Using the Control Panel 182
EPSON AcuLaser C3800 User's Guide
*1
After this item is changed, the setting value takes effect after a warm boot or after the power is turned on
again. While it is reflected in the Status Sheet and EJL read-back, the actual change takes effect after a
warm boot or after the power is turned on again.
*2
Available only when USB Host is set to ON.
USB Host
Enables you to print directly from a USB memory via a USB Host interface.
Device Detection
Specifies whether or not to detect the device inserted in the USB Host interface every time.
If you select Auto, the device is detected every time just after the device is inserted. If you
select Manual, the device may not be detected when the printer is in the sleep mode.
PCL Menu
These settings are available in the PCL mode.
*1
Available only when downloaded fonts are available.
*2
Available only when the optional font ROM module is installed.
*3
Depending on the font that has been selected.
*4
Depending on whether Letter (60) or A4 (64) paper has been selected.
Item Settings (default in bold)
FontSource Resident, Download
*1
, ROM A
*2
Font Number 0… 65535 (depending on your settings)
Pitch
*3
0.44 … 10.00 … 99.99 cpi in 0.01 cpi increment
Height
*3
4.00 … 12.00 … 999.75 pt in 0.25 pt increment
SymSet IBM-US, Roman-8, Roman-9, ECM94-1, 8859-2 ISO, 8859-9 ISO, 8859-10ISO,
8859-15ISO, PcBlt775, IBM-DN, PcMultiling, PcE.Europe, PcTk437, PcEur858,
Pc1004, WiAnsi, WiE.Europe, WiTurkish, WiBALT, DeskTop, PsText, VeInternati,
VeUS, MsPublishin, Math-8, PsMath, VeMath, PiFont, Legal, UK, ANSI ASCII,
Swedis2, Italian, Spanish, German, Norweg1, French2, Windows, McText,
Hebrew7, 8859-8 ISO, Hebrew8, Arabic8, OCR A, OCR B Pc866Cyr, Pc866Ukr,
WinCyr, ISOCyr, Pc8Grk, Pc851Grk, WinGrk, ISOGrk, Greek8, Pc862Heb,
Pc864Ara, HPWARA
Form 5 … 60/64
*4
… 128 lines
CR Function CR, CR+LF
LF Function LF, CR+LF
Tray Assign 4K, 5S, 4
