B_in_situ_Adapt_e.fm Seite 9 Dienstag, 2. August 2005 1:42 13 Contents 1 2 3 3.1 3.2 3.3 3.4 4 5 6 General information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Function and operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Delivery package and installation . . . . . . . . . . . . . . . . . . . . . . . . 12 Technical description . . . . . . . . . . . . . . . .
B_in_situ_Adapt_e.fm Seite 10 Dienstag, 2. August 2005 1:42 13 1 General information The in situ Adapter for the Eppendorf Mastercycler® and the Eppendorf Mastercycler® gradient enables in situ PCR reactions to be carried out on a specially developed carrier system. This allows the Mastercycler® and the Mastercycler® gradient to be used for the conventional PCR technique in different tube systems as well as for the in situ technique.
B_in_situ_Adapt_e.fm Seite 11 Dienstag, 2. August 2005 1:42 13 2 Safety precautions Voltage Before startup, please ensure that your power supply corresponds to the voltage specifications on the identification plate! Mastercycler or Mastercycler gradient must be plugged into a grounded socket. Before carrying out maintenance or cleaning work or replacing the fuses, switch off the Mastercycler, Mastercycler gradient or in situ adapter and disconnect them from the mains supply.
B_in_situ_Adapt_e.fm Seite 12 Dienstag, 2. August 2005 1:42 13 3 Function and operation 3.1 Delivery package and installation Delivery package – Metal carrier – Transparent covering hood (double-walled) – Transparent plate attachment – Operating manual Together with a transparent plate attachment, the covering hood offers protection during transport. The plate attachment and the covering hood should also be used for storing the adapter.
B_in_situ_Adapt_e.fm Seite 13 Dienstag, 2. August 2005 1:42 13 3.2 Technical description The glass slides are placed onto the four contact surfaces of the metal carrier: Up to four glass slides can be attached to the carrier 3.3 Programming The Mastercycler / Mastercycler gradient is programmed in accordance with the operating manual for these devices. The in situ Adapter is treated by the Mastercycler and Mastercycler gradient like all other tube types (i.e.
B_in_situ_Adapt_e.fm Seite 14 Dienstag, 2. August 2005 1:42 13 For Mastercycler gradient only: The Gradient function switches off automatically, independent of the entry in the Gradient field: The gradient is switched off FILES... Edit Load Standard New Delete UNNAMED – –/22.0° 3 4 5 Edit UNNAMED T=44.0° T=72.0° +0.0° R= 3.0°/s G=0.0° GOTO2 0:00:15 0:00:30 +0:01 +0.1°/s REP24 10:22:06 3.4 The in situ reaction – Place the in situ Adapter onto the thermoblock.
B_in_situ_Adapt_e.fm Seite 15 Dienstag, 2. August 2005 1:42 13 4 Maintenance The in situ Adapter does not require regular maintenance. Contamination can be removed using water or a mild laboratory cleaning agent. The covering hood should be wiped using a moist cloth only in order to prevent water or other liquids from entering the lateral ventilation slits of the double chamber. Do not allow any parts of the in situ Adapter to come into contact with organic solvents or aggressive chemical.
B_in_situ_Adapt_e.fm Seite 16 Dienstag, 2. August 2005 1:42 13 6 Ordering information Order number 5331 220.002 5331 221.904 0030 127.501 0030 127.510 0030 127.528 0030 127.
