Service Menu Parameters
69
TYPE -- -
COMP 1 SHORT CYCLE SC1 W MSG, WRN, ALM
COMP 2 SHORT CYCLE SC2 W MSG, WRN, ALM
NO POWER NOP W MSG, WRN, ALM
CONDENSER 1 FAILURE CN1 W MSG, WRN, ALM
CONDENSER 2 FAILURE CN2 W MSG, WRN, ALM
----
----
----
----
----
----
Table 29 Sensor calibration / setup parameters
Function
Read/
Write
Range
Imperial (metric)
Large Display Small Display
Page 1 of 3
Password PASSWORD W -
Return Temperature RTN TEMP W ±18°F (±9.9°C)
Calibrated Return Temperature CAL TEMP R 32-122°F (0-50°C)
Return Humidity RTN HUM W ±9.9%
Calibrated Return Humidity CAL HUM R 20-80%
Digiscroll 1 NTC DS1 NTC W ±18°F (±9.9°C)
Calibrated Digiscroll 1 NTC CAL DS1 R 84-313°F (29-156°C)
Digiscroll 2 NTC DS2 NTC W ±18°F (±9.9°C)
Calibrated Digiscroll 2 NTC CAL DS2 R 84-313°F (29-156°C)
Page 2 of 3
Password PASSWORD W -
Temperature Sensor A TEMP A W ±18°F (±9.9°C)
Calibrated Temperature Sensor A CAL A R 32-122°F (0-50°C)
Humidity Sensor A HUM A W ±9.9%
Calibrated Humidity Sensor A CAL A R 20-80%
Temperature Sensor B TEMP B W ±18°F (±9.9°C)
Calibrated Temperature Sensor B CAL B R 32-122°F (0-50°C)
Humidity Sensor B HUM B W ±9.9%
Calibrated Humidity Sensor B CAL B R 20-80%
Page 3 of 3
Password PASSWORD W -
Table 28 Set alarms parameters (continued)
Function
Read/
Write
Range
Imperial (metric)
Large Display Small Display
SET
ALARMS
+ / -
