stretched to create a sufficient amount of tension for perfect material flatness. 3.
PAGE 7
Center Support Bar 1. Center Support Bar may be packed in a plastic tube with the screen material. Center support bar 支 2. 撑 Insert the Center Support Bar into the upper top groove on the back of the frame (note: this not the same groove where the fix plate inserts) with the bottom end near the center point of the frame, and place it in at an angle so that both ends of the bar are aligned with the groove. 3.
PAGE 8
Installation 1. Use butterfly screws to install the upper bracket as shown in diagram: Use butterfly screws to assemble a 1.77” L-Bracket and a 3.54”L-Bracket into an upper bracket 2. Locate the height where you want to set up, and draw an upper base line. Confirm the distance between the two brackets on the level direction following E on the diagram below. Mark the hole location on the wall by following the base line and the upper bracket’s screw hole site, and then drill the hole.
PAGE 9
4. Place the upper frame on the upper brackets, and gently pull the frame down onto the bracket. The lower bracket will also slide into the groove of the lower frame. Upper base line Lower base line 5. Mounting the frame to the brackets will finish your installation. Installation diagram of frame and bracket Base line Swing the bottom bracket to the left or right to fit it in the groove of the lower frame. Note: Two (2) or more people must install the frame for added safety. Rev042314 EA www.
