Related Documents

xvii About This Guide

RELATED DOCUMENTS

The following Enterasys Networks documents may help to set up, control, and manage the switch

module:

• 6C105 SmartSwitch 6000 Overview and Setup Guide

• Matrix E7 Chassis Overview and Setup Guide

• SmartTrunk User’s Guide

• WAN Series Local Management User’s Guide

Documents associated with the optional HSIM and VHSIM interface modules, module installation

user’s guides, and the manuals listed above, can be obtained from the World Wide Web in Adobe

Acrobat Portable Document Format (PDF) at the following web site:

http://www.enterasys.com

DOCUMENT CONVENTIONS

The guide uses the following conventions:

NOTE: Calls the reader’s attention to any item of information that may be of special

importance.

TIP: Conveys helpful hints concerning procedures or actions.

CAUTION: Contains information essential to avoid damage to the equipment.
