Epson PowerLite Home 10+ ® ® Home Theater Projector • Projecteur cinéma maison User’s Guide Guide de l’utilisateur CPD-17904R2
Copyright Notice All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of Seiko Epson Corporation. The information contained herein is designed only for use with this Epson product. Epson is not responsible for any use of this information as applied to other products.
Contents 5 Remote Control Information 6 Presenting the Epson PowerLite Home 10+ 7 Registration and Warranty Projector Parts Projection Controls Using This Manual Getting More Information Supported Devices Cable Requirements Optional Accessories 7 8 9 10 10 11 11 12 Using the Projector 13 Choosing a Location Adjusting the Picture Adjusting the Volume Turning Off the Picture and Sound Freezing the Action Using the Projector’s Menu System Changing Menu Settings Adjusting the Appearance of the Picture
Caring for the Projector 25 Cleaning the Lens Cleaning the Projector Case Changing the Remote Control’s Battery Cleaning and Replacing the Air Filter Replacing the Lamp Resetting the Lamp Timer Storing the Projector Transporting the Projector 25 26 26 27 28 30 30 30 Problem Solving 31 What To Do When the Lights Flash Solving Picture Problems Solving Remote Control Problems Where To Get Help 31 32 36 36 Specifications and Notices 37 General Projection Lamp Remote Control Dimensions Electrical En
Important Safety Information Follow these safety instructions when setting up and using the projector: ■ Never look into the projector lens when the lamp is turned on; the bright light can damage your eyes. Never let children look into the lens when it is on. ■ Never open any cover on the projector, except the lamp and filter covers. Dangerous electrical voltages inside the projector can severely injure you.
■ Unplug the projector from the wall outlet before cleaning. Use a damp cloth for cleaning. Do not use liquid or aerosol cleaners. ■ This product includes a lamp component that contains mercury (Hg). Please consult your state and local regulations regarding proper disposal or recycling, and do not place in the trash. ■ Unplug the projector during lightning storms or when not in use for extended periods. ■ Don’t place the projector or remote control on top of heat-producing equipment.
Presenting the Epson PowerLite Home 10+ The Epson® PowerLite® Home 10+ Theater Projector lets you enjoy high-quality projection in the relaxing environment of your own home.
Projector Parts Control panel Focus lever Ventilation slots Infrared receiver Zoom lever Adjustable foot Lens cover S-video port Video port (composite video) Input B (computer) Input A (component video) Infrared receiver Speaker Remote control holder 8 Audio ports Control port for service use only Kensington security lock AC power inlet
Projection Controls Power button Turns the projector on and off Menu button Displays or hides projector’s menus Source button Switches the video input source Power light Indicates operating status Keystone correction and volume buttons Also used to navigate the projector’s menus Warning light Alerts you to problems Select button Selects a menu item or advances to the next menu Source buttons Switch between equipment connected to the projector Aspect button Changes the picture’s aspect ratio Arrow and
Using This Manual See the Quick Setup sheet to connect the projector to your video or computer equipment. This book contains all the information you need to use the projector, in addition to maintenance instructions, troubleshooting tips, important safety instructions, specifications, and warranty information. Please follow these guidelines as you read through the manual: Warnings: Must be followed carefully to avoid bodily injury. Cautions: Must be observed to avoid damage to your equipment.
Supported Devices You can connect the projector to any of the following video sources: VCR, DVD player, DTV decoder, HDTV tuner, videodisc player, cable/satellite box, TV, video game console, audio/video receiver, camcorder, personal video recorder, digital camera, or laser disc player. You can also connect to a desktop or laptop PC or Apple® Macintosh® system. The projector supports composite video, S-video, and component video, and it automatically senses the video format (HDTV, NTSC, PAL, or SECAM).
Optional Accessories Epson provides the following optional accessories for the projector: Product Part number Replacement lamp V13H010L29 Air filter replacement V13H134A04 Remote control V12H007T12 Customized carrying cases: Samsonite® wheeled soft case Samsonite soft shoulder bag ELPKS35 ELPKS43 Ceiling mount Suspension adapter False ceiling plate ELPMB42 ELPMBAPL ELPMBFCP Kensington security lock ELPSL01 Projection screens: 50-inch portable screen 60-inch portable pop-up screen 80-inch porta
Using the Projector Follow the instructions in this section to choose a location for the projector, adjust the image and volume, turn off picture and sound, freeze the action, or use the projector menus. Choosing a Location The distance from the projector to the screen or wall determines the size of the picture. The picture will be larger when you place the projector further from the screen. See the Quick Setup sheet for details about the relationship between distance and picture size.
■ Rear: You can also set up your projector behind a translucent screen. Choose Rear for the Projection option. ■ Rear/Ceiling: Professional installation is recommended if you choose to attach the projector to the ceiling behind a translucent screen. (See page 12 for information about ordering ceiling mounting equipment.) Choose Rear/Ceiling for the Projection option.
2. Rotate the focus ring to sharpen the picture, or the zoom ring to reduce or enlarge it. Zoom lever Focus lever 3. If your image looks like or , press the control panel until the image is corrected. and buttons on the projector’s 4. To optimize color settings, press the Color Mode button on the remote control to choose from these four pre-set color modes: ■ Dynamic For projecting in bright rooms; images will have greater color intensity.
Adjusting the Volume Use the control panel to adjust the volume of the projector’s audio system or speakers connected directly to the projector’s Audio ports: ■ Press the button to decrease the volume. ■ Press the button to increase the volume. Turning Off the Picture and Sound You can use the A/V Mute button on the remote control to darken your screen and turn off the sound. This is useful if you pause the video. ■ To turn off the picture and sound, press the A/V Mute button. The screen goes dark.
Using the Projector’s Menu System You can use the projector’s on-screen menus to fine-tune the image quality, check lamp usage, and customize projector features: ■ The Image menu controls the look and quality of the picture. It offers several ways to adjust the color and improve the sharpness and clarity of the picture. ■ The Setting menu lets you set the child lock or sleep mode, adjust the position and size of the picture, select front or rear projection, and customize other projector features.
3. Press the up or down arrow button on the remote control or the or button on the projector to move through the list of options. When the option you want to change is highlighted, press the Select button. You may see a list of settings, a submenu providing additional options, or a line menu or slider bar similar to the one below: 4. If you see a list of settings, use the arrow buttons on the remote control or the or button on the projector to move to the setting you want, then press the Select button.
1. Press the Menu button. You see the menu screen. 2. Press the Select button to select the Image menu. Then press the Select button again to select Picture Quality. 3. Use the arrow buttons on the remote control or the projector to set the following options: ■ , , or buttons on the Brightness Adjusts the brightness of the picture. Increase (+) the setting to make the picture brighter, or decrease (-) the setting to reduce brightness.
■ Theatre For projecting movies or images with dark scenes. ■ Theatre Black For projecting in a dark room; lamp brightness decreases and image contrast increases. 5. To save the adjustments you made in the Image menu, select the Memory option. Select Memory 1 to save your first set of adjustments. Later you can recall these settings by pressing the Memory button on the remote control. Note: You can save a second set of adjustments by selecting Memory 2.
4. Use the arrow buttons on the remote control or the projector to set these options: ■ , , or buttons on the Position See “Repositioning the Picture” on page 22. ■ Zoom Caption Adjusts both the length of the picture and its vertical position on the screen. You can adjust this function only when you’ve selected the Zoom aspect ratio. ■ Keystone Corrects vertical keystone distortion of the image (when your image looks like ). This procedure makes the image smaller.
6. Select the On Screen Display option to make changes to these settings: ■ Message Turn this option off if you don’t want to display the No Signal message or the name of the input source or color mode. Warning messages are still displayed. ■ Background Color Selects the screen color to display (blue or black) when you press the A/V Mute button on the remote control. ■ Startup Screen Turn on this option to display the Epson logo whenever the projector starts. 7.
Viewing Lamp Usage and Other Information Use the Info menu to view information about the display settings of your input source and the number of hours the lamp has been used. 1. Press the Menu button to display the menu screen. 2. Press the down arrow button on the remote control or the button on the projector to highlight the Info menu. Then press Select.
Restoring the Default Settings The Reset menu lets you reset the lamp timer and the projector’s memory, or return all the projector settings to their factory default values. 1. Press the Menu button to display the menu screen. 2. Press the down arrow button on the remote control or the button on the projector to highlight the Reset menu. Then press Select. You see this menu: 3. Change any of the following settings: ■ Lamp-Hours Reset See page 30 for detailed information.
Caring for the Projector Your projector needs little maintenance. All you need to do on a regular basis is keep the lens clean. You also need to clean the air filter periodically to prevent overheating. Warning: Before you clean any part of the projector, turn it off and unplug the power cord. Never open any cover on the projector, except the lamp and filter covers. Dangerous electrical voltages in the projector can injure you severely.
Cleaning the Projector Case Before you clean the case, turn off the projector and unplug the power cord. ■ To remove dirt or dust, wipe the case with a soft, dry, lint-free cloth. ■ To remove stubborn dirt or stains, moisten a soft cloth with water and a neutral detergent. Then wipe the case. Caution: Never use wax, alcohol, benzene, thinner, or other chemical detergents. These can damage the case. Changing the Remote Control’s Battery You can obtain a replacement CR2025 lithium battery commercially.
Cleaning and Replacing the Air Filter Clean the air filter on the bottom of the projector after every 100 hours of use. If it’s not cleaned periodically, it can become clogged with dust, preventing proper ventilation. This can cause overheating and damage the projector. 1. Turn off the projector and wait for the P power light to stop flashing. 2. Unplug the power cord and disconnect any cables. 3. Turn the projector over.
Replacing the Lamp The lamp lasts up to 3000 hours when the projector is used in Theatre Black mode. Lamp life results vary depending upon environmental conditions and usage. Turn the projector off when not in use. Continuous 24-hour-a-day use may reduce the overall life of this product. It’s time to replace the lamp when: ■ The projection image gets darker or starts to deteriorate. ■ The projector’s warning light flashes red. ■ The message Replace the lamp appears on the screen.
4. Use a small screwdriver to loosen the two silver screws holding the lamp in place. (You can’t remove these screws.) 5. Grasp the lamp as shown and pull it straight out. 6. Gently insert the new lamp and tighten its screws. Caution: Don’t touch the glass portion of the lamp assembly. Touching the glass could result in premature lamp failure. 7. To replace the lamp cover, insert the tabs and then snap the cover into place. (The projector won’t work if the lamp cover is loose.
Resetting the Lamp Timer 1. Press the Menu button on the projector or remote control. 2. Highlight the Reset menu and press the Select button. 3. Select Lamp Hours Reset. 4. When you see a prompt asking whether you want to execute the command, highlight Yes and press the Select button. 5. When you’re finished, press Esc or Menu. The lamp usage timer doesn’t register until you’ve used the lamp for at least 10 hours.
Problem Solving This section explains how to interpret the projector’s status lights, solve problems with the picture and remote control, and contact technical support. What To Do When the Lights Flash The lights on top of the projector indicate the projector’s status and let you know when a problem occurs. If the projector isn’t working correctly, first turn it off, let it cool, and unplug it. Then plug the power cord back in and turn on the projector.
The warning light is flashing orange. High-speed cooling is in process. If the projector gets too hot again, projection stops automatically. Make sure there is plenty of space around and under the projector for ventilation. Clean or replace the air filter if necessary. See page 27 for details. The warning light is red. The projector is too hot, which turns off the lamp automatically. Let it cool for five minutes, then turn it back on.
■ Try reconnecting both ends of your cable. ■ Make sure your video equipment is on. If it isn’t, turn the projector off, then turn it on again after you’ve turned on your video equipment. You see a screen with the message No Signal displayed. ■ Make sure your video equipment is turned on. ■ Make sure your cable(s) are connected correctly, as described in the Quick Setup sheet.
4. Click Mirror Displays in the lower corner of the screen. One of the monitor icons automatically moves on top of the other. Click here If you’re using a Macintosh laptop with OS 9.x or earlier: 1. From the Apple menu, select Control Panels, then click Monitors and Sound. 2. Click the Arrange icon, and then drag one monitor icon on top of the other. Click here Drag one monitor icon on top of the other If the Arrange option isn’t available, you may need to select one of the Simulscan resolutions.
Only part of the picture is displayed, or the picture is distorted. ■ Press the Aspect button to select a different aspect ratio. ■ Use the Position setting in the Setting menu to reposition the image on the screen. See page 22 for details. The picture is trapezoid-shaped. Press the and buttons on the projector to correct the problem. The picture contains static or noise. ■ Make sure your cable is securely connected at both ends. ■ Don’t use an extension cable or a cable longer than 6 feet.
Solving Remote Control Problems The projector doesn’t respond to remote control commands. ■ Make sure you’re within 20 feet of the projector, and within range of the projector’s front or back sensor (approximately 30° left or right, and 15° above or below). ■ You may need to replace the remote control’s battery. See page 26 for details. ■ Dim the room lights and turn off any fluorescent lights. Make sure the projector is not in direct sunlight.
Specifications and Notices General Type of display Poly-silicon TFT active matrix Size of LCD panels 0.55 inch (14 mm) wide Lens F=1.7 to 2.1, f=13.9 to 21.4 mm Resolution (native format) 854 × 480 pixels, 480p Brightness 1200 lumens (ANSI) Color reproduction 24 bit, 16.8 million colors Contrast ratio 800:1 Image size 30 to 300 inches (0.76 to 7.6 m) Projection distance 2.5 to 46.8 feet (0.76 to 14.3 m) Internal sound system 1 W monaural Zoom ratio 1:1.54 Optical aspect ratio 16.
Dimensions Height 4.5 inches (114 mm) Width 15.8 inches (402 mm) Depth 11.6 inches (294 mm) Weight 7.9 lb. (3.6 kg) Electrical Rated frequency 50/60 Hz AC Power supply 100 to 120 VAC, 2.3 A 200 to 240 VAC, 1.
Compatible Video Formats The projector supports HDTV, NTSC, PAL, and SECAM international video standards, as well as the monitor display formats listed below. To project images from a computer, set the computer’s video card at a refresh rate (vertical frequency) compatible with the projector; see the table below for compatible formats. Some images are automatically resized to display in the projector’s native resolution (480p).
FCC Compliance Statement For United States Users This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio or television reception.
Declaration of Conformity According to 47CFR, Part 2 and 15 for Class B Personal Computers and Peripherals; and/or CPU Boards and Power Supplies used with Class B Personal Computers: We: Located at: Epson America, Inc. 3840 Kilroy Airport Way MS 3-13 Long Beach, CA 90806 Telephone: (562) 290-5254 Declare under sole responsibility that the product identified herein, complies with 47CFR Part 2 and 15 of the FCC rules as a Class B digital device.
product or part may be new or previously repaired to the Epson standard of quality, or, at Epson’s option, may be another model of like kind and quality. Exchange or replacement products assume the remaining warranty period of the product covered by this limited warranty, except that each replacement lamp carries the limited 90-day warranty stated above. What This Warranty Does Not Cover: This warranty covers only normal use of the product in the United States and Canada.
Index A E A/V Mute button, 9 Accessories, 12, 36 Air filter cleaning and replacing, 27 ordering, 12 Anti-theft device, 12 Aspect button, 9, 15, 35 Auto button, 9, 35 Electrical specifications, 38 Epson accessories, 12, 36 Home Service, 7 PrivateLine Support, 36 technical support, 10, 36 B Filter, see Air filter Focus lever, 8, 15 Freeze image, 16 Battery, changing, 26 Blurry picture, 35 Brightness, 37 C Cables, 11 to 12 Ceiling projection, 13 to 14, 21 Child Lock, 21 Cleaning air filter, 27 lens and
M S Macintosh desktop adapter, 12 Memory button, 9, 20 Menu button, 9 Menus adjusting picture quality, 18 to 20 using, 17 to 18 Moving projector, 30 Safety approvals, 38 Safety instructions, 5 to 6 Sleep Mode, 21 Sources, switching, 9, 33 Specifications compatible video formats, 39 electrical, 38 environmental, 38 general, 37 lamp, 37 remote control, 37 Storing projector, 30 Support, see Technical support Sync, 19, 35 P Picture problems, 32 to 35 Picture, repositioning, 22 Problems picture, 32 to 35 rem
