Operating instructions

26’’ LCD TV Envision L26W761
60
C733 067T 305471 3T 470UF +-20% 16V
C732 067T 305471 3T 470UF +-20% 16V
C731 067T 305471 3T 470UF +-20% 16V
C924 067T215Y1007KT EC105 10U 50V KEM50V
C931 067T215Y2207KT EC CAP 22UF 50V
C927 067T215Y2212KT LOW ESR EC 220UF 10V 6.3*11MM
C928 067T215Y2212KT LOW ESR EC 220UF 10V 6.3*11MM
C4K2 067T215Y4704KT EC CAP.105
C932 067T215Y4704KT EC CAP.105
C933 067T215Y4704KT EC CAP.105
R2 061T0603101 CHIP 100OHM 1/16W
R4 061T0603102 CHIP 1K OHM 1/16W
R1 061T0603102 CHIP 1K OHM 1/16W
R3 061T0603153 RST CHIPR 15 KOHM +-5% 1/10W
C3 065T0603104 32 CHIP 0.1UF 50V X7R
C5 065T0603104 32 CHIP 0.1UF 50V X7R
C4 065T0603104 32 CHIP 0.1UF 50V X7R
C1 065T0805475 15 CHIP 4.7UF 16V X5R
LED1 081T 14501 KT LED
ZD1 093T 39S 24 T RLZ 5.6B LLDS
715T2471 1 2 IR BOARD PCB
C24 065T0603104 32 CHIP 0.1UF 50V X7R
C25 065T0603104 32 CHIP 0.1UF 50V X7R
C26 065T0603104 32 CHIP 0.1UF 50V X7R
C22 065T0603104 32 CHIP 0.1UF 50V X7R
C23 065T0603104 32 CHIP 0.1UF 50V X7R
C21 065T0603104 32 CHIP 0.1UF 50V X7R
C20 065T0603104 32 CHIP 0.1UF 50V X7R
715T2470 1 KEY BOARD PCB
T902 006T 31502 1.5MM RIVET
T901 006T 31502 1.5MM RIVET
Q903 006T 31502 1.5MM RIVET
Q902 006T 31502 1.5MM RIVET
L906 006T 31502 1.5MM RIVET
L905 006T 31502 1.5MM RIVET
L904 006T 31502 1.5MM RIVET
C973 006T 31502 1.5MM RIVET
C919 006T 31502 1.5MM RIVET
IC908 056T 158 10 T IC AZ431AZ-AE1 TO-92 AAC
IC906 056T 158 10 T IC AZ431AZ-AE1 TO-92 AAC
Q908 057T 420 3 T KTA1273
R974 061T 17210252T RST CFR 1KOHM +-5% 1/4W
R917 061T 60247052T CFR 47OHM +-5% 1/6W
C962 064T701J1040AT 0.1UF J 50V
C940 067T215Y1007KT EC105 10U 50V KEM50V
C937 067T215Y2207KT EC CAP 22UF 50V
C918 067T215Y4707KT 47UF 50V
C915 067T215Y4707KT 47UF 50V
