Preface Copyright 2010 All Rights Reserved. The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
Table of Content BEFORE YOU START ............................................................................... 2 LET YOUR COMPUTER ACCLIMATE ITSELF .............................................. 9 HEAT, COLD, HUMIDITY, AND GLARE .................................................. 10 SUITABLE PLACE TO WORK ................................................................. 10 INTRODUCTION...................................................................................... 12 FRONT VIEW .....................
RUNNING BIOS SETUP ......................................................................... 47 INFO SETUP ...................................................................................... 49 MAIN SETUP ..................................................................................... 49 ADVANCED ........................................................................................ 50 SECURITY ......................................................................................... 50 BOOT SETUP .
1
Before you Start Conventions of This Manual Use this manual will help you get the most from your notebook computer. If you are an experienced user of computers and/or Microsoft’s Windows operating systems, you might find it useful to read the Quick Start Guide that comes along with your accessories. If you are a less experienced user, you should go through the manual carefully before using your system.
6. 7. 8. 9. 10. 11. 12. 13. 14. 15. 16. Make sure to use the right voltage for the power source when connecting the equipment to the power outlet. Place the power cord in such a way that people can not step on it. Do not place anything on top of the power cord. All cautions and warnings on the equipment should be noted. If the equipment is not used for a long time, disconnect the equipment from the main power outlet to avoid being damaged by transient overvoltage.
The minimum specifications for the flexible cord are No. 18 AWG, (2) Type SPT-2, and (3) 2-conductor. B. For Japan: All components of the cord set must bear a “PSE” mark and in accordance with the Japanese Dentori Law. The minimum specifications for the flexible cord are .75m ㎡ conductors, (2) Type VCTR or VCTFK, and (3) 2-conductor. The cord set must have minimum rated current capacity of 7 A.
Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning. Do not use the telephone to report a gas leak in the vicinity of the leak. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may explode. Check with local codes for possible special instructions. 18. Do not use the AC adapter near open water or other liquids. Never spill liquid into the AC adapter. 19.
Class 1 Laser Product Appareil A Laser De Classe 1 Laserschutzklasse 1 Produkt Do not attempt to disassemble the cabinet containing the laser. The laser beam used in this product is harmful to the eyes. The use of optical instruments, such as magnifying lenses, with this product increase the potential hazard to your eyes. For your safety, have this equipment serviced only by an authorized service provider. Wichtige Sicherheitshinweise 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13.
14. 15. 16. 17. Stromnetz zu trennen und von einer qualifizierten Servicestelle zu Überprüfung.: a. Netzlabel oder Netzstecker sind beschädigt. b. Flüssigkeit ist in das Gerät eingedrungen. c. Das Gerät war Feuchtigkeit ausgesetzt. d. Wenn das Gerät nicht der Bedienungsanleitung entsprechend funktioniert oder Sie mit Hilfe dieser Anleitung keine Verbesserung erzielen. e. Das Gerät ist gefallen und/oder das Gehäuse ist beschädigt. f. Wenn das Gerät deutliche Anzeichen eines Defektes aufweist.
Die Minimalanforderungen für das Kabel sind .75m ㎡ Leiter. (2) Type VCTF oder VCTFK, und (3) 2conductor. Der Kabelsatz muss mindestens für eine Stromstärke von 7A geeignet sein. Der Wandstecker muss ein zweipoliger geerdeter Steckertyp gemäß dem Japanese Industrial Standard C8303 (15A, 125 VAC) sein. C. Für andere Länder: Die Zubehörteile des Kabel-Sets müssen das Prüfsiegel derjenigen Stelle, die in dem jeweiligen Land für die Sicherheitsprüfung zuständig ist, tragen.
befindet. Verwenden Sie nur die in diesem Benutzerhandbuch angegebenen Stromkabel und Batterien. Werfen Sie die Batterien nicht ins Feuer, sie könnten explodieren. Informieren Sie sich über die örtlichen Bestimmungen bezüglich der Entsorgung. 19. Benutzen Sie das Netzteil nicht in unmittelbarer Nähe zu Wasser oder anderen Flüssigkeiten. Gießen Sie nie Flüssigkeiten über das Netzteil. 20. Es besteht Explosionsgefahr, wenn der Akku nicht ordnungsgemäß ersetzt wird.
If your system arrives in cold weather, do not apply power to the computer or monitor until they have been allowed to come to room temperature. Heat, Cold, Humidity, and Glare Find a suitable place for your computer that’s not too hot, too cold, too dark, or too bright. Glare can make it hard to read the screen. Try to avoid the computer components from being destroyed if it is overheated, so try to allow plenty of room for air to circulate around the case. Do not block the ventilation opening.
11
Introduction Please use the adapter recommended in this manual.
Knowing your Computer With the LCD screen open, you will see several features important for operating your notebook computer. To avoid damage to the display panel: 1. Try not to slam the display upon closing it. 2. Try not to place any object on top when it is closed or open. 3. Be sure the system is turned off or in suspend mode before you close the display panel.
For best system performance, image is compressed when using the Crazy Talk Camsuite PRO's preview function. Photographs taken with 'snapshot' retain its original quality. LCD Display This LCD panel can only support up to a maximum opening of 125-130 degrees, please do not push it forcibly. Power/Suspend Button Press for 1~1.5 seconds to turn on the system. Press and hold for at least 4 seconds to turn off the system. Press the power / suspend button again to return from the suspend mode.
System & Power Status Indicators LED Graphic Symbol Indication Blue light indicates the system is ON. Blinking blue light indicates the notebook is in suspend mode. Blue light indicates the LAN is active. Battery status Charging – Blue light flashing Full – Blue Low – Red light flashing Blue light indicates the hard drive and/or optical drive is being accessed.
Left Views Kensington Lock DC In Ventilation Opening 16
Ethernet / LAN Port When using a LAN, please use an EMI Shielding Cable to minimize an interference when transmitting CRT Port HDMI Port (Option) USB 2.
USB 2.0 Port USB 2.0 or 3.0 Port (Either one) This system provides two USB 2.0 and one USB 3.0 (optional) chargeable ports. This model provides charging function through USB 2.0 or 3.0 port on any peripherals such as cellular phones whether the system is ON or OFF under AC mode. Optical Drive Modem Port (Optional) Always disconnect all telephone lines from the wall outlet before servicing or disassembling this equipment. To reduce the risk of fire, use only No. 26 AWG or larger telecommunication line cord.
19
Getting Started Connecting to a Power Source Connecting the AC Adapter A universal AC adapter is provided to supply your computer with power and also charge the computer’s battery pack. The adapter’s AC input voltage can range anywhere from 100 to 240 volts, covering the standard voltages available in almost every country. To connect the computer to an external power source: Do not use inferior extension cords as this may result in damage to your notebook. The notebook comes with its own AC adapter.
Whenever possible, keep the AC adapter plugged into the notebook and an electrical outlet to recharge the battery. Never turn off or reset your notebook while the hard disk is in use status icon is lit; doing so can result in loss or destruction of your data. Always wait at least 5 seconds after turning off your notebook before turning it back on; turning the power on and off in rapid succession can damage the notebook’s electrical circuitry.
Danger of explosion if battery is incorrectly replaced. Replace only with same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions or local laws. Explisionsgefahr bei unsachgernazen Austausch der Batterie. Ersatz nur durch denselben oder einem vom Hersteller empfohlenem ahnlichen Typ. Entsorgung gebrauchter Batterien navh Angaben des Herstellers.
To Remove the Battery Pack: Charging the Battery Pack The installed battery pack charges automatically any time the computer is connected to the AC adapter and an external power source. It is a good idea to occasionally discharge the battery pack fully to preserve its operating performance.
24
Using the Notebook Computer Adjusting the LCD Screen Display The LCD screen display can be adjusted by the following key combinations. Fn + F4 Fn + F7 Fn + F8 Changes Display Mode: LCD-only, CRT/HDMI-only and simultaneous LCD&CRT/HDMI. Increase the brightness level. Decreases the brightness level. LCD Care LCD screens are delicate devices that need careful handling. Please pay attention to the following precautions: When you are not using the computer, keep the LCD screen closed to protect it from dust.
You can switch between these display configurations by pressing the key combination [Fn] + [F4]. The Notebook’s Hot Key Controls Action Fn + F1 Fn + F2 Fn + F3 Fn + F4 Fn + F5 Fn + F6 Fn + F7 Fn + F8 Fn + F9 Fn + F10 Fn + F11 System Control Enters Suspend Mode. Enters the Silent Mode. Mute/Unmute Audio/ PC beep to Output Changes Display Mode: LCD-only CRT/HDMI -only and simultaneous LCD&CRT/HDMI. Increase the speaker volume. Decrease the speaker volume. Increase the brightness level.
Scroll Locks On/Off RF On/Off Fn + F10 Brightness Fn + F7/F8 Volumn On/Off Fn + F3 Volume Fn + F5/F6 OSD-Bar Icon Caps Locks On Num Locks On Scroll Locks On Silent Mode ON Touchpad Off WLAN On RF On (By project) Web Cam On The OSD bar can be shown on the sidebar or you can drag it anywhere either on top (horizontally) or on the sides (vertically) of your screen.
Click on the Live Power icon from the lower right bar of your screen to open up the Live Power Display. The Live Power provides five modes according to the application that you are executing: Power saving mode: Provides the low consumption function, suitable for low utilization ratio and suspend mode. Normal mode: Provides for general work status. High Performance mode: For highest efficiency condition. DVD player mode: Provide for watching movie playback.
Power Saving Mode LCD Brightness: Level 1 CPU Speed: Level 0 LCD Off: Idle after 5 minutes HDD Off: Idle after 3 minutes Sleep: Idle after 5 minutes Hibernate: Idle after 10 minutes Normal Mode LCD Brightness: Level 5 HDD Off: Idle after 30 minutes 29
CPU Speed: Maximum level LCD Off: Idle after 15 minutes Sleep: Idle after 1 hour Hibernate: Idle after 2 hours High Performance Mode LCD Brightness: Level 5 CPU Speed: Maximum level LCD Off: Never DVD Play Mode 30 HDD Off: Never Sleep: Never Hibernate: Never
LCD Brightness: Level 5 CPU Speed: Maximum level LCD Off: Idle 4 hours HDD Off: Idle after 4 hours Sleep: Idle after 1 hour Hibernate: 2 hours Dynamic Switch Mode CPU Loading Battery life% High 50% up level 5 level 4 level 3 level 2 level 1 90% up 50% up 30% up 15% up 6% up less level than 0 5% Middle plus 30% up Middle 4%up High Performance mode High Performance mode High Performance mode High Performance mode High Performance mode High Performance mode Normal mode Normal mode Normal mode No
The TouchPad The touchpad is a rectangular electronic panel located just below your keyboard. You can use the static-sensitive panel of the touchpad and slit it to move the cursor. You can use the buttons below the touchpad as left and right mouse buttons. TouchPad Precautions The TouchPad is a pressure sensitive device. Please take note of the following precautions. Make sure the TouchPad does not come into contact with dirt, liquids or grease. Do not touch the TouchPad if your fingers are dirty.
Touchpad Usage Illustrations The typed is an electronic sensitive device with the light pressure of your fingertip to move the cursor around or select items displayed on the screen. Two Finger Straight Motion Gesture Place your two fingers on the surface of the Sensing Pad, side-byside in a slightly separated manner.
Two Fingers Curve Gesture Slide your index finger in an arching motion to clockwise or counterclockwise rotation. Connecting an External Tracking Devices The system will only enable you to use one tracking device whether it is an internal or external tracking device. Data Storage and Retrieval Data storage and retrieval are two of the most fundamental tasks you will perform when working with your computer. The Notebook is equipped with a hard disk drive (HDD).
including the AC Adapter, the battery system, recharging the battery, and tips for conserving battery power. The power system is comprised of two parts, the AC Adapter and the battery system. The AC Adapter converts AC power from a wall outlet to the DC power required by the computer. The Battery Power System Before using the computer on battery power for the first time, check the battery status icon on the Windows Toolbar to make sure the battery is fully charged.
next step. Otherwise, let the battery run down until the battery low-low warning beeps are heard. The system will automatically enter Suspend mode. 2. Turn the notebook off. Connect the AC adapter and let the battery fully recharge. When the battery charge indicator turns off, the battery is fully charged. 3. Turn On the notebook, let the battery run down until the battery is in low-low state and you hear a warning beeps. The system will automatically enter the Suspend mode.
approximately 7 ~ 10 minutes of the usable battery life is left. You will hear an audible beep signal every 15 seconds alerting you to the “Battery Low” status. When the battery power reaches the “Battery Low Low” status the beeping sound will accelerate. Your battery now has 1 ~ 2 minutes of battery charge remaining. You must save your data or connect AC power immediately; otherwise, you may lose your data.
Adjusting the Brightness To adjust the brightness on the LCD screen, press and hold down the [Fn] key in the lower left hand corner of the keyboard and press the [F7] key to increase the brightness or [F8] to decrease the brightness. Using the Windows Help Windows For Windows 7 help, click Start Help and Support icon will open the dialog box. Desktop Desktop may vary differently on the software installed in your notebook with different or additional shortcuts.
Recycle Bin Used for storing deleted files in case you want to recover and save it in your system. The files will only be deleted from the Recycle Bin permanently only if you empty it by right clicking your mouse and select the “Empty Recycle Bin”. Start Button Allows easy access to all Windows programs.
most frequently. If you wish to keep an item, right click the item and click Pin to Start menu. Log Off will enable the current user to log off and allows a new user to log on. Turn Off Computer allows you to shut down, restart, and Stand by modes for power saving purposes. Taskbar When you open a program, its icon is displayed at the taskbar for you to conveniently move between programs by clicking the relevant button.
Control Panel It is in this area that you can change how Windows looks and works. Click Start Control Panel dialog box. There are two interfaces – Classic View.
42
Internet Connection Using a modem for Connection to Internet (optional) 43
For more detail on the Network key, please refer to your local ISP provider and follow the procedures described in the “ISP Installation Guide” to proceed with the installation.
Using Wireless LAN Network for Connection to Internet 45
46
Running BIOS Setup The Setup Utility is a hardware configuration program built into your computer’s BIOS (Basic Input/Output System). It runs and maintains a variety of hardware functions. It is menu-driven software, which allows you to easily configure and change the settings. The BIOS contains manufacturers default settings for the computer’s standard operations. However, there are occasions when you may be required to modify the default settings in the BIOS.
BIOS Action Keys Function Key ESC Enter F1 F9 F10 + Command Description Leaves a sub-menu to return to the Exit previous menu OR exits the BIOS setup while saving changes. Go to Sub Screen Shows the Sub Menu General Help Shows the Help Screen Default Set as default Saves changes and reboots the Save and Exit computer. Select a field Selects the next field. Select an item Selects the next upper item. Select an item Selects the next lower item.
Info Setup Main Setup 49
Advanced Security 50
Boot Setup Exit Setup 51
52
Switchable Graphics (Optional) Switchable Graphics is a mobile graphics switching process optimizing your system for either high-powered graphics processing or low power consumption. It is designed to dynamically switch the graphics operation between Intel® integrated graphics and ATI Mobility Radeon™ discrete graphics (depending on the power source and user preferences) without rebooting the notebook.
Click on the “Configure Switchable Graphics” item.
Maximum Performance In this process, your notebook is plugged in to the power socket where ATI Switchable Graphics enables the ATI Mobility Radeon™ graphics processor for astonishing performance. This will deliver high performance and incredible 3D graphics that allows you to enjoy superior HD gaming, Blu-ray movies and other HD content in full HD-1080p on your HD-capable monitor.
Click on the “Configure Switchable Graphics” item.
57
Troubleshooting Your computer has been fully tested and complies with the system specifications before shipping. However, incorrect operations and/or mishandling may cause problems. This chapter provides a reference for identifying and correcting common hardware and software problems that you may encounter. When you encounter a problem, you should first try to go through the recommendations in this chapter.
Be sure all the device drivers are installed properly. For example, without the audio driver properly installed, the speakers and microphone will not work. If external devices such as USB cameras, scanner, printer do not function correctly when connected to the system, it is usually the device’s own problem. Consult the device’s manufacturer first. Some software programs, which have not gone through rigorous coding and testing, may cause problems during your routine use.
60
Specification O.S. Supports Windows 7 Home Premium CPU Support Intel Arrandale MCP Dual core, 32nm, 3MB L3 Cache, 1066MHz Processor The Integrated graphics controller contains a refresh of the 5th generation graphics core Memory DDRIII 1066/1333 MHz support (1333MHz downgrade to 1066 MHz ) RAM socket * 2 System DDRIII up to 4 GB total depends on module availability Core Logic Intel Calpella Arrandale + Ibex Peak (HM55) VGA (Optional) AMD Robson XT TDP 12-15 W DX11 and OpenGL 3.
DDR3 up to 1G VRAM support. Static and dynamic power management support (APM as well as ACPI) with full VESA DPM and Energy Star compliance Support Switchable Graphics technology Audio Codec Realtek ALC269Q-GR Card reader (6 in 1) Support SD / SDXC / SDHC / MS / MMC / MS Pro Memory Card USB2.0 interface LAN Controller Supports 10/100/1,000Mb/Sec PCI-E interface Wireless LAN PCI-E interface (WLAN module or WLAN/BT Combo module) REALTEK RTL8188CE Half-Card size IEEE 802.
Support 16:9 5.2mm thickness LED panel Battery Pack 4 cell, 2200mAh Celxpert O40-4S2200-C1L3 SIMPLO O40-4S2200-S1B1 Gallopwire O40-4S2200-G1L3 4 cell, 2600mAh SIMPLO O40-4S2600-S1S6 6 cell, 4400mAh Celxpert O40-3S4400-C1L3 SIMPLO O40-3S4400-S1B1 Gallopwire O40-3S4400-G1L3 6 cell, 5200mAh SIMPLO O40-3S5200-S1S6 AC-Adapter Automatics Voltage adjustment between 100 and 240VAC, 50/60Hz, LV5-19V / LV4-20V, 65 Watts., 2 pin / 3pin Delta Electronic, Inc.
Physical Outline Dimension: 350mm x 240mm x 20.6 ~ 36.5 (w/o rubber foot) Weight 1.9 Kg w/ 4 cell battery 2.
