YSTEM

PECIFIER

www.englertinc.com

MANUFACTURER

ENGLERT, INC.

1200 Amboy Avenue

Perth Amboy, New Jersey 08861

Tel: (732) 826-8614

Fax: (732) 826-8865

SECTION 07410 - WALL PANELS

This specification guide

is designed to assist in

the proper insertion of

Englert Roof Systems

into any architectural

building specifications.

This guide is formatted

to match the CSI Spec

Data System, however is

not part of that program.

PART I - GENERAL

SERIES 4000

1.01 WORK INCLUDED

Providing all labor, materials, tools, equipment and services to furnish and install metal wall

panels/siding, including soffit, flashing, trim and such other accessories to make the system

complete and weathertight, as indicated on the drawings and specified herein.

1.02 RELATED WORK (to be coordinated with other trades by the successful contractor

under this section.) FOR APPLICATIONS OVER PLYWOOD DECKING (edit as required.)

A. Section 06100: Rough Carpentry

B. Section 06200: Finish Carpentry

C. Section 07620: Sheet Metal Flashing and Trim

D. Section 07700: Roof Specialties and Accessories

E. Section 07800: Skylights

F. Section 07900: Joint Sealers

1.02 RELATED WORK (to be coordinated with other trades by the successful contractor

under this section.) FOR APPLICATIONS OVER METAL DECKING WITH RIGID

INSULATION AND STANDING SEAM ROOF (edit as required.)

A. Section 05100: Structural Steel

B. Section 05200: Steel Joists

C. Section 05300: Metal Decking

D. Section 05580: Sheet Metal Fabrication

E Section 07200: Insulation

F. Section 07500: Membrane Roofing

G. Section 07620: Sheet Metal Flashing and Trim

H. Section 07700: Roof Specialties and Accessories

I. Section 07800: Skylights TRI\SPECS:4000:01/01/03

J. Section 07900: Joint Sealers 90311L

PECIFICATION

Summary of content (6 pages)

PAGE 1
SPECIFICATIONS YSTEM PECIFIER www.englertinc.com MANUFACTURER ENGLERT, INC. 1200 Amboy Avenue Perth Amboy, New Jersey 08861 Tel: (732) 826-8614 Fax: (732) 826-8865 SECTION 07410 - WALL PANELS This specification guide is designed to assist in the proper insertion of Englert Roof Systems into any architectural building specifications. This guide is formatted to match the CSI Spec Data System, however is not part of that program. PART I - GENERAL SERIES 4000 1.
PAGE 2
1.03 QUALITY ASSURANCE A. Installation: By a roofing/sheet metal contractor with at least a minimum of five years experience in similar type of construction and documenting successful completion of contracts for projects similar in size, scope and products. B. Before Fabrication: The contractor shall take field measurements of the structure and substrates indicated and specified to ensure that panel lengths and brakeformed flashings are dimensioned accurately to facilitate easy installation.
PAGE 3
1.07 WARRANTY A. Manufacturer shall warrant the metal wall panels against rupture or perforation or from structurally failing due to normal atmospheric conditions for a period of twenty five (25) years. In addition, Manufacturer shall provide a 35-year finish warranty against peeling and blistering, chalk, and fade (color change). B.
PAGE 4
2.02 A. Panel System shall be the Englert Series 4000, 1-1/2” x 12” or 14” wide, Flat Panels. Flush wall soffiit is available with ribs. All fasteners shall be concealed, and panels shall give a flush appearance. The soffit panels shall have the same finish as the roofing system. The panels shall have baked on finish as specified in Section 2.05 hereunder, in Manufacturer’s standard colors. Manufacturer shall offer at least a minimum of 23 standard colors to choose from. B.
PAGE 5
2.05 PERMACOLOR3500 FINISH - (35-Year Warranty) A. Englert’s PermaColor 2000 standard 30-year color coatings comprises of a .8 to .9 mil full strength 70% Kynar 500 fluorocarbon (Polyvinylidene Fluoride PVF2) coating over a urethane primer of. 2 to .3 mil on the finish side, with primer and a wash coat on the reverse, on steel with just a wash coat on aluminum. Face film thickness 1.0 mil + .2 mil. 2.05.1 FILM THICKNESS Topside Finish: Primer shall be .2-.3 mil. Kynar 500 top coat shall be .8 - .9 mil.
PAGE 6
2.07.1 MILL FINISH GALVALUME (Bare) A. A coating of aluminum zinc alloy applied by a continuous hot dipping process, offering greater corrosion resistance, high temperature oxidation resistance, and heat reflectivity. Mill finish Galvalume carries a 25-year warranty.(AZ-55) PART III – EXECUTION 3.01 INSPECTION A. Verify substrate is uniform, even and symmetrical by running a string test.
