i
Preface Copyright 2009 All Rights Reserved. The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
Reorient or relocate the receiving antenna Increase the separation between the equipment and receiver Connect the equipment into an outlet on a circuit different from that to which the receiver is connected Consult the dealer or an experienced radio TV technician for help This device complies with Part 15 of the FCC Rules.
Table of Content BEFORE YOU START ............................................................................... 2 LET YOUR COMPUTER ACCLIMATE ITSELF .............................................. 9 HEAT, COLD, HUMIDITY, AND GLARE .................................................... 9 SUITABLE PLACE TO WORK ................................................................. 10 INTRODUCTION...................................................................................... 12 FRONT VIEW ....................
NO SPEAKER OUTPUT ........................................................................ 67 SOUND CANNOT BE RECORDED .......................................................... 67 THE HARD DISK DRIVE DOES NOT WORK OR IS NOT RECOGNIZABLE ....... 68 THE HARD DRIVE IS MAKING ABNORMAL WHINING NOISES ..................... 68 THE HARD DISK DRIVE HAS REACHED ITS CAPACITY ............................. 68 THE HARD DISK TAKES LONGER TO READ A FILE ................................... 69 THE FILES ARE CORRUPTED ......
1
Before you Start Conventions of This Manual Use this manual will help you get the most from your notebook computer. If you are an experienced user of computers and/or Microsoft’s Windows operating systems, you might find it useful to read the Quick Start Guide that comes along with your accessories. If you are a less experienced user, you should through the manual carefully before using your system.
7. 8. 9. 10. 11. 12. 13. 14. 15. 16. 17. Make sure to use the right voltage for the power source when connecting the equipment to the power outlet. Place the power cord in such a way that people can not step on it. Do not place anything on top of the power cord. All cautions and warnings on the equipment should be noted. If the equipment is not use for a long time, disconnect the equipment from the main power outlet to avoid being damaged by transient overvoltage.
The minimum specifications for the flexible cord are No. 18 AWG, (2) Type SPT-2, and (3) 2-conductor. B. For Japan: All components of the cord set must bear a “PSE” mark and in accordance with the Japanese Dentori Law. The minimum specifications for the flexible cord are .75m ㎡ conductors, (2) Type VCTR or VCTFK, and (3) 2-conductor. The cord set must have minimum rated current capacity of 7 A.
Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may explode. Check with local codes for possible special instructions. 19. Do not use the AC adapter near open water or other liquids. Never spill liquid into the AC adapter. 20. Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions.
Class 1 Laser Product Appareil A Laser De Classe 1 Laserschutzklasse 1 Produkt Do not attempt to disassemble the cabinet containing the laser. The laser beam used in this product is harmful to the eyes. The use of optical instruments, such as magnifying lenses, with this product increase the potential hazard to your eyes. For your safety, have this equipment serviced only by an authorized service provider. Wichtige Sicherheitshinweise 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13.
14. 15. 16. 17. Stromnetz zu trennen und von einer qualifizierten Servicestelle zu Überprüfung.: a. Netzlabel oder Netzstecker sind beschädigt. b. Flüssigkeit ist in das Gerät eingedrungen. c. Das Gerät war Feuchtigkeit ausgesetzt. d. Wenn das Gerät nicht der Bedienungsanleitung entsprechend funktioniert oder Sie mit Hilfe dieser Anleitung keine Verbesserung erzielen. e. Das Gerät ist gefallen und/oder das Gehäuse ist beschädigt. f. Wenn das Gerät deutliche Anzeichen eines Defektes aufweist.
Die Minimalanforderungen für das Kabel sind .75m ㎡ Leiter. (2) Type VCTF oder VCTFK, und (3) 2conductor. Der Kabelsatz muss mindestens für eine Stromstärke von 7A geeignet sein. Der Wandstecker muss ein zweipoliger geerdeter Steckertyp gemäß dem Japanese Industrial Standard C8303 (15A, 125 VAC) sein. C. Für andere Länder: Die Zubehörteile des Kabel-Sets müssen das Prüfsiegel derjenigen Stelle, die in dem jeweiligen Land für die Sicherheitsprüfung zuständig ist, tragen.
19. Benutzen Sie das Netzteil nicht in unmittelbarer Nähe zu Wasser oder anderen Flüssigkeiten. Gießen Sie nie Flüssigkeiten über das Netzteil. 20. Es besteht Explosionsgefahr, wenn der Akku nicht ordnungsgemäß ersetzt wird. Ersetzen Sie den Akku nur durch einen Akku gleichen oder äquivalenten Typs, der vom Hersteller empfohlen wird. Entsorgen Sie Akkus entsprechend den Anweisungen des Herstellers.
Suitable place to work Your computer will run well wherever you’re comfortable but extremes of temperature and humidity can be challenging to your system’s parts. There are some things you can tolerate that the computer can’t – things like static electricity, dust, water, steam and oil. In case you decide to pull over for roadside computing, try to choose a clean, comfortable work area for your system. A lithium-ion battery pack will be available when you are traveling.
11
Introduction Preparing your Computer 1. 2. 3. 4. Install the battery pack Connecting the AC adapter Opening the display panel Turning on your computer Knowing your Computer With the LCD screen open, you will see several features important for operating your notebook computer.
To avoid damage to the display panel: 1. Try not to slam the display upon closing it. 2. Try not to place any object on top when it is closed or open. 3. Be sure the system is turned off or in suspend mode before you close the display panel. Front View 1. 2. Camera Button (Optional) LCD Display This LCD panel can only support up to a maximum opening of 115-120 degrees, please do not push it forcibly.
3. 4. Power / Suspend Button Press for 1~1.5 seconds to turn on the system. Press and hold for at least 4 seconds to turn off the system. Press the power / suspend button again to return from the suspend mode. Keyboard 5. The keyboard differs for each territory Multi Media Buttons (Optional) 1. 2. 3. 4. 5. 6. 7. 8. 6. 7. 8.
Left Views 1. 2. DC In Modem Port (Optional) Always disconnect all telephone lines from the wall outlet before servicing or disassembling this equipment. To reduce the risk of fire use only No. 26 AWG or larger telecommunication line cord. USB 2.0 Port 3. 4. Kensington Lock 5.
System & Power Status Indicators LED Graphic Symbol Indication Blue light indicates the system is ON. Blue light indicates the RF (WLAN/Bluetooth) is active. Battery status Charging – Blue Full – Blue Low - Red Blue light indicates the hard drive and/or optical drive is being accessed. Right View 1.
2. Enhanced USB 2.0 Port This strengthen USB power sourse for the USB port, the function lets users when using any other major big power consumption USB device in avoiding creating any harm to the USB port. When using any External USB Device, only use the approve cable provided by the manufacturer. Using other cable where it affect the current flow will cause undetermined damage. Not suitable to use any 3.5” or 5.25” USB ODD or HDD 3. 4. 5.
2. 3. 4.
19
Getting Started Connecting to a Power Source Connecting the AC Adapter A universal AC adapter is provided to supply your computer with power and also charge the computer’s battery pack. The adapter’s AC input voltage can range anywhere from 100 to 240 volts, covering the standard voltages available in almost every country. To connect the computer to an external power source: Do not use inferior extension cords as this may result in damage to your notebook. The notebook comes with its own AC adapter.
Whenever possible, keep the AC adapter plugged into the notebook and an electrical outlet to recharge the battery. Never turn off or reset your notebook while the hard disk is in use status icon is lit; doing so can result in loss or destruction of your data. Always wait at least 5 seconds after turning off your notebook before turning it back on; turning the power on and off in rapid succession can damage the notebook’s electrical circuitry.
batteries according to the manufacturer’s instructions or local laws. Explisionsgefahr bei unsachgernazen Austausch der Batterie. Ersatz nur durch denselben oder einem vom Hersteller empfohlenem ahnlichen Typ. Entsorgung gebrauchter Batterien navh Angaben des Herstellers.
23
Using the Notebook Computer Adjusting the LCD Screen Display The LCD screen display can be adjusted by the following key combinations. Fn + F4 Fn + F7 Fn + F8 Changes Display Mode: LCD-only, CRT only and simultaneous LCD&CRT. Increases the brightness level. Decreases the brightness level. LCD Care LCD screens are delicate devices that need careful handling. Please pay attention to the following precautions: When you are not using the computer, keep the LCD screen closed to protect it from dust.
the key combination [Fn] + [F4]. The Notebook’s Hot Key Controls Action Fn + F1 Fn + F2 Fn + F3 Fn + F4 Fn + F5 Fn + F6 Fn + F7 Fn + F8 Fn + F9 Fn + F10 Fn + F11 Fn + F12 System Control Enters Suspend Mode. Enters the Silent Mode. Mute/Unmute Audio/ PC beep to Output Changes Display Mode: LCD-only, CRT only and simultaneous LCD&CRT. Increases the speaker volume. Decreases the speaker volume. Increases the brightness level. Decreases the brightness level.
3G On/Off Fn + F12 Brightness Fn + F7/F8 Mute On/Off Fn + F3 Volume Fn + F5/F6 OSD-Bar Icon Caps Locks On Num Locks On Scroll Locks On RF On Web Cam On RF On Mobile Broadband On The OSD bar can be shown on the side bar or you can drag it anywhere either on top (horizontally) or on the sides (vertically) of your screen.
Click on the Live Power icon from the lower right bar of your screen to open up the Live Power Display. The Live Power provides five modes according to the application that you are executing: Power saving mode: Provides the low consumption function, suitable for low utilization ratio and suspend mode. Normal mode: Provides for general work status. High Performance mode: For highest efficiency condition. DVD player mode: Provide for watching movie playback.
LCD Brightness: Level 1 CPU Speed: Level 0 LCD Off: Idle after 5 minutes HDD Off: Idle after 3 minutes Sleep: Idle after 5 minutes Hibernate: Idle after 10 minutes Normal Mode LCD Brightness: Level 5 CPU Speed: Maximum level LCD Off: Idle after 15 minutes High Performance Mode 28 HDD Off: Idle after 30 minutes Sleep: Idle after 1 hour Hibernate: Idle after 2 hours
LCD Brightness: Level 5 CPU Speed: Maximum level LCD Off: Never HDD Off: Never Sleep: Never Hibernate: Never DVD Play Mode LCD Brightness: Level 5 CPU Speed: Maximum level LCD Off: Idle 4 hours HDD Off: Idle after 4 hours Sleep: Idle after 1 hour Hibernate: 2 hours Dynamic Switch Mode 29
CPU Loading Battery life% level 5 level 4 level 3 level 2 level 1 90% up 50% up 30% up 15% up 6% up less level than 0 5% High Middle plus Middle Low 50% up 30% up 4%up <4% High Performance mode High Performance mode High Performance mode High Performance mode High Performance mode High Performance mode Power Saving mode Power Saving mode Power Saving mode Normal mode Normal mode Power Saving mode Power Saving mode Power Saving mode Normal mode Normal mode Normal mode Normal mode Normal m
TouchPad Precautions The TouchPad is a pressure sensitive device. Please take note of the following precautions. Make sure the TouchPad does not come into contact with dirt, liquids or grease. Do not touch the TouchPad if your fingers are dirty. Do not rest heavy objects on the TouchPad or the TouchPad buttons. You can use the TouchPad with Microsoft Windows as well as nonWindows applications.
Removing the Battery Pack To remove the battery pack from its compartment, please refer to Chapter 3, Inserting and Removing the Battery Pack. Preparing the Battery Pack for Use (Battery Calibration) Before using the battery pack for the first time, battery pack should be calibrated in order to get accurate reporting of remaining battery life status.. To calibrate the battery pack follows the instructions below: 1. Insert the battery into the battery compartment and turn on the notebook.
adapter plugged in until the charging LED turns off. Battery Status Windows Vista has an applet in the Control Panel that will display an icon in the Windows taskbar indicating when the notebook is running on battery power or is attached to the AC adapter. This applet also displays a meter that indicates how much charge is remaining in the battery. Battery Low Warning When the pack initially reaches the “Battery Low” state approximately 7 ~ 10 minutes of the usable battery life is left.
Resetting the System After installing a software application package, you may be prompted to reset the system to load the changed operating environment. To reset the system, or “reboot,” press the [Ctrl]+[Alt]+[Delete] keys simultaneously. This is known as “warm boot.” This key combination acts as “software” reset switch when you encounter hardware or software problems, which lock up the notebook.
Desktop Desktop may vary differently on the software installed in your notebook with different or additional shortcuts. Recycle Bin Used for storing deleted files in case you want to recover and save it in your system. The files will only be deleted from the Recycle Bin permanently only if you empty it by right clicking your mouse and select the “Empty Recycle Bin”. Start Button Allows easy access to all Windows programs.
The Start menu allows you to adapt and show the programs used most frequently. If you wish to keep an item, right click the item and click Pin to Start menu. Log Off will enable the current user to log off and allows a new user to log on. Turn Off Computer allows you to shut down, restart, and Stand by modes for power saving purposes. Taskbar When you open a program, its icon is displayed at the taskbar for you to conveniently move between programs by clicking the relevant button.
Control Panel It is in this area that you can change how Windows looks and works. Click Start Control Panel dialog box. There are two interfaces – Classic View.
38
Internet Connection Using a modem for Connection to Internet (optional) For more detail on the Network key, please refer to your local ISP provider and follow the procedures describe in the “ISP Installation Guide” to proceed with the installation.
Using a wired LAN for Connection to Internet For you connect to the Internet, a wired LAN environment normally uses the company’s LAN or a broadband modem.
Using Wireless LAN Network for Connection to Internet 41
42
Running BIOS Setup The Setup Utility is a hardware configuration program built into your computer’s BIOS (Basic Input/Output System). It runs and maintains a variety of hardware functions. It is menu-driven software, which allows you to easily configure and change the settings. The BIOS contains manufacture’s default settings for the computer’s standard operations. However, there are occasions when you may be required to modify the default settings in the BIOS.
BIOS Action Keys Function Key Command ESC Exit F1 General Help F10 Save and Exit ↑ ↓ + Select a field Select an item Select an item Lower value Higher value Description Leaves a sub-menu to return to the previous menu OR exits the BIOS setup while saving changes. Shows the Help Screen Saves changes and reboots the computer. Selects the next field. Selects the next upper item. Selects the next lower item. Selects the next value within a field. Selects the next value within a field.
Main Setup Under this menu, you may change time/date and view basic processor and system memory information.
46
Advanced Setup 47
Security Boot Setup 48
Exit Setup 49
System Recovery When you start to use this notebook, kindly make a rescue disk by “System Recovery AP” to back up your disk.” This application can be activated by: From “Start”, click on the “System Recovery This process enables you to restore your system whether your system is damaged or for some other reason that you can not operate your computer. First turn on the power. When the BIOS performs the POST (Power-On Self Test) Press F9 key quickly to activate the System Recovery Program.
Click the “Recover your computer” if you want to proceed. You will be asked whether you would like to proceed with the recovery procedures. Click “OK” if you want to proceed or “Cancel” if you want to discontinue with the recovery procedures. This illustration will be shown twice after you made the first decision in case you change your mind to discontinue with the recovery procedures.
The system will start with the recovery procedures. This illustration indicates the system has finished with the recovery procedures.
53
VGA Utilities You can click the touchpad or mouse right button and select the “Properties” item.
Select the “Display Settings” option to enter its window display. Click on the “Advanced Settings” tab to enter “Generic PnP Monitor on Mobile Intel ® 4 Series Express Chipset Family” window display.
56
57
58
59
60
3G Connection 3G is the third generation of mobile phone standards and technology. 3G enable users a wide range of more advanced service while achieving greater network capacity through improved spectral efficiency.
Press Fn + F12 to run the 3G application. Procedures in installing the application Insert the SIM card into the SIM slot. Execute the application by pressing the Mobile Partner icon 62 From the Mobile Partner display window, click on the “Tools” item Select the “Options”.
Double click on the “Profile Management” and click on the “New” tab Click on the “OK” tab.
64 On the next window, click on the “Connect” tab.
65
Troubleshooting Your computer has been fully tested and complies with the system specifications before shipping. However, incorrect operations and/or mishandling may cause problems. This chapter provides a reference for identifying and correcting common hardware and software problems that you may encounter. When you encounter a problem, you should first try to go through the recommendations in this chapter.
Be sure all the device drivers are installed properly. For example, without the audio driver properly installed, the speakers and microphone will not work. If external devices such as USB camera, scanner, printer do not function correctly when connected to the system, it is usually the device’s own problem. Consult the device’s manufacturer first. Some software programs, which have not gone through rigorous coding and testing, may cause problems during your routine use.
Select Recording and click the OK button. After Click OK button, the recording volume control panel will appear. Go to [Start > Settings > Control Panel] and double-click the Multimedia icon (or Sounds and Audio Devices icon). In the Volume or Audio page, make sure that the audio codec mentioned in the spec is the default recording device.
Many browsers store files in the hard drive as a cache to speed up the performance. Check the program’s Online Help for instructions on decreasing the cache size or on removing temporary Internet files. Empty the Recycle Bin to create more disk space. When you delete files, Windows saves them to the Recycle Bin. The hard disk takes longer to read a file If you have been using the drive for a period, the files may be fragmented.
Keyboard and Mouse Problems The built-in touch pad performs erratically Make sure there is no excess perspiration or humidity on your hand when using the touch pad. Keep the surface of the touch pad clean and dry. Do not rest your palm or wrist on the surface of the touchpad while typing or using the touch pad. The built-in keyboard accepts no input Please try to make sure the system doesn’t hang up and is still working.
Memory Problems The POST does not show an increased memory capacity when you have already installed additional memory Certain brands of memory module may not be compatible with your system. You should ask your vendor for a list of compatible DIMM. The memory module may be defective. The O/S issues an insufficient memory error message during operation This is often a software or Windows-related problem. A program is draining the memory resources.
Windows crashes or freezes when you remove the PC card Make sure you have the PC card before removing it. Double-click the Safely Remove Hardware icon at the lower right corner of the task bar and select the card you wish to stop. When you click , in few seconds Windows will prompt you to remove the card. Performance Problems The computer becomes hot In a 35oC environment, the certain areas of the computer’s back case are expected to reach 50 degrees.
USB2.0 Problems The USB device does not work Check the settings in the Windows Control Panel. Make sure you have installed the necessary device drivers. Contact the device vendor for additional support. Unable to use the External USB Device Detach the external device; insert it into the Enhanced USB port. Separate the cable with the equipment; first insert the wire into the port, then connect the device with the cable that is inserted into the Enhanced USB port.
74
Specification O.S. Supports Windows 7 Starter, Home Basic, Home Premium with logo submission Supports WinXP, Professional, Home Edition CPU Supports Celeron ULV Value, Single Core CPU, 1.2GHz (723),1MB L2 cache, 800MHz FSB, TDP10W Supports Celeron ULV Value, Dual Core CPU, 1.2GHz(SU2300), 1MB L2 cache, 800MHz FSB, TDP10W (TBD) Supports Pentium ULV, Single Core CPU, 1.
Audio Codec Realtek ALC269 Card reader (4 in 1) Support SDHC/MMC/MS/MS pro Memory Card USB2.0 interface LAN Controller Supports 10/100 Mb/Sec. PCI-E interface Wireless LAN Mini Card w/ PCI-E interface IEEE 802.11 B/G w/Single antenna IEEE 802.11n compatible (w/o WiFi logo) Camera CCD (Optional) Support 1.3M Camera Keyboard US 86 /UK 87/ BR 88 keys KB support Pointing Device PS2 Touch Pad with 2 buttons Support gesture function (optional) LCD 13.
AC-Adapter Automatics Voltage adjustment between 100 and 240VAC 50/60Hz, 40 Watts.2 Pin Delta ADP-40PH AB Delta ADP-40HM AD Liteon PA-1400-11 Lishin 0225C2040 Speaker/MIC Build-in 2 speakers Internal Microphone support BIOS Supports PnP, ACPI 3.0 Support external USB flash memory card boot up. With Phoenix BIOS and 1.2MB flash ROM Power Management (default: Silent mode) “Smart Power II” Power Management Physical Outline Dimension: 333.6 x 217.5 x 24.5mm~32.
