Specification Sheet

G E NE R AL
S elf-contained, double wall hung electric refrigerated, water
cooler. C apacity 8.0 GP H of 50°F drinking water, based upon
80°F inlet water and 90°F ambient.
All models have a hooded stream projector with s elf closing
push bars on front and both right and left s ides . Flow regula-
tor provides constant s tream from 20 to 105 psi water pres-
sure. B ubbler orifice fully protected to meet all s anitary codes .
N
OTE: Minimum 40 psi supply line press ure required in s pe-
cial circumstances where both sides of bi-level are in us e
simultaneous ly to ensure adequate stream height. Does not
apply to non-refrigerated units.
Press urized s tainless s teel evaporator/storage tank for long
life. Waterways are certified NS F/ANS I 61, far exceeding the
requirements of the S afe Drinking Water Act. S tainles s steel
water tank is lo
cated after bubbler valve, s o that the tank is
subject to line pres s ure only when pus h bar is pres s ed.
A
DA C OM P L I A N T
Thes e Water C oolers comply with the requirements of A.D.A.
(Americans with Disabilities Act) when properly installed. Also
meets the guidelines for children’s environments providing
the floor to orifice height is 30" or less and proper clear floor
s pace is provided for parallel approac h. (B as ed on
Architectural and Trans portation B arriers C ompliance B oard
final ruling.) C heck Local and S tate C odes .
NO L E A D DE S IG N
Thes e Water C oolers are certified to be lead-free as defined
by the S afe Drinking Water Act. E lkay Water C oolers are man-
ufactured with a waterway system utilizing copper compo-
nents and completely lead-free materials. These waterways
have no lead becaus e all lead materials, s uch as leaded
brass, have been removed. All joints are brazed using silver
solder only. No lead s older is permitted. A strainer with an
easily cleanable s creen is provided to allow trapping and con-
venient removal of waterborne particulate of 140 microns and
larger prior to their entry into the water cooler.
C
OOL IN G S Y S T E M
Motor C ompres s or: Hermetically sealed, reciprocating type,
115 Volt/60 Hz, single phas e. S ealed-in lifetime oil supply.
E quipped with electric cord and three prong molded rubber
plug.
C ondens er: Fan cooled, copper tube with aluminum fins. Fan
motor is permanently lubricated.
C ooling Unit: C ombination tube-tank type. Tube portion is
continuous coil of copper tubing. Fully insulated with EP S
foam which meets Un
derwriters Laboratories Inc. require-
ments for self extinguishing material.
C
APA C IT IE S C HAR T
**B as ed on 80°F (27°C ) inlet water temperature.
R ated watts shown are based on operational (run) time, in compliance with A.R .I.
S tandard 1010 conditions. S pecific applications will determine the actual watts
consumed per hour. Watts cons umed will be based on number of people
served per hour (usage), ambient temperatures , and inlet water temperature.
**GPH of 50°F
Drinking Water
Ship.
Room Temperature °F
Full Glass Wt.
Model Volt./ Base 70°F 80°F 90°F Rated Load Filler Filter Lbs.
Number Hertz Rate (21°C) (27°C) (32°C) Watts Amps Option Option (Kg.)
EMABFTLR8C
115V/
8.0 9.7 8.8 8.0 370 4.0 No Yes 92
60Hz
EMABFTLRDDC – – – – – – – No Yes 70
Tw o S ta tion Wa ll M ount Wa te r C oole r (R e ve rs e d)
B a r r ie r-F r e e Ac c e s s (A dult or C hild)
NS F /ANS I 6 1 C om plia nt
M ode ls E M A B F T L R 8 C a nd E M AB F T L R D DC
®
S P E C I F I C A T I O N S
R efrigerant C ontrol: R efrigerant HFC -134a is controlled by
accurately calibrated capillary tube for pos itively trouble-free
operation.
Temperature C ontrol: Enclosed adjustable thermos tat is
factory preset. R equires no adjustment other than for altitude
requirements. E as ily accessible.
C
ONS T R UC T IO N
Frame: Galvanized s tructural steel chas s is supports fountain
top and cabinet panels.
Fountain Top: S eries 300 one piece stainles s s teel top,
polished to a uniform E lkay bright luster finish. B asin has
embos s ed bubbler pad.
E xc lus ive F lexi-Guard
®
S afety B ubbler: Innovative design
utilizes a pliable polyester elas tomer to prevent accidental
mouth injuries . Flex on impact, then returns to original posi-
tion. S trong. Abras ion-res istant. Anti-s weat. B ubbler meets
UL requirements and all sanitary codes and is keyed in loca-
tion to prevent rotation.
C abinet: C abinet design allows for flush to wall mounting. No
reces s s pace is required. Inc ludes bottom c over plate
fastened with s tandard s crews .
C olor S elec tion: Light Gray G ranite furnished as s tandard.
S tainles s s teel available at extra cos t.
P rotected by E lk ay’s 5 Y
ear L imited Warranty on the refrig-
eration system of the unit.
E lkay Pres s ure-Type Water C oolers are des igned to operate
on 20 psi (138 K P a) to 105 ps i (724 K P a) supply line pressure.
If inlet pres sure is above 105 psi (724 K P a), a pressure
regulator mus t be installed in the s upply line. Any damage
caus ed by reason of connecting this product to supply line
pres s ures lower than 20 ps i (138 K Pa) or higher
than 105 psi
(724 K P a) is not covered by the warranty.
S
TAND A R D S
Model E MAB FTLR 8C
E lkay
2222 C amden C ourt
Oak B rook, IL 60523
Printed in U.S .A.
© 2011 Elkay
(R ev. 7/14) 12-54D
elkay.com
In keeping with our policy of c ontinuing product improvement, E lkay reserves the right to c hange
product s pecifications without notice. Please visit elkay.com for most current version of Elkay product
This s pecification describes an Elkay produc t with design, quality and functional benefits to the
user. When making a comparison of other produc ers ’ offerings, be c ertain thes
e features are not
overlooked.
Elkay Electric Air C ooled Water C oolers are listed
by Underwriters Laboratories Inc. and comply with
both C anadian and U.S . requirements.
These units comply with A.R .I. S tandard 1010.
This cooler is certified by WQA to lead-free compliance including
NS F/ANS I 61-ANNE X G , AB 1953.
