Gold Tuba Installation Guide
MAN-G-TUBIG-EC (Ver. 1.201)
|www.elmomc.com
60
Table of Contents
7.11. Network I/O
The following table lists the Gold Tuba network I/O pin assignments.
Note: This option is only present in G-TUBXX/YYYXXXEX type.
Network I/O Pins Signal Function
1 EXT_IN1 Extended I/O Input 1
2 EXT_IN2 Extended I/O Input 2
3 EXT_IN3 Extended I/O Input 3
4 EXT_IN4 Extended I/O Input 4
5 EXT_IN5 Extended I/O Input 5
6 EXT_IN6 Extended I/O Input 6
7 EXT_IN7 Extended I/O Input 7
8 EXT_IN8 Extended I/O Input 8
9 EXT_IN9 Extended I/O Input 9
10 ANALRET2 Analog Input 2 Return
11, 12 VDDRET Supply Return for Extended Out 1-6
13, 14 VDD_IN Supply for Extended Out 1-6
15 INRET1-12 Extended Inputs 1-12 Return for the S/T
version
Positive Extended Inputs 1-12 for the H
version
16 EXT_IN10 Extended I/O Input 10
17 EXT_IN11 Extended I/O Input 11
18 EXT_IN12 Extended I/O Input 12
19 ANALOG2- Analog Input 2 -
20 ANALOG2+ Analog Input 2 +
21 EXT_OUT1 Extended OUT 1
22 EXT_OUT2 Extended OUT 2
23 EXT_OUT3 Extended OUT 3
24 EXT_OUT4 Extended OUT 4
25 EXT_OUT5 Extended OUT 5
26 EXT_OUT6 Extended OUT 6
