3.10 NAME SERVICES CONFIGURATION SCREEN
When to Use
Use this screen when enabling Port-based Web authentication. This screen can also be used to
configure the global Secure Harbour name and IP address. The user can Enable/Disable Name
Services and associate the switch name with the Secure Harbour IP address.
How to Access
Use the arrow keys to highlight the NAME SERVICES CONFIGURATION menu item on the
Security Menu screen and press ENTER. The Name Services Configuration screen, Figure 3-11,
displays.
Screen Example
Figure 3-11 Name Services Configuration Screen
3650_21
EXIT
Switch Name:
Secure Harbour IP:
Name Services:
Web Authentication:
Secure Harbour
0.0.0.0
[DISABLED]
[DISABLED]
SAVE
RETURN
