Quick Installation Guide TEW-424UB
Table ofofContents Table Contents English ..................................................................................................... 1. Before You Start ................................................................................ 2. How to Install .................................................................................... 3. Wireless Configuration ...................................................................... 1 1 2 7 Troubleshooting .........................................
1. Before You Start Package Contents ? TEW-424UB ? Quick Installation Guide Utility & Driver CD-ROM ? USB Cable ? System Requirements USB port: 1.1 or 2.0 ? ? CD-ROM Drive ? CPU: 300MHz or Above/ 800MHz or above (Windows Vista) Memory: 256MB RAM or above / 512MB RAM or above (Windows Vista) ? ? Windows Vista/XP/2000/ME/98SE Application Workstation with 54Mbps Wireless USB 2.0 Adapter (TEW-424UB) Cable/ DSL Modem 54Mbps 802.
2. How to Install Important! DO NOT install the USB adapter in the computer until instructed to do so. Note: Refer to the User's Guide on the Driver CD-ROM for Windows 98SE and Windows ME installation instructions 1. Insert the Utility & Driver CDROM into your computer's CD-ROM Drive and then click Install Utility. Then click on your operating system. 2. Follow the InstallShield Wizard instructions. For Windows Vista continue on to step 3. For Windows XP, proceed to step 7.
. Connect the wireless adapter to an available USB port on your computer. 6. Drivers will install automatically. Proceed to step 19. Windows XP 7. Click Continue Anyway. 8. Click Finish. 9. Connect the wireless adapter to an available USB port on your computer.
10. Click No, not this time. Then click Next. 11. Select Install the software automatically and then click Next. 12. Click Continue Anyway. 13. Click Finish. Then proceed to step 19.
Windows 2000 14. Click Yes. 15. Click Finish. 16. Connect the wireless adapter to an available USB port on your computer. 17. Drivers will install automatically. 18. Click Yes. Then proceed to step 19.
19. Remove the Utility & Driver CD-ROM from your computer's CD-ROM drive. Your installation is now complete. For detailed information regarding the TEW-424UB configuration and advanced settings, please refer to the User's Guide included on the Utility & Driver CD-ROM or TRENDnet's website at www.trendnet.com Register Your Product To ensure the highest level of customer service and support, please take a moment to register your product Online at: www.trendnet.
3. Wireless Configuration Note: If you are running Windows XP, you need to disable Wireless Zero Configuration. Please refer to question 4 of the Troubleshooting section. 1. On the bottom right-hand corner of the screen, double-click on the Wireless Adapter Configuration Utility icon. Windows Vista 2. Click Site Survey. Click the SSID that matches your wireless access point and then click Connect. Windows XP/2000 3. Click Site Survey.
Troubleshooting Q1: I inserted the Utility & Driver CD-ROM into my computer's CD-ROM Drive but the installation menu does not appear automatically. What should I do? A1: If the window does not appear automatically, click Start, click Run, and type D:\autorun.exe where "D" in "D:\autorun.exe" is the letter assigned to your CD-ROM Drive, and then press the ENTER key on your keyboard.
Certifications This equipment has been tested and found to comply with FCC and CE Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received. Including interference that may cause undesired operation. Waste electrical and electronic products must not be disposed of with household waste. Please recycle where facilities exist. Check with you Local Authority or Retailer for recycling advice.
Customer Support Visit www.trendnet.com/support Email: support@trendnet.com Europe (Germany . France . Italy . Spain . Switzerland . UK) Toll Free Telephone: +00800 60 76 76 67 English/Espanol - 24/7 Francais/Deutsch - 11am-8pm, Monday - Friday MET Worldwide Telephone: +(31) (0) 20 504 05 35 English/Espanol - 24/7 Francais/Deutsch - 11am-8pm, Monday - Friday MET Product Warranty Registration Please take a moment to register your product online. Go to TRENDnet’s website at http://www.trendnet.
