User Manual See the Unseen
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
User Manual P/N 5002035-1 Rev D ©2014 L-3 EOTech. All Rights Reserved Registered Trademarks of L-3 EOTech Patents This product is covered by one or more of the following patents: U.S. Patent Nos.: 5,288,649; 5,367,167; 6,267,501; 6,586,831; 6,521,477; 6,690,014; 6,479,320, 6,879,035, 7,015,074, 7,262,412, 7,375,331, 7,718,965, 7,655,909, 6,777,681, 8,183,513, and under license to 5,196,703. Euro.Pat.Appllication. 1159591. Additional Patents Pending.
1. Introduction ............................................................................... 7 • Welcome to Infrared .......................................................... 7 • Handling & Precautions.......................................................9 • Contacting L-3 Communications Infrared Products........... 9 2. Operation................................................................................. 10 • The X320 Thermal Imaging Camera ...............................
1. Introduction Thank you for choosing the X320 Thermal Imaging Camera. With its small size, rugged design, and simplicity, you can now focus on the job at hand, rather than the camera in your hand. Before using this camera, please read these instructions carefully, and retain them for future reference. Welcome to Infrared L-3 EOTech has long been a leader in the production and development of military products based on infrared thermal imaging.
The X3200 was designed to sense differing amounts of long wavelength infrared coming ing from the various areas of a scene and to convert them to corresponding intensities of visible light on a display. This allows true see–in–the–dark dark capability, as well as the ability to discern additional information—differences differences in temperature—by observing ing the thermal properties of objects in any light condition.
• Handling and Precautions ⇒ All batteries can cause property damage or bodily injury if a conductive material such as jewelry or keys touch exposed terminals. Exercise care when placing batteries inside a pocket, case, or other container with metal objects. ⇒ Do not replace batteries in a potentially explosive atmosphere, such as a gas station orr any place where you might normally be advised to turn off your vehicle engine. Contact sparking may occur and cause an explosion.
2. Operation The X320 Thermal Imaging Camera Submersible to 1 meter Rubber Armored construction Floats in water Connect External Power, USB, or external Video.
Holding the Camera ⇒ The Camera can be mounted to a tripod using the 1/4-20 insert. ⇒ handed, or left left-handed. The Camera can be held either right-handed, ⇒ To avoid dropping the camera, attach ttach the strap provided. Both a neck strap and a wrist strap are provided for your convenience. Attach the strap to the camera by looping it through the attachment point as shown here.
Loading the Batteries Open the battery Door Unscrew Battery Door knob Counterclockwise Open the door to install batteries Install 2 AA Lithium Batteries “+” & “ – “ symbols inside the battery compartment indicate the direction to install batteries Notice the Raised Tab next to the (+) sign, and the Sunken Tab next to the (-)) sign. These tabs allow the user to install the batteries in complete darkness by “feel” - without having to “see” the battery symbols. Sunken Tab Insert battery with Positive end down.
Batteries ⇒ L-33 EOTech recommends the use of Lithium AA batteries. The camera can operate with Alkaline, Nickel-Metal Metal-Hydride (NiMh) rechargeable, but performance and battery life may be inconsistent. *L91 Lithium batteries are recommended for maximum operating time. The camera does not have an internal battery charger. If using rechargeable batteries, they must be charged with a separate external charger.
Camera Start-Up The camera requires approximately 5 seconds of start-up time. During these 1st 5 seconds after the camera is switched on, a logo will appear in the Display. After 5 seconds have passed, the logo will disappear, and video of the thermal scene begins. Camera Shutter To maintain an optimum Thermal Image, the X320 automatically shutters. During this shutter, the video freezes for approximately 3/4 second, and a faint “click” sound may be heard inside the camera.
L91 Batteries provide enough charge for approximately 6 hours of operation. FULL EMPTY Operating Time is based on a display set to minimum brightness (night-time setting), and camera at room temperature. Very Low or Very High temperatures, and Brightness Setting of the Display, could reduce the expected time of operation by 50%. Partially used alkaline batteries may not have enough energy to start the camera, reducing total operating time.
Adjusting the Display Brightness Turn the User Control Switch past the on/off detent, continuing to increase the LCD display brightness. Bright Brighter LCD Display: Turn Clockwise Dimmer LCD Display: Turn Counterclockwise Function Off Dim On To maximize battery life, set the LCD Display to the minimum brightness setting practical.
⇒ function for a long push is to cycle through white/black hot and colorized video modes. Extended Long Push (Factory Defined) – Press and hold User Control Switch for period longer than 5 seconds. *An Extended Long Push resets the camera to factory defaults defaults. This may be desireable if the user wishes to undo any changes that were made using the GUI and return the camera to original out of the box configuration.
Cleaning Do not apply any chemicals to the camera. ⇒ Clean the body of the camera using a water-moistened cloth. ⇒ Clean the Lens with a cleaner/cloth that has been specially formulated for cleaning camera lenses – one is provided, and if additional cloths are needed, they may be purchased from any camera retailer. 3. GUI Included with the X320 is a Graphical User Interface (GUI) that the user can use to customize the scene display and the functionality of the User Control Switch.
When starting the GUI a warning message appears on the computer screen It is recommended that the user insert a fresh set of batteries or plug the camera into the optional power adapter and remove the internal batteries when communicating with the GUI to avoid data loss. IF THE X320 LOSES POWER DURING COMMUNICATION WITH THE GUI, INTERNAL MEMORY OF THE CORE MAY BE CORRUPTED AND THE CAMERA MAY NOT FUNCTION PROPERLY UNTIL FACTORY DEFAULTS ARE RESTORED.
The single panel screen shown above provides access to all of the customization options available to the user via 10 separate user zones. First make sure that the X320 is turned ON. Next, connect the camera to a computer USB port using the included cable with the USB connector. Next, click the Connect button . Once connected the Status light turns green and changes from to and the user can now configure the X320.
Multi-function Button Settings This zone configures the operation of the User Control Switch. Drop Box Expanded The Very Long Push drop box is a factory defined function that resets the X320 to factory defaults and is grayed out since it cannot be re-assigned to another function. Selecting an option from the drop boxes defines the operation of the X320 when the User Control Switch is pressed for the specified time period.
1.00× is always selected and is the default power up setting. Factory defaults select 1.00× and 2.00× and pressing the User Control Switch cycles between these two settings. Colorization Sequence sets the X320 to toggle through the selections made in the Colorization Sequence zone White Hot means that cold objects in the scene appear black and hot objects appear white with all objects between being shades of gray.
Below is an example of a standard image with Hot Target Level I and II applied.
Temperature units selected in the Temperature Units zone applies to the temperature setting temperatures used in the custom colorization settings. Manual Touch-up instructs the camera to perform a single point non-uniformity correction. Auto Touch-up calibrations occur periodically for the first 120 seconds as the camera is warming up unless turned off by the user in Camera Shutter Touch-up zone.
assigned to perform Manual Touch-up for improved image quality. Display Icons turns symbology elements ON/OFF in the display. o Temperature Number displays the value of the temperature reading in the scene. The temperature reading is taken by sampling the center 4×4 pixels of the scene. This is centered about the crosshair. o C-F Character displays the units of the temperature reading (C for degree Celsius and F for degree Fahrenheit). The Temperature Units zone is used to select the temperature units.
DO NOT DISCONNECT THE CAMERA FROM THE COMPUTER OR REMOVE POWER WHILE DATA IS BEING SAVED BY APPLY CHANGES. IF THE CAMERA LOSES POWER WHILE DATA IS BEING SAVED, THE CAMERA MEMORY MAY BE CORRUPTED. A message pops up to confirm that you want to save the changes you have made. Once the changes have been saved successfully the Status symbol turns green and it is now safe to disconnect the camera.
You may also return to factory defaults without using the GUI by holding down the User Control Switch for 5 seconds. 4. Accessories Contact L-3 EOTech for accessories that are approved for use with your X320 Camera. Accessory Video & Power Adapter Common accessories for the X320 camera are: Video/USB Cables These may appear the same as common video/USB /USB cables. However, they are actually unique for the X320 Camera.
AC/DC Power Adapter Connect the AC/DC Power Adapter to the X320 Connector labeled “Power”, and to AC power (wall outlet). If batteries are installed and the AC/DC adapter is connected, the X320 receives its power from the AC/DC power adapter. It continues to monitor battery voltage and will stop operating if the batteries are low The AC/DC Power Adapter provides power to the camera – however, it does not recharge batteries installed in the camera.
4.
Physical 5 ¼ x 4 ½ x 2 (inches) 13.4 x 11.4 x 5.1 (cm) 13oz.
Frequently Asked Questions Q1 Can different battery types be used? A1 As long as the battery is an AA size, the user can install Alkaline, NiMh Rechargeable, or Lithium. NOTE: The X320 can run on AA Alkaline batteries but performance and battery life may be inconsistent. Q2 Why does my camera sometimes behave erratically? A2 When batteries become very low, the camera may behave erratically (i.e. video flashing, power cycles on & off, etc). Replacing batteries is the most common cure to erratic operations.
Trouble Shooting Guide Problem Possible Cause Possible Remedy After waiting the 5 seconds of warm up, the video does not appear and/or the screen is white or flashing blue Low Battery Power Replace Batteries No Image in the LCD display (no logo, no battery icon, and no video or white video) The LCD Display Brightness is too low Adjust the display brightness by turning the on/switch clockwise Batteries are low Replace Batteries or remove batteries and use external power A solid blue screen is disp
L-3 EOTech Warranty Product(s) will conform to L-3 EOTech’s current drawings and specifications at the time of delivery and be free from defects in material and workmanship under normal use and service for three (3) years, beginning on the date the product is delivered to the customer, (the “warranty”). L-3 EOTech’s sole obligation, buyer’s exclusive remedy, under the warranty is for L-3 EOTech, at its option, to repair or replace any part of the product which fails to meet the warranty.
HOW TO RETURN PRODUCTS FOR REPAIR: 1. Do not return product to place of purchase 2. Please complete the Return Authorization Request off the EOTech Web Site at www.eotech-inc.com/raform.php 3. Please advise Model, serial number, date of purchase (proof of purchase may be required) and a description of the problem 4. EOTech will issue you a Return Authorization # 5.
L-3 EOTech/ Infrared Products Division 3414 Hermann Dr Garland TX 75041 Phone: 1-888-EOTHOLO 1-888- 368- 4656 5002035-1 Rev D 35
