Specification Sheet

Emtek Products, Inc. 15250 Stafford St. City of Industry, CA 91744 Tel: [phone] Fax: [phone] www.emtek.com
1
Brass Tubular Entrance Handlesets - Wilmington Style
Wilmington Trim Style
Part # 4314/4324
Additional Dimensions: (Part # 4314/4324)
• Exterior Projection is 2 ¾”
• Interior Projection Depends on Handle Style
• Overall Grip thickness: 1"
• Clearance between door & grip is 17/16”
• Plates thickness: ½"
Same Dimensions for Dummy Function
19-5/16"
9-3/4"
2-13/16"
2-13/16"
2-3/8" 2-3/8"
2-1/8"
Standard interior trim
Part # 4314
