Before you Start Conventions of This Manual Use this manual will help you get the most from your notebook computer. If you are an experienced user of computers and/or Microsoft’s Windows operating systems, you might find it useful to read the Quick Start Guide that comes along with your accessories. If you are a less experienced user, you should go through the manual carefully before using your system.
6. 7. 8. 9. 10. 11. 12. 13. 14. 15. 16. 17. Make sure to use the right voltage for the power source when connecting the equipment to the power outlet. Place the power cord in such a way that people can not step on it. Do not place anything on top of the power cord. All cautions and warnings on the equipment should be noted. If the equipment is not used for a long time, disconnect the equipment from the main power outlet to avoid being damaged by transient overvoltage.
The appliance coupler must have a configuration for mating with a CEE7/EN60320/IEC 320/NEMA/ JIS C 8303 appliance inlet. For U.S. and Canada: The cord set must be UL Listed and CSA Certified. The minimum specifications for the flexible cord are No. 18 AWG, (2) Type SPT-2, and (3) 2-conductor. For Japan: All components of the cord set must bear a “PSE” mark and in accordance with the Japanese Dentori Law. The minimum specifications for the flexible cord are .
should always be followed to reduce the risk of fire, electric shock and injury to persons. These precautions include the following: Do not use this product near water, for example, near a bathtub, washbowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning. Do not use the telephone to report a gas leak in the vicinity of the leak.
Ensure proper use by reading and following the instructions carefully. Do not attempt to make any adjustment of the unit. Class1 Laser Product Appareil A Laser De Classe 1 Laserschutzklasse 1 Produkt Do not attempt to disassemble the cabinet containing the laser. The laser beam used in this product is harmful to the eyes. The use of optical instruments, such as magnifying lenses, with this product increase the potential hazard to your eyes.
geöffnet werden. 13. Wenn folgende Situationen auftreten ist das Gerät vom Stromnetz zu trennen und von einer qualifizierten Servicestelle zu Ü berprüfung.: a. Netzlabel oder Netzstecker sind beschädigt. b. Flüssigkeit ist in das Gerät eingedrungen. c. Das Gerät war Feuchtigkeit ausgesetzt. d. Wenn das Gerät nicht der Bedienungsanleitung entsprechend funktioniert oder Sie mit Hilfe dieser Anleitung keine Verbesserung erzielen. e. Das Gerät ist gefallen und/oder das Gehäuse ist beschädigt. f.
Der Kabelsatz muss mindestens für eine Stromstärke von 7A geeignet sein. Der Wandstecker muss ein zweipoliger geerdeter Steckertyp gemäß dem Japanese Industrial Standard C8303 (15A, 125 VAC) sein. Für andere Länder: Die Zubehörteile des Kabel-Sets müssen das Prüfsiegel derjenigen Stelle, die in dem jeweiligen Land für die Sicherheitsprüfung zuständig ist, tragen. Das Kabel muss vom HAR (harmonisierten) Typ H03VVH2-F sein.
bezüglich der Entsorgung. 19. Benutzen Sie das Netzteil nicht in unmittelbarer Nähe zu Wasser oder anderen Flüssigkeiten. Gießen Sie nie Flüssigkeiten über das Netzteil. 20. Es besteht Explosionsgefahr, wenn der Akku nicht ordnungsgemäß ersetzt wird. Ersetzen Sie den Akku nur durch einen Akku gleichen oder äquivalenten Typs, der vom Hersteller empfohlen wird. Entsorgen Sie Akkus entsprechend den Anweisungen des Herstellers.
Suitable place to work Your computer will run well wherever you’re comfortable but extreme temperature and humidity can be challenging to your system’s parts. There are some things you can tolerate that the computer can’t – things like static electricity, dust, water, steam and oil. In case you decide to pull over for roadside computing, try to choose a clean, comfortable work area for your system. A lithium-ion battery pack will be available when you are traveling.
11
Introduction Please use the adapter recommended in this manual. Preparing your Computer Install the battery pack Connecting the AC adapter Opening the display panel Turning on your computer Knowing your Computer With the LCD screen open, you will see several features important for operating your notebook computer.
To avoid damage to the display panel: 1. Try not to slam the display upon closing it. 2. Try not to place any object on top when it is closed or open. 3. Be sure the system is turned off or in suspend mode before you close the display panel. Front View Picture is only for reference Internal Microphone Camera (Optional) For best system performance, image is compressed when using the Crazy Talk Camsuite PRO's preview function. Photographs taken with 'snapshot' retain its original quality.
This LCD panel can only support up to a maximum opening of 125-130 degrees, please do not push it forcibly. Power/Suspend Button Press for 1~1.5 seconds to turn on the system. Press and hold for at least 4 seconds to turn off the system. Press the power / suspend button again to return from the suspend mode.
Left Views DC In Ethernet / LAN Port When using a LAN, please use an EMI Shielding Cable to minimize an interference when transmitting CRT Port HDMI Port USB 2.0 ports or USB 3.0 (Optional) This system provides two USB 2.0 or two USB 3.0 (optional) chargeable ports.
Right View USB 2.
Bottom View Battery Lock Battery Compartment Battery Release Latch 17
18
Getting Started Connecting to a Power Source Connecting the AC Adapter A universal AC adapter is provided to supply your computer with power and also charge the computer’s battery pack. The adapter’s AC input voltage can range anywhere from 100 to 240 volts, covering the standard voltages available in almost every country. To connect the computer to an external power source: Do not use inferior extension cords as this may result in damage to your notebook. The notebook comes with its own AC adapter.
Whenever possible, keep the AC adapter plugged into the notebook and an electrical outlet to recharge the battery. Never turn off or reset your notebook while the hard disk is in use status icon is lit; doing so can result in loss or destruction of your data. Always wait at least 5 seconds after turning off your notebook before turning it back on; turning the power on and off in rapid succession can damage the notebook’s electrical circuitry.
Explisionsgefahr bei unsachgernazen Austausch der Batterie. Ersatz nur durch denselben oder einem vom Hersteller empfohlenem ahnlichen Typ. Entsorgung gebrauchter Batterien navh Angaben des Herstellers. Installing and Removing the Battery Pack To Install the Battery Pack: To Remove the Battery Pack: Charging the Battery Pack The installed battery pack charges automatically any time the computer is connected to the AC adapter and an external power source.
22
Using the Notebook Computer Adjusting the LCD Screen Display The LCD screen display can be adjusted by the following key combinations. Fn + F4 Changes Display Mode: LCD-only, CRT/HDMI-only and simultaneous LCD&CRT/HDMI. Fn + F7 Decrease the brightness level. Fn + F8 Increase the brightness level. LCD Care LCD screens are delicate devices that need careful handling. Please pay attention to the following precautions: When you are not using the computer, keep the LCD screen closed to protect it from dust.
The Notebook’s Hot Key Controls Fn + ESC Enable/Disable Bluetooth Fn + F1 Enters Suspend Mode. Fn + F2 Enable/Disable Silent mode (power management) Fn + F3 Mute On/Off. Fn + F4 Changes Display Mode: LCD-only, CRT/HDMI-only and simultaneous LCD&CRT/HDMI Fn + F5 Decrease the speaker volume. Fn + F6 Increase the speaker volume. Fn + F7 Decrease the brightness level. Fn + F8 Increase the brightness level.
TouchPad Precautions The TouchPad is a pressure sensitive device. Please take note of the following precautions. Make sure the TouchPad does not come into contact with dirt, liquids or grease. Do not touch the TouchPad if your fingers are dirty. Do not rest heavy objects on the TouchPad or the TouchPad buttons. You can use the TouchPad with Microsoft Windows as well as nonWindows applications.
equipped with a hard disk drive (HDD). The HDD is removable allowing for easy upgrades. Power Saving Modes This section contains information on the notebook’s power system, including the AC Adapter, the battery system, recharging the battery, and tips for conserving battery power. The power system is comprised of two parts, the AC Adapter and the battery system. The AC Adapter converts AC power from a wall outlet to the DC power required by the computer.
Insert the battery into the battery compartment and turn on the notebook. If the battery is completely without power go to the next step. Otherwise, let the battery run down until the battery low-low warning beeps are heard. The system will automatically enter Suspend mode. 2. Turn the notebook off. Connect the AC adapter and let the battery fully recharge. When the battery charge indicator turns off, the battery is fully charged. 3.
Battery Low Warning When the pack initially reaches the “Battery Low” state approximately 7 ~ 10 minutes of the usable battery life is left. You will hear an audible beep signal every 15 seconds alerting you to the “Battery Low” status. When the battery power reaches the “Battery Low Low” status the beeping sound will accelerate. Your battery now has 1 ~ 2 minutes of battery charge remaining. You must save your data or connect AC power immediately; otherwise, you may lose your data.
Adjusting the Brightness To adjust the brightness on the LCD screen, press and hold down the [Fn] key in the lower left hand corner of the keyboard and press the [F7] key to increase the brightness or [F8] to decrease the brightness. Using the Windows Help Windows For Windows 7 help, click Start Help and Support icon will open the dialog box. Desktop Desktop may vary differently on the software installed in your notebook with different or additional shortcuts.
Recycle Bin Used for storing deleted files in case you want to recover and save it in your system. The files will only be deleted from the Recycle Bin permanently only if you empty it by right clicking your mouse and select the “Empty Recycle Bin”. Start Button Allows easy access to all Windows programs.
The Start menu allows you to adapt and show the programs used most frequently. If you wish to keep an item, right click the item and click Pin to Start menu. Log Off will enable the current user to log off and allows a new user to log on. Turn Off Computer allows you to shut down, restart, and Stand by modes for power saving purposes. Taskbar When you open a program, its icon is displayed at the taskbar for you to conveniently move between programs by clicking the relevant button.
Start Control Panel dialog box. There are two interfaces – Classic View.
33
Internet Connection Using Wireless LAN Network for Connection to Internet 34
35
Running BIOS Setup The Setup Utility is a hardware configuration program built into your computer’s BIOS (Basic Input/Output System). It runs and maintains a variety of hardware functions. It is menu-driven software, which allows you to easily configure and change the settings. The BIOS contains manufacturers default settings for the computer’s standard operations. However, there are occasions when you may be required to modify the default settings in the BIOS.
BIOS Action Keys Function Key Command ESC Exit Enter F1 F9 F10 + Go to Sub Screen General Help Default Save and Exit Select a field Select an item Select an item Select a menu Select a menu Lower value Higher value Description Leaves a sub-menu to return to the previous menu OR exits the BIOS setup while saving changes. Shows the Sub Menu Shows the Help Screen Set as default Saves changes and reboots the computer. Selects the next field. Selects the next upper item.
Main Setup 38
Info Setup 39
Advanced Security 40
Boot Setup Exit Setup 41
42
Super POSH Super POSH is an integrated AP which has great benefit for the system. It includes “Super Power” “Super OSD” “Super Speed” and “Super HDD.” These applications enable you to run the power saving scheme in your system, enable shortcut icon, optimize your system configuration, and detect your system current status. Super POSH System Tray Use your mouse left button by clicking once on the icon will show the status bar.
The main functions are as follows: Capslock / Silent mode / Touchpad / WLAN / Webcam / Bluetooth / Numlock / Scroll lock / Brightness / (sound) volume / Discrete / UMA Super Power Super Power provides an integrated page for user to control power management. It could increase battery life and provides effectiveness of your system.
Mode Power saving Icon Description Decrease system performance to provide more battery life Normal Balance system performance High performance Provide system best performance Dynamic switch Switch to “Power saving” & “ Normal” mode automatically on battery mode, and auto switch to “High performance” mode when plug-in. Power Status Show Current Power Source from AC or Battery.
Monitor HDD Stand by Brightness CPU Power Saving Hibernate LCD will be turned off after the interval time and setting of the OS if keyboard or mouse is not operated and no movie/game System will spin down disk after the interval time and setting to OS. System will sleep after the interval time and setting to OS. Adjust range is “Never” to “5hrs”. Show the LCD monitor brightness level through EC sent out code. *Brightness level synchronize with Fn-key.
Hibernate Wallpaper Turn off LCD Turbo mode Advance power engine SmartEye Allow Windows Power Plan Auto Switch Mode when Plug-in/out Power off Audio If users disable Hibernate, the option of Hibernate will not show in “Setting Page.” Default: ON Desktop background will be white. Press button to turn off the LCD immediately. Default: ON Overclocking CPU instantly. Function options depend on the definition of product specification. Drop efficacy to save the battery power.
Press Quick key to switch among each power management modes and on-screen display. Warning: If the percentage of battery was under 10%, there will pop a warning window on task icon. Super OSD (On-Screen-Display) Super OSD provides several styles and locations selection of OSD. And also could get the current status of OSD from status bar. >> or << to preview function and OSD pictures.
OSD Style: Blue, Green and Orange. Status: This area displayed the current status of OSD. Status bar will auto detect device connected in your system. If the color of the icon is yellow, it means the function is working. If the color of the icon is gray, it means the function is turn off. The value of volume and brightness also show at the side. The icon of status bar depends on product specification.
Volume Level Definition: Volume level value are as below Level Volume Value 0 0 1 1 ~ 10 2 11 ~ 20 3 21 ~ 30 4 31 ~ 40 5 41 ~ 50 6 51 ~ 60 7 61 ~ 70 8 71 ~ 80 9 81 ~ 90 10 91~1 00 * When adjusting the volume level, volume value will become current level x10 automatically. There are two options to either enable or disable the OSD. Uncheck the “Disable OSD”, the system will not show the OSD picture. Uncheck the “Display OSD Status bar”, Status bar will be closed.
An example is shown below where the OSD is shown on the lower right corner of the screen. Super OSD functions are as follows: The function will depend on the definition of product specification.
Scroll lock Web browser Media player Play Previous Rewind Stop Fast forward Next VGA/UMA Super Speed Super Speed optimizes and cleans the system to obtain the best effectiveness and fragmentation.
Optimizing Windows Setting: Click “Optimize” button after selecting the optimizing options to improve system performance. Click “Restore” button to restore the system to original status. After “Optimize” or “Restore” are executed, please reboot the computer for the changes to take effect. Click will pop a .
Click “Analyze” button to analyze the system. Click “Free” button after selecting the options to free up system disk space. The options are described in the following table: Options System temporary files Internet temporary file Recycle bin Description Clean the unnecessary files in Windows Clean the browsing history in Internet Explorer Clean the Recycle Bin in Windows System Disk Defragment: This will show the HDD health status according to “Super HDD” page.
Status & Picture Super HDD Super HDD displays the health status of HDD and information of CPU and RAM. Information of main HDD: Name, Type, Partitions and Total Size. Use scroll bar to choose the partition, it will display File system, Total Size and Free Size of in partitions. Hard Disk Menu Normal: Show the HDD Health Index according to S.M.A.R.T result.
HDD Health Index Condition Healthy HDD status will be healthy if all status of items are normal. Warning HDD status is in warning state if there are more than one warning item. Danger HDD status is in danger state if there more than one danger item. Not Support HDD does not support this function. Advanced : There were 46 attributes from S.M.A.R.T to determine the HDD health Index. Item's status depends on 3 main values: A: threshold, B: worst, and C: current value.
Warning: If the status of HDD and CPU is Danger, a warning window will pop up on the POSH icon. Setting page A: Show “about” in the top area. Include: Icon, Version, release date and information of every pages. B: Setting Options: Advanced setting of super POSH. Options ToolTip Refresh time Description Whether show ToolTip and Warning message Refresh battery status time * Refresh time would affect synchronized time with OS and discharge time.
58
Troubleshooting Your computer has been fully tested and complies with the system specifications before shipping. However, incorrect operations and/or mishandling may cause problems. This chapter provides a reference for identifying and correcting common hardware and software problems that you may encounter. When you encounter a problem, you should first try to go through the recommendations in this chapter.
Some software programs, which have not gone through rigorous coding and testing, may cause problems during your routine use. Consult the software vendor for problem solving. Legacy peripheral are not plug-and-play capable. You need to restart the system with these devices powered up and connected first. Be sure to go to BIOS SETUP and load DEFAULT SETTING after BIOS re-flash.
61
Specification Operaion System ( OS ) Supports Windows 7 Home Premium 32bit/64bit CPU Support Sandy Bridge SV Dual core 35W Support Ivy Bridge SV Dual core 35W Memory DDRIII DDR3 speed up to 1333MHz SO-DIMM*2, Max. support to 8GB Core Logic Panther Point HMxx TDP 4.1W Audio Codec Realtek ALC269Q-VB6-GR Card reader (6 in 1) Support SD, SDHC, SDXC, MMC, MS, MS Pro Memory Card WLAN/Bluetooth Combo (Optional) Combo Half-MiniCard type IEEE 802.11 B/G/N (1x1) BT 3.0 + HS support WLAN Half-MiniCard type IEEE 802.
Camera CCD Support 0.3M / 1.3M camera Keyboard US 300.8 mm-length new Flat keyboard support Pointing Device PS2 Touch Pad with 2 buttons Support multi-gesture function LCD 14" (16:9) HD 1366 x 768 LED-Back Light Unit Support 16:9 5.2mm thickness LED panel Battery Pack 6 Cells w/ SW gasguage Battery Li-on 4400mAh AC-Adapter Automatics Voltage adjustment between 100 and 240VAC 50/60Hz, LV5 -19V, 65 Watts. 2 Pin.
EMI CE RF R&TTE Safety CB 64
