5. Repair Flow Chart
1. No Power (No LED indicator)
NG
Check power cord and board interface
Plug in power cord and interface
OK
Check F901, BD901, C907 NR901
NG
Replace F901 BD901 C907 NR901
OK
Check, Q904 IC904
Check Q901 IC901 D919 D901 D902
L906 R921
NG
Replace Q904 IC904
OK
Check D903, D917, IC902, Q902 ZD902
OK
Replace D903, D917, IC902, Q902 ZD902
Replace Q901 IC901 D919 D901 D902
L906 R921
OK
NG
NG
Check IC903，Q903
NG
Re
p
lace IC902，Q902
Check D916，D913，D915，IC907
Re
p
lace D916，D913，D915，IC907
OK
NG
