Specification Sheet
© 2014 Elkay
SPEC00240 (07/2014)
SPECIFICATIONS
Freeze-Resistant
No Lead Drinking Fountain Soft Sides
®
Wall Mount – Fully Exposed
Model EDFPVR214RFPK
2222 Camden Court
Oak Brook, IL 60523
630-572-3192
elkay.com
In keeping with our policy of continuing product improvement,
Elkay reserves the right to change specication without notice.
Please visit elkay.com for the most current version.
This specication describes an Elkay product with design, quality and functional
benets to the user. When making a comparison of other producer’s offerings,
be certain these features are not overlooked.
PRODUCT SPECIFICATION
Wall-mounted drinking fountain constructed of a premium composite, solid-
surface material. Offer a contemporary look with smooth rounded lines.
White Granite nish.
Contoured basin minimizes splashing and has exclusive one-piece, heavy
duty Vandal-resistant bubbler. Easy to operate, fully functional chrome
plated pushbutton is vandal-resistant. Bottom cover plate included. Flow
regulator provides constant stream from 20 to 105 psi water pressure.
Complies with the requirements of A.D.A. (American’s with Disabilities Act)
when properly installed.
NO LEAD DESIGN
THIS DRINKING FOUNTAIN COMPLIES WITH THE LEAD-FREE
DEFINITION IN THE SAFE DRINKING WATER ACT OF 1986 AND LEAD
CONTAMINATION CONTROL ACT OF 1988.
Elkay Drinking Fountains are manufactured with a waterway system utilizing
copper components and completely lead-free material. These waterways
have no lead because all leaded materials, such as leaded brass, have
been removed.
This fountain is certied by WQA to lead-free compliance including NSF/
ANSI 61 and 372.
ACCESSORIES
MPW101 In wall carrier mounting plate
ML100 Support columns for MPW101
CONSTRUCTION
EDFPVR214RFP furnished complete with vandal-resistant bubbler, heavy-
duty push button and vandal-resistant bottom cover plate.
LKFRB1 includes box with separate front louvered panel. Flow regulator
provides constant stream from 20 to 105 psi water pressure. Operated by
adjustable cable system. Trap and drain tube included for proper installation.
DETAIL "A"
WASHER REQUIRED TO MINIMIZE
BREAKAGE OF FOUNTAIN
(TYP.) ALL MOUNTING BOLTS
WASHERS NOT INCLUDED
18 3/16"
462mm
27"
686mm
ADA
REQUIREMENT
7 1/8"
181mm
13 1/4"
337mm
14 1/4"
362mm
17 3/4"
451mm
5 3/16"
132mm
13 11/16"
348mm
3 5/8"
91mm
2 5/8"
66mm
FINISHED FLOOR
SEE DETAIL "A"
