User`s manual

Installation
Page 3-10
Figure 12 displays the notch marks and what they should look like on your RIMM
memory module.
RIMMs have 232-pins and one notch that will match with the onboard RIMM
socket. RIMM modules are installed by placing the chip firmly into the socket at
a 90 degree angle and pressing straight down (figure 13) until it fits tightly into
the RIMM socket (figure 14).
Figure 12
Figure 13
RIMM Module clip before installation
RIMM Module clip after installation
To remove the RIMM module simply press down both of the white clips on either
side and the module will be released from the socket.
Figure 14
