Spec Sheet

SPECIFICATIONS
Elkay Quartz Classic 33" x 20-1/2" x 9-1/2"
Offset 60/40 Double Bowl Undermount Sink with Aqua Divide
Model(s) ELGULBO3322
In keeping with our policy of continuing product improvement, Elkay reserves the right to change product specifications without notice. Please visit elkay.com
for the most current version of Elkay product specification sheets. This specification describes an Elkay product with design, quality, and functional benefits to the
user. When making a comparison of other producers’ offerings, be certain these features are not overlooked.
Elkay REV 05012021 1333 Butterfield Road, Suite 200 © 2021 Page 1
ELGULBO3322 Downers Grove, IL 60515 ELGULBO3322_spec.pdf
PRODUCT SPECIFICATIONS
Elkay Quartz Classic® 33" x 20-1/2" x 9-1/2", Offset 60/40 Double Bowl
Undermount Sink with Aqua Divide. Sink is molded with up to 80%
natural quartz and high performance acrylic resins that are non-porous
providing superior heat, scratch, fade and stain resistance. Naturally
sound deadening and Rear Center drain placement.
Installation Type:
Undermount
Material:
Quartz
Special Features:
Aqua Divide
Finish:
Bisque (BQ), Black (BK),
Dusk Gray (GY), Greige (GR),
Greystone (GS), Mocha (MC), Putty (PT),
White (WH)
Number of Bowls:
2
Sink Dimensions:
33" x 20-1/2" x 9-1/2"
Bowl 1 Dimensions:
17-1/2" x 18-3/16" x 9-1/2"
Bowl 2 Dimensions:
12-13/16" x 16-3/16" x 9-1/2"
Drain Size:
3-1/2" (89mm)
Drain Location:
Rear Center
Minimum Cabinet Size:
36"
Mounting Hardware:
Part # 54300408 included
Template Included:
Yes
Cutout Template #:
1000002208
Template is available for download at elkay.com. CAD software will be
required to open the template.
AMERICAN PRIDE. A LIFETIME TRADITION.
Like your family, the Elkay family has values and traditions that endure.
For almost a century, Elkay has been a family-owned and operated
company, providing thousands of jobs that support our families and
communities.
Product Compliance:
CSA B45.5/IAPMO Z124
Sinks are listed by IAPMO
®
as meeting the applicable requirements
of the Uniform Plumbing Code
®
, International Plumbing Code
®
, and
National Plumbing Code of Canada.
Clean and Care Manual (PDF)
Installation Instructions (PDF)
Warranty (PDF)
