MAC Supplicant Configuration Screen
Accessing Local Management 3-57
Screen Example
Figure 3-19 MAC Supplicant Configuration Screen
Field Descriptions
Refer to Table 3-17 for a functional description of each screen field.
Table 3-17 MAC Supplicant Configuration Screen Field Descriptions
Use this field… To…
Port
(Read-Only)
See the port numbers of all ports known to the device. Up to 10 ports
can be displayed at a time. To see additional ports, select NEXT and
press ENTER to display the authentication type and status for the next
10 ports.
Duration
(Read Only)
See the time in days:hours:minutes:seconds that an active supplicant is
logged on via the port.
MAC Address
(Read Only)
See the ASCII value of the MAC address for each active supplicant
associated with a port.
35281_93
EXITSAVE NEXTPREVIOUS
RETURN
------------------------------------------------------------------------------------------------------------
1 00:12:23:58 nn-nn-nn-nn-nn-nn [FALSE] [FALSE]
2 54:02:56:00 nn-nn-nn-nn-nn-nn [FALSE] [FALSE]
Port Duration
(dd:hh:mm:ss)
MAC
Address
Initialize
Supplicant
Reauthenticate
Supplicant
