11. BOM List
E267AZNK2WE1NN
Location Part No. Description
001T6021 1 SCREW
007T 6 L 12 COMPOUND PALLET
007T 6 L 13 COMPOUND PALLET
044T3231 21 2 EVA WASHER
044T3231 21 3 EVA WASHER
044T6000 1 1A EMPTY CARTON FOR LOADING
044T6000 4 6B SPACE PAPER
044T9003 1 CORNER PAPER
045T 77 3 PE PACKING
049T 51 1A ERADICATOR
052T 1185 MIDDLE TAPE FOR CARTON
052T 1186 SMALL TAPE
052T 1211 A ADHESIVE TYPE
052T 1211 B ADHESIVE TYPE
052T 2191 A TAPE
052T6019 1 YELLOW TAPE
052T6022 27 GP BLUE TAPE
078T 478 2 YL SPEAKER 8 OHM 10 W 90 X51 MM SUNLINK
078T 478 2 YR SPEAKER 8 OHM 10 W 90 X51 MM SUNLINK
E08904 089T 17356C554 AUDIO CABLE
089T 725HAA DB D-SUB
089T402A15N IS POWER CORD
092TB1JX1A21GM BATTERY LR06 XINLI
095T8013 2W561 WIRE HARNESS 2P 500
095T8013 3W570 WIRE HARNESS 3P 500
095T801413W651 WIRE HARNESS 13P-5P+8P
095T801414WH27 WIRE HARNESS 14P-12P 180MM
095T801836D504 LVDS CABLE 36P-30P 260MM
098TR7BDINEENF REMOTE FUHUA FOR ENVISION
0D1T 930 6120 SCREW
0M1T 930 4120 SCREW
0M1T 930 4120 SCREW
0M1T 940 6120 SCREW
0M1T 940 6120 SCREW
0M1T 940 6120 SCREW
0M1T 940 8 47 CR3 SCREW
0M1T 940 8120 SCREW
0M1T1140 6120 SCREW 4*6MM
0M1T1730 6120 SCREW 3*6MM
0M1T1730 6120 SCREW 3*6MM
0M1T1740 6120 SCREW
0M1T1740 6120 SCREW
0Q1T 340 12 47 CR3 SCREW
0Q1T 930 6120 SCREW
0Q1T 930 6120 SCREW
