User Menu Parameters
54
Table 20 Total run hours parameters
Function
Read/
Write
Range
Imperial (metric)
Large Display Small Display
Page 1 of 1
Actual Hours / Limit - - -
Fan Motor(s) MOTOR(S) W 0-32000
Fan Motor(s) Limit LIMIT W 0-32000
Compressor 1 COMP1 W 0-32000
Compressor 1 Limit LIMIT W 0-32000
Compressor 2 COMP2 W 0-32000
Compressor 2 Limit LIMIT W 0-32000
Chilled Water/Free Cool CW/FC W 0-32000
Chilled Water/Free Cool Limit LIMIT W 0-32000
HotGas / HotWater HG / HW W 0-32000
HotGas / HotWater Limit LIMIT W 0-32000
Electric Heater 1 EL HEAT1 W 0-32000
Electric Heater 1 Limit LIMIT W 0-32000
Electric Heater 2 EL HEAT2 W 0-32000
Electric Heater 2 Limit LIMIT W 0-32000
Electric Heater 3 EL HEAT3 W 0-32000
Electric Heater 3 Limit LIMIT W 0-32000
Humidifier HUM W 0-32000
Humidifier Limit LIMIT W 0-32000
Dehumidification DEHUM W 0-32000
Dehumidification Limit LIMIT W 0-32000
Table 21 Timer parameters—Sleep Mode
Function
Read/
Write
Range
Imperial (metric)
Large Display Small Display
Page 1 of 1
Password PASSWORD W -
Sleep On: - - -
Mon MON W No, Yes
Tue TUE W No, Yes
Wed WED W No, Yes
Thu THU W No, Yes
Fri FRI W No, Yes
Sat SAT W No, Yes
Sun SUN W No, Yes
Sleep Every Day (1) - - -
From / To
START1 / START1 /
STOP1 / STOP1
W Time (hh:mm)
Sleep Every Day (2) - - -
From / To
START2 / START2 /
STOP2 / STOP2
W Time (hh:mm)
Timer Mode TIME MOD W NO, YES, AUTO
