16 GND Power Ground
17
LED0
Analog or digital input/
open drain output.
General-purpose analog/digital input or open drain
LED output.
18
LED1
Analog or digital input/
open drain output.
General-purpose analog/digital input or open drain
LED output.
19
LED2
Analog or digital input/
open drain output.
General-purpose analog/digital input or open drain
LED output.
20
LED4
Analog or digital input/
open drain output.
General-purpose analog/digital input or open drain
LED output.
21 LED5
Analog or digital input/
open drain output.
General-purpose analog/digital input or open drain
LED output.
22 GND Power Ground
23 1V8 Power 1.8V output
24 VDD_PADS_3&7 Power 1.8 V/3.3 V PIO supply
25 VDD_PADS_1 Power 1.8 V/3.3 V PIO supply
26 PIO2
Digital: Bidirectional with programmable
strength internal pull- up/pull-down
Programmable I/O line 2.
Alternative function : TBR_MISO[3]
27 PIO3
Digital: Bidirectional with programmable
strength internal pull- up/pull-down
Programmable I/O line 3.
Alternative function : TBR_MISO[2]
28 PIO4
Digital: Bidirectional with programmable
strength internal pull- up/pull-down
Programmable I/O line 4.
Alternative function : TBR_MOSI[1]
29
PIO5
Digital: Bidirectional with programmable
strength internal pull- up/pull-down
Programmable I/O line 5.
Alternative function : TBR_MISO[1]
30
PIO6
Digital: Bidirectional with programmable
strength internal pull- up/pull-down
Programmable I/O line 6.
Alternative function : TBR_MOSI[0]
31
PIO7
Digital: Bidirectional with programmable
strength internal pull- up/pull-down
Programmable I/O line 7.
Alternative function : TBR_MISO[0]
32
PIO8
Digital: Bidirectional with programmable
strength internal pull- up/pull-down
Programmable I/O line 8.
Alternative function : TBR_CLK
33
PIO1
Digital: Bidirectional with programmable
strength internal pull- up/pull-down
Automatically defaults to RESET# mode when the
device is unpowered, or in off modes.
Reconfigurable as a PIO after boot.
Alternative function : Programmable I/O line 1
34 GND Power Ground
