Brochures and Data Sheets

12013.10
eSure
™
Converter
C48/24 -1500
Key Features
1500 Watt high-efficiency
converter designed to operate
from a nominal 48V DC source
to provide 24 VDC load power
Optimized depth –
reduced footprint allows
installation in short-depth
racks and cabinets
DSP (Digital Signaling
Processor) – means fewer
components, optimized
operation and active load
sharing for increased reliability
Compliant with global
standards – delivers quality,
performance and reliability no
matter what the application or
location demands
High efficiency, approaching
96% – reduces power
consumption for lower
operating costs
Hot pluggable – facilitates
future extensions
Wide input voltage range to
operate in the most
demanding environments
where input voltage changes
Wide temperature operating
range (-40°C / -40°F to +80°C /
176°F) to meet the harshest
climatic environment
requirements
In addition to reducing power consumption and
lowering operating cost, eSure
™
high-efficiency
converters offer superior performance and
uncompromised reliability.
Description
The eSure™ C48/24-1500 high-efficiency converter is designed to operate from a
nominal 48 Vdc source to provide nominal 24Vdc load power, which is adjustable
to application needs. The C48/24-1500 is a constant power converter designed
with the latest patented switchmode technology, using DSP (Digital Signaling Processor)
functionality for efficient operation.
For a higher load capacity, converters can be connected in parallel, and intelligent
control can be added with the help of a separate controller.
Efficiency
Load
0 10 20 30 40 50 60 70 80 90 100
96
94
92
90
