Specification Sheet

GENERAL
Self-contained, wall hung electric refrigerated water cooler. Chilling
capacity of 50°F drinking water, based upon 80°F inlet water and
90°F ambient.
Model LZO8 sensor-operated cooler has unique Hands-Free
®
oper-
ation and patented* valve with built-in flow regulator to provide con-
stant stream from 20 to 105 psi.
Non-pressurized stainless steel cooling tank is standard. Non-
pressurized water tank is located after bubbler valve, so that tank is
subject to line pressure only when sensor is activated.
ADA COMPLIANT
This Water Cooler complies with the requirements of A.D.A.
(Americans with Disabilities Act) when properly installed. Also meets
the guidelines for children’s environments providing the floor to orifice
height is 30" or less and proper clear floor space is provided for par-
allel approach. (Based on Architectural and Transportation Barriers
Compliance Board final ruling.) Check Local and State Codes.
NO LEAD DESIGN
This Water Cooler is certified to be lead-free as defined by the Safe
Drinking Water Act. Elkay Water Coolers are manufactured with a
waterway system utilizing copper components and completely lead-
free materials. These waterways have no lead because all lead mate-
rials, such as leaded brass, have been removed. All joints are brazed
using silver solder only. No lead solder is permitted. A strainer with an
easily cleanable screen is provided to allow trapping and convenient
removal of waterborne particulate of 140 microns and larger prior to
their entry into the water cooler.
This water cooler is certified to NSF/ANSI 61.
WATERSENTRY
®
VII FILTER SYSTEM
Elkay Water Coolers are equipped with the WaterSentry VII Filter
System, which is tested and certified by NSF International. The
WaterSentry VII Filter System reduces cysts such as cryptosporidium
and giardia by 99.99%. Tested to NSF/ANSI Standard 53 yields a
reduction of soluble and insoluble lead content to less than
0.015mg/l. This translates to lead reduction levels of 93% to 99%.
Class 1 particulate reduction as tested per NSF/ANSI 42. Removes over
97.5% of free available chlorine which provides Class 1 performance
as tested to NSF/ANSI 42. Provides taste and odor improvement.
FILTER MONITOR
Filter Monitor records water usage and advises users when filter
needs changing. The three light system Green (filter below 80% of
capacity) Yellow (80% to 90% of capacity and Red (Filter needs to be
replaced) helps maintain that user always has the best filtered water
available to them.
COOLING SYSTEM
Motor Compressor: Hermetically sealed, reciprocating type, 115V,
60 Hz single phase. Sealed-in lifetime oil supply. Equipped with elec-
tric cord and three prong molded rubber plug (domestic models).
Condenser: Fan cooled, copper tube with aluminum fins. Fan motor
is permanently lubricated.
Cooling Unit: Combination tube-tank type. Self cleansing. Tube por-
tion is continuous coil of copper tubing. Tank is stainless steel. Fully
insulated with EPS foam which meets Underwriters Laboratories Inc.
requirements for self-extinguishing material.
Refrigerant Control: Refrigerant HFC-134a is controlled by accu-
rately calibrated capillary tube for positively trouble-free operation.
Temperature Control: Enclosed adjustable thermostat is factory pre-
set. Requires no adjustment other than for altitude requirements.
Easily accessible.
CONSTRUCTION
Electronic Sensor Hands-Free
®
Operation: On-off solenoid valve is
actuated by an infrared light beam sensor. When light beam is inter-
rupted by subject in front of cooler desiring a drink, the sensor actuates
the solenoid valve which then opens to allow water flow. No physical
contact with cooler is required. A built in time delay is provided to pre-
vent actuation by persons moving past cooler. There is a maximum run-
ning time of 30 seconds to prevent malicious damage to the cooler or
water damage if sensor vision is blocked. Unit automatically resets when
blockage is removed. Sensor range is adjustable.
Frame: Galvanized structural steel chassis supports refrigeration
system and fastens to wall. Provides increased structural integrity and
rigidity to cooler.
Stainless Steel Basin: One piece polished to a uniform Elkay bright
luster finish. Basin has integral drain grid, embossed bubbler pad. No
exposed fasteners.
Exclusive Flexi-Guard
®
Safety Bubbler*: Innovative design
utilizes an infused anti-microbial pliable polyester elastomer to pre-
vent accidental mouth injuries. Flexes on impact, then returns to orig-
inal position. Strong. Abrasion-resistant. Anti-sweat. Keyed in loca-
tion to prevent rotation.
Upper Shroud: Contoured shock-absorbing, provides additional pro-
tection against accidental injury. No exposed fasteners.
Lower Shroud: One piece easy to remove and replace. Allows
access to internal components from three sides.
Cabinet: Cabinet design allows for flush to wall mounting. No recess
space is required.
Color Selection: Unless otherwise specified cabinet is two-tone gray
on upper shroud with textured gray lower shroud. Stainless Steel
lower shroud available at extra cost.
5 YEAR LIMITED WARRANTY on the refrigeration system of the
unit. Electrical components and water system are warranted for 12
months from date of installation. Sample Certificate available on
request.
Elkay Pressure-Type Water Coolers are designed to operate on 20 psi
to 105 psi supply line pressure. If inlet pressure is above 105 psi, a
pressure regulator must be installed in the supply line. Any damage
caused by reason of connecting this product to supply line pressures
lower than 20 psi or higher than 105 psi is not covered by the
warranty.
STANDARDS
Model LZO8
* Patent #4,481,971
Elkay
2222 Camden Court
Oak Brook, IL 60523
Printed in U.S.A.
©2009IElkay
(8/09) 8-25A
elkayusa.com
In keeping with our policy of continuing product improvement, Elkay reserves the right to change
product specifications without notice.
This specification describes an Elkay product with design, quality and functional benefits to the
user. When making a comparison of other producers’ offerings, be certain these features are not
overlooked.
Wall Mount Water Cooler Hands-Free
®
Barrier-Free Access (Adult & Child)
With WaterSentry
®
VII Filter System and
Filter Monitor – Model LZO8
®
S P E CI F IC ATI O NS
CAPACITIES CHART
**Based on 80°F inlet water temperature.
Rated watts shown are based on operational (run) time, in compliance with A.R.I.
Standard 1010 conditions. Specific applications will determine the actual watts
consumed per hour. Watts consumed will be based on number of people
served per hour (usage), ambient temperatures, and inlet water temperature.
**GPH of 50°F Drinking Water
Full Glass Ship.
Model Base
Room Temperature °F
Rated Load Filler Wt.
Number Rate 70°F 80°F 90°F Watts Amps Option Lbs.
LZO8 8.0 9.7 8.8 8.0 370 4.0 No 56
These units comply with A.R.I. Standard 1010.
Elkay Electric Air Cooled Water Coolers are listed
by Underwriters Laboratories Inc. and comply with
both Canadian and U.S. requirements.
RATED FOR INDOOR APPLICATIONS ONLY
